UPDU RN3000 family short user manual
Thank you for choosing a PDU of the RN3000 family from RNX. Here are a few instructions to get you started.
Please read this manual carefully before
installing or decommissioning this product.
Failure to follow these instructions may result in
hazardous situations.
In addition to this operating manual the
generally applicable legal regulations and other
binding instructions concerning safety
regulations, regulations for preventing
accidents and regulations for the protection of
the environment must be adhered to.
To avoid potential injuries, make sure the
product is secured to a wall or a rack with its
mounting bolts.
This product is intended for indoor use only.
Humidity or water may result in electrical or fire
hazard.
Assembly and maintenance can only be done by
trained personnel (i.e. an electrician).
The building mains outlet where the PDU is
connected to must be protected by fuses or
MCBs in the building distribution box of the
same current rating of the PDU. E.g. a 16A PDU
must be protected by 16A MCBs and a 32A PDU
must be protected by 32A MCBs.
The inlet plug can be used as a disconnect
device: it must be easily accessible at all times.
This product is intended to be used only with IT
devices. The user must make sure that any load
connected to a C13 outlet has a rated current of
10A or less.
Modules are not hot-swappable. The product
must always be disconnected from the mains
when disassembled or serviced by trained
personnel (i.e. an electrician).
Outlets to
connect
the loads
Quick
select
button
2022-11-30 / Revision: 2.7 / Public
RIEDO NETWORKS Ltd / Route de la Fonderie 6 / CH-1700 Fribourg / Switzerland / +41 26 505 50 00 / support@riedonetworks.com / www.riedonetworks.com
Data interfaces
Buttons
Ethernet, USB,
auxiliary
Display
Mechanical mounts
Go to https://riedonetworks.com/support
download the full user manual for detailed
information on installing the product, using the
software and get a copy of the certificates.
Inlet cable
with plug
Outlets to
Quick select
connect
button
the loads
and
External
ground
terminal
