I N S T R U C T I O N M A N U A L
Cordless/Brushless
20Volt Li-Ion
AIR PUMP
Part Number: PB20VAP
IMPORTANT:
Read before using.
Compatible Batteries:
PB20VLIB2 Battery (2.0 Ah)
& PB20VLIB4 Battery (4.0 Ah)
www.theoriginalpinkbox.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB20VAP and is the answer not in the manual?

Questions and answers

Summary of Contents for The Original Pink Box PB20VAP

  • Page 1 I N S T R U C T I O N M A N U A L Cordless/Brushless 20Volt Li-Ion AIR PUMP Part Number: PB20VAP IMPORTANT: Read before using. Compatible Batteries: PB20VLIB2 Battery (2.0 Ah) & PB20VLIB4 Battery (4.0 Ah)
  • Page 2 Keep these instructions with the accompanying tool for the life of the tool. Read all of the instructions before assembling, operating or maintaining this tool. The Original Pink Box This manual has been compiled by Tools describing the purpose for which this tool has been designed, and contains all the necessary information to ensure its correct and safe use.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS..................Pg. 04 Electrical safety Personal safety Use and maintenance of Air Pump SAFETY PRECAUTIONS FOR AIR PUMP ............Pg. 05 PRODUCT SPECIFICATION......................Pg. 06 PARTS LIST AND SCHEMATIC DIAGRAM ............Pg. 07 FUNCTION DESCRIPTION ...................Pg. 08 How to charge the battery pack ..........................Pg. 08 How to install the battery............................Pg.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, re or serious personal injury. When using electrical appliances, basic precautions should always be taken and observed, including the following. ELECTRICAL SAFETY 1.

  • Page 5: Safety Precautions For Air Pump

    IMPORTANT SAFETY INSTRUCTIONS 5. Check whether the moving parts are misaligned or stuck, whether the parts are broken and any other conditions that may a ect the operation of the in ator. If damaged, please repair the in ator before use.

  • Page 6: Product Specification

    SAFETY PRECAUTIONS FOR INFLATOR 11. Do not attempt to pull or carry the inflator through the hose. 12. In addition to all safety rules of the inflator, all safety regulations recommended by the inflator manufacturer must be observed. Following this rule will reduce the risk of serious personal injury. 13.

  • Page 7: Parts List And Schematic Diagram

    PARTS LIST AND SCHEMATIC DIAGRAM A. Digital display B. Start switch C. Set button D. Light switch E. Tire pressure increase/decrease button F. Rubber cover handle G. Battery (NOT INCLUDED) H. LED lighting I. Air hose buckle J. Air hose K.

  • Page 8: Function Description

    FUNCTION AND OPERATION INSTRUCTIONS HOW TO INSTALL THE BATTERY Step 1: Fig. 3 Install battery pack or 12V car power adapter ■ Install or Remove the battery pack (Figure 3) To install: Slide the battery pack into the bottom until you hear a click.

  • Page 9: Install Or Remove 12V Automobile Power Adapter

    FUNCTION AND OPERATION INSTRUCTIONS ■ install or remove 12V car power adapter Fig. 4 (Figure 4) 1. Unravel cord before using. If the battery is installed, remove it from the machine rst by pressing battery release button and pulling out.. 2.

  • Page 10: Set Pressure Value

    FUNCTION AND OPERATION INSTRUCTIONS Note: When using the in ator, make sure that the hose is free of obstacles. If the hose is blocked, it may be overheated. Step 3: set the pressure value Fig. 6 1. Press the " "...

  • Page 11: Storage Of Air Hoses And Accessories

    FUNCTION AND OPERATION INSTRUCTIONS Note: 1.Since the pressure gauge is not calibrated and not binding for exact values, tire pressure must be checked by using a reliable measuring device after in ating tires with this pump. Driving a vehicle with improperly in ated tires could result in serious injury. 2.

  • Page 12: How To Install A Sports Ball Needle

    FUNCTION AND OPERATION INSTRUCTIONS Parts The accessories provided have a variety of functions: the conical adapter can be used on the smaller pinch valve to in ate small items such as children's toys. Usually, the user needs to blow air to in ate them. The sports ball needle can be used to in ate various types of balls or any other items that need to in ate the sports ball needle.

  • Page 13: Product Maintenance

    PRODUCT MAINTENANCE 1. Do not let brake fluid, gasoline, petroleum products, penetrating oil, etc. contact with plastic parts. Chemicals may damage, weaken or break plastic, resulting in serious machine injury. 2. Wipe the surface of the machine with a soft wet cloth to keep the surface of the inflator clean. Do not use solvents on plastic parts.
