Installation
Tools
- Basin Wrench
- Adjustable Wrench
- Pipe Wrench
- Screwdriver
- Thread Seal Tape
- Supply Lines
- Protective Goggles
- Silicone Sealant
Maintenance
Plumbworks
faucets are crafted with the skill and quality
®
to last a lifetime. By following the instructions in this
booklet you will enjoy this quality item for years to come.
To clean, wipe gently with a soft damp cloth, then wipe
dry. Plumbworks
finishes are very durable.However, to
®
assure a long lasting luster, harsh abrasives or polishes
should be avoided.
Safety Tips
Turn off the water before loosening any connections
or disassembling the faucet. When working underneath
a sink, protect your eyes from any dust or dirt by wearing
safety glasses.
Important Points
Most faucet problems can be fixed by tightening a nut or
connection or replacing a washer. Check supply line
connections for any leaks and tighten if necessary. Don't
overtighten any supply line connections.
Need Help?
Have an installation question? DO NOT RETURN THIS PRODUCT TO THE
STORE. Call toll free: 1-800-545-5230 Monday thru Friday 8:00am - 5:00pm CST
For Models: 673-7140, 673-7141
Single Handle Lavatory
Faucet With Pop-Up
1.
Advertisement
Summary of Contents for PW 673-7140
- Page 1 Installation Tools For Models: 673-7140, 673-7141 - Basin Wrench - Adjustable Wrench Single Handle Lavatory - Pipe Wrench Faucet With Pop-Up - Screwdriver - Thread Seal Tape - Supply Lines - Protective Goggles - Silicone Sealant Maintenance Plumbworks faucets are crafted with the skill and quality ®...
-
Page 2: Parts Diagram / List
Parts Diagram / List Pop-up Assembly (complete) Hot/Cold Button Handle Screw Handle Adjustment Ring Dome Nut Cam Packing Stainless Steel ball Plug Cover plate Faucet Seat (2) Faucet Spring (2) Mounting Bolt (2) O-Rings Fixing Chip Screw Copper Tubing Mounting Nut (2) Putty Plate Outlet Gasket... - Page 3 Preparation/Assembly (Steps 1-5) 1. Shut off the water supply from the stop valves by turning the handle clockwise and remove the existing faucet from the sink. 2. Remove any dirt or plumber’s putty from around the faucet holes on the sink. Place the putty plate (19) onto the cover plate (23) and thread the mounting bolts (13) to the underside of the cover plate (23).
- Page 4 Assembly (Steps 6-10) 6. Secure the faucet by threading the mounting nuts (18) onto the mounting bolts (13). Check the position of the faucet and hand tighten until faucet is securely mounted. NOTE: It is helpful to have a second person hold the faucet in place while tightening the mounting nuts (18).PLEASE NOTE: Do not remove the customer service tag with the model number and phone number...
- Page 5 Assembly (Steps 11-15) 11. Remove the drain seat (28) and the pop-up plunger (34) from the pop-up assembly. Turn the mounting nut (27) down towards the center of the drain body (26). 12. Apply a bead of silicone sealant to the underside of the drain seat flange (28).
- Page 6 Assembly (Steps 16-20) figure A 16. Place the pivot rod (30) into the opening in the drain body (26), making sure that the rod enters the opening at the bottom of the plunger (34, see figure A). NOTE: Make sure that the pivot rod seal (37) is seated inside the drain body (28, see figure B).
- Page 7 Assembly (Steps 21-23) 21. Before turning the water on, unscrew and remove the aerator (24) from the faucet spout. If necessary, use pliers and a cloth to protect the finish of the faucet. 22. Open the hot and cold water supply valves. Check for leaks at the shut off valves and the faucet shanks.
-
Page 8: Troubleshooting
Troubleshooting If a faucet installation doesn’t deliver water properly or leaks, finding the cause and fixing it can be easy. Problem: Cause: Action: Uneven Aerator assembly water flow. is dirty or improperly installed Remove any loose Replace the aerator Loosen the aerator Remove the aerator on the faucet.
Need help?
Do you have a question about the 673-7140 and is the answer not in the manual?
Questions and answers
