Summary of Contents for LVM GEMINI INTERIOR DETAIL KIT
- Page 1 GEMINI INTERIOR DETAIL KIT for the REVELL Gemini Space Capsule 1/24 (00028/1835) (C)2014 by LVM Studios. All rights reserved...
- Page 2 Drill bit 0.5 mm Drill bit 0.8 mm Assembly Guide: Bend line: Part description: PEXYY, PE= photo etch, X = fret, YY = part number All dimensions in this manual are in millimeters (C)2014 by LVM Studios. All rights reserved...
-
Page 3: Parts Identification
02, 03, 04, 05, 08, 09, 10 and 11 are used in resin part R1, R2 and R3. The mentioned PE parts are not used anymore! 13 (5*) 07(2*) Fret B: 19(2*) 08(2*) 14L/14R 06 (4*) Resin: R6 (2x) R4 (2x) R5 (2x) (C)2014 by LVM Studios. All rights reserved... - Page 4 Cut 4* strip 0.25*0.5, length 30 mm and glue these at the locations indicated. Cut 2 strip 6.3*3.2 at the length of 20 mm and glue these in PEB02 as shown. 0.5*0.25 (2*) 90° UP 90° DOWN Large radius 90° UP (C)2014 by LVM Studios. All rights reserved...
- Page 5 PEB04. These holes were than reinforced with a flange. Use plastic pipe Ø4 (5 mm long) and a ball point pen to form these flanges at the holes with a half etched ring around them in part PEB04. Do not use to much force, just gentle!!! (C)2014 by LVM Studios. All rights reserved...
- Page 6 78°down 60°down 90° up 12°down 30°down 30°up PEB05 (2*) All bends 90° down PEB08 (2*) unless otherwise stated Plastic strip 3.2*4.8 L=22.5 Backside Twist tab with flat pliers PEB09 PEB06 (C)2014 by LVM Studios. All rights reserved...
- Page 7 Foot rests: The original seat also had foot rests as seen on the photos above. With styrene strip like Evergreen you can scratch build the foot rests. An original engineering drawing of the foot rest is shown below. (C)2014 by LVM Studios. All rights reserved...
- Page 8 For knobs use 0.75mm plastic rod, predril with drill bit 0.8mm. Cut off at about 1 mm. For PEB10, use drill bit 0.5mm to drill the holes and glue in position. PEA07, glue in position. Pre-drill if needed before PEA06 is placed. PEB10 Switch Knob PEA07 PEA06 (C)2014 by LVM Studios. All rights reserved...
- Page 9 PEA13 PEA12 Switch (wire 0.3 mm) Note: It is easier to pre-drill all holes, than paint and detail the instrument panels and finally place the swiches, etc.. The resin parts are already pre-drilled! (C)2014 by LVM Studios. All rights reserved...
- Page 10 PEB15L and PEB15R are the window frames. Use the PE parts as template to cut the windows out of the supplied clear plastic pla- te. Glue the frames to the windows and glue the sub-assembly in the hatch. For clear parts use PVA glue! Apply the following plastic parts to the hatch for extra detail. (C)2014 by LVM Studios. All rights reserved...
- Page 11 More reference photos are supplied on the CD-rom with this kit. PEB18L PEB18R (C)2014 by LVM Studios. All rights reserved...
- Page 12 Dry fit everything and check if everything matches up. It is known that the original kit has a pooring fitting. Check if the hatches open and close. If the hatches are blocked somehow you can bend the actuator arm untill the blockage is resolved. Bend slightly (C)2014 by LVM Studios. All rights reserved...
- Page 13 Space Modellers Group at Yahoo.com - http://groups.yahoo.com/group/space-modelers/ The Gemini Chronicles - http://gemini.eklapper.com/ Project Gemini—Spacecraft Films Support: If you need help or have questions for this kit you can always e-mail us at enquiries@LVM-Studios.com. (C)2014 by LVM Studios. All rights reserved...
- Page 14 No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopy, recording, or any information storage ad retrieval system, without permission in writing from the publishers. Photo etch design by and property of LVM Studios. Illegal imitations are subject to prosecution. (C)2014 by LVM Studios. All rights reserved...
