SafeTrust 8855-000 Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

8855-000 – 8860-000
Quickstart Guide
Last Updated: January 15, 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8855-000 and is the answer not in the manual?

Questions and answers

Summary of Contents for SafeTrust 8855-000

  • Page 1 8855-000 – 8860-000 Quickstart Guide Last Updated: January 15, 2024...

  • Page 2: Table Of Contents

    In the box What you'll need Contents Installation Configuration Testing Regulatory Support Safetrust Inc. | safetrust.com sales@safetrust.com...

  • Page 3: In The Box

    In the box Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 4 IoT Sensor USB Reader Cord is USB-A format (USB-C available as special order) Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 5 Optional Accessories 9200-007-01 - 55 Degree 9004-08-10 - Wall Mount Desktop Mount Bracket For mounting to wall Stand for use on desk (includes screws for fixing) environment Safetrust Inc. | safetrust.com sales@safetrust.com...

  • Page 6: What You'll Need

    What you'll need Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 7 A WiFi connection is preferable however configuration is also possible using the Safetrust Wallet App A PC/printer/device to plug the USB into Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 8 Installation Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 9 To install, simply uncoil the cord and plug the IoT Sensor USB Reader/or Programmer into your laptop or desktop computer. Within 5 seconds, the IoT Sensor will complete its "power on cycle" and be operational and ready for configuration. Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 10 Configuration Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 11 Open the Safetrust Wallet App and select the Manage Sensor tab. Make sure your system administrator has set you up with this role. Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 12 With the Admin Installer tab open from the App, bring the phone in range of the IoT Sensor and once visible from the App, highlight and select “Configure.” Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 13 • Assign a short Name and Description using alphanumeric characters. • Choose a Media Output for the sensor (the default is set to USB Keyboard). *Note: Identity System must be previously created in the Safetrust Credential Manager portal by a system administrator.
  • Page 14 WiFi Profile or manually enter WiFi details. Once complete, tap the ‘Submit’ button at the bottom of the configuration screen to save settings*. *Note: The IoT USB will restart to apply the changes to the configuration. Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 15 When the IoT Sensor information is saved successfully to Credential Manager and assigned to the Identity System, the new description will appear in the Manage Sensor tab with a unique serial number assigned. Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 16 Supported technologies such as DESFire, Prox, iCLASS, Apple Access, HCE, etc. Human Interface Device Data Model Hexadecimal Wiegand, Card Number, Facility+Card number Custom format with static text, card, facility raw Carriage return and line feed Networking Enterprise-grade WiFi options, including PPSK, 802.1x EAP/TLS Safetrust Inc. | safetrust.com sales@safetrust.com...

  • Page 17: Testing

    Testing Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 18 LED Ring Access with cards Status LED Solid red Indicates idle mode Flashing red, blue, green Power up mode Flashing green Card credential is read and transmitted through designated wires Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 19 Access with Mobile – BLE Status LED Solid red Indicates idle mode Flashing red, blue, green Power up mode Solid Blue Mobile credential detected Flashing green Mobile BLE credential is read and transmitted through designated wires Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 20 LED Ring Access with Mobile – NFC Status LED Solid red Indicates idle mode Flashing red, blue, green Power up mode Flashing green Mobile BLE credential is read and transmitted through designated wires Safetrust Inc. | safetrust.com sales@safetrust.com...

  • Page 21: Regulatory

    Regulatory Information Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 22 (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CE Marking: Safetrust hereby declares that these proximity readers are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

  • Page 23: Support

    Thank purchasing Safetrust IoT Sensor USB. Support If for any reason you need assistance with your installation, please contact your local Sales representative . Sincerely - The Safetrust Team Safetrust Inc. | safetrust.com sales@safetrust.com...
  • Page 24 www.safetrust.com/support...
