Instruction Manual
■Paint Tank
ＰＴ-１０Ｄ・１０ＤＷ・１０ＤＭ・１０ＤＭＷ
ＰＴ-２０Ｄ・２０ＤＷ・２０ＤＭ・２０ＤＭＷ
ＰＴ-４０Ｄ・４０ＤＭ・４０ＤＭＷ
ＰＴ-６０Ｄ・６０ＤＭ・６０ＤＭＷ
ＰＴ-８０Ｄ・８０ＤＭ・８０ＤＭＷ
This instruction manual includes important warnings, cautions and
operations.
Before use, be sure to read this instruction manual fully.
Keep this instruction manual in an appropriate place for immediate
reference.
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Anest Iwata PT-10D
- Page 1 Instruction Manual ■Paint Tank ＰＴ-１０Ｄ・１０ＤＷ・１０ＤＭ・１０ＤＭＷ ＰＴ-２０Ｄ・２０ＤＷ・２０ＤＭ・２０ＤＭＷ ＰＴ-４０Ｄ・４０ＤＭ・４０ＤＭＷ ＰＴ-６０Ｄ・６０ＤＭ・６０ＤＭＷ ＰＴ-８０Ｄ・８０ＤＭ・８０ＤＭＷ This instruction manual includes important warnings, cautions and operations. Before use, be sure to read this instruction manual fully. Keep this instruction manual in an appropriate place for immediate reference.
- Page 2 ■ Important information ・This product is exclusively used for coating. Do not use for other purposes than coating. ・Be sure to read and understand this instruction manual fully. The operator shall be fully conversant with the requirements stated within this instruction manual including important warnings, cautions and operations.
- Page 3 ■Contents Important information １． Safety precautions・・・・・・・・・・ ２ ２． Check the products ・・・・・・・・・ ３ ３． Specifications・ ・・・・・・・・・・・ ４ ４． Name of each section and function・・ ５ ５． Installation ・・・・・・・・・・・・・ ７ ６． Operation・ ・・・・・・・・・・・・・ ７ ７． Maintenance・・・・・・・・・・・・・１１ ８． Problems and remedies・・・・・・・・１２ ９． Parts list・・・・・・・・・・・・・・・１４ - 1 -...
- Page 4 ■１．Safety precautions Wear protective gear. During painting, be sure to wear protective gear such as glasses, mask or gloves. Paints or solvents might enter your eyes or you might inhale them. If you feel any abnormality during operation, immediately see a medical doctor. Be careful about ventilation.
- Page 5 Be careful about explosion. ・Be sure to use it at less than maximum fluid operating pressure. If done, it can cause damage to the paint tank or emission of paint or flying parts, resulting in serious bodily injury. ・Never remove safety valve or alter setting figures. If done, it makes it difficult to deal with emergencies, resulting in explosions or accidents.
- Page 6 Where to attach warning stickers Always keep warning labels clean. If they become dirty or damaged, replace them with new ones. If you need new stickers, contact the shop which sold the product to you. ■３. Specifications PT-10 PT-20 PT-40 PT-60 PT-80 PT-10...
- Page 7 ■４. Name of each section and function Paint tank feeds paint in paint tank by pressure which is adjusted by an air regulator. ＰＴ－２０Ｄ(W)（manual agitating system） - 5 -...
- Page 8 ＰＴ－２０ＤＭ(W)（automatic agitating system） - 6 -...
- Page 9 If you loosen butterfly nut while compressed air remains in paint tank, flying parts or paint can cause serious injury or accidents. Job ２ Close air valve and stop air motor. （This is not necessary in the case of manual agitating type PT-10D(W), 20D(W), 40D, 60D and 80D） - 7 -...
- Page 10 Job ７ Open oil cap (screw) of air motor and pour in grease. After supplying grease, securely close oil cap. （This is not necessary in the case of manual agitating type PT-10D(W), 20D(W), 40D, 60D, and 80D.） ６－２．Start-up operation and adjustment ・Never remove safety valve or alter setting figures.
- Page 11 After spray test, start normal coating job. ６－３．End of operation Job １ Close air valve and stop air motor （this is not necessary for manual agitating type PT-10D(W), 20D(W), 40D, 60D and 80D） Job ２ Close air cock, open exhaust valve to release compressed air pressure in paint tank.
- Page 12 ・Dirty safety valve fails and can also be dangerous. Pay special attention to this point. Safety valves for PT-10D(W), 10DM(W), 20D(W) and 20DM(W) have been adjusted to operate at 0.34MPa｛3.5kgf／cm ｝ and the others for PT-40D, 40DM(W), 60D, 60DM(W), 80D and 80DM(W) have been adjusted to operate at 0.18MPa｛1.9kgf／cm...
- Page 13 ３）When you need an inner container, order it. But a common 18 liter drum can be used as an inner container for ＰＴ－６０Ｄ、６０ＤＭ(W)、８０D and ８０ＤＭ(W). In that case, change position so that turbulent plate is inside tank. ４）Replenish paint through paint inlet. As ＰＴ－１０Ｄ(W)、１０ＤＭ(W)、２０Ｄ(W) and ２０ＤＭ(W) are not equipped with paint inlet, remove lid and replenish paint.
- Page 14 ■８.Problems and remedies Ask the distributor or the shop who sold it to you about ☆ marked items. If they are not done properly, it can cause poor performance. Problems Causes Research Remedies ①Pressure does not ① Air cock is open. ①Open exhaust valve and ①...
- Page 15 Problems Causes Research Remedies ⑤Pressure rises even ①Damage to valve set ①Remove rear lid, valve ① Replace valve set.☆ of air regulator. if handle of air set and check. regulator is loosened. ②Dust is stuck between ②Remove dust. ②-ditto- valve set and seal. ⑥Air exhausts from ①Damage to tapered ①Replace diaphragm bolt...
- Page 16 ■９. Parts list 9-1. Paint tank（PT-10D(W)・20D(W)） Lid set of Ｎｏ．１ includes １－１～１－１６ ※marked parts are consumable parts. quantity quantity Ｎｏ． Ｎｏ． part name part name 10DW 20D 20DW 10DW 20DW lid set reducing tee １ handle lid set exhaust valve body...
- Page 17 ９－２. Paint tank（ＰＴ－４０Ｄ・６０Ｄ・８０Ｄ） Lid set of Ｎｏ．１ includes １－１～１－１５ ※Marked parts are consumable parts. quantity quantity Ｎｏ． Ｎｏ． part name part name PT-40D PT-60D PT-80D PT-40D PT-60D PT-80D １ lid set １ １ １ paint inlet packing １ １ １ handle lid set １...
- Page 18 ９－３. Paint tank （ＰＴ－１０ＤＭ（Ｗ）・２０ＤＭ（Ｗ）） Lid set of Ｎｏ．１ includes １－１～１－２４ - 16 -...
- Page 19 Ｎｏ．１ lid set includes １－１～１－２４. ※marked parts are consumable parts. quantity quantity Ｎｏ． Ｎｏ． part name part name １ lid set safety valve handle lid set reducing tee air motor exhaust valve body muffler － － exhaust valve bar set washer and bolt ass’y －...
- Page 20 ９－４. Paint tank （ＰＴ－４０ＤＭ（Ｗ）・６０ＤＭ（Ｗ）・８０ＤＭ（Ｗ）） Lid set of Ｎｏ．１ includes １－１～１－２５. - 18 -...
- Page 21 Ｎｏ．１ lid set includes１－１～１－２５. ※marked parts are consumable parts. quantity quantity Ｎｏ． part name Ｎｏ． part name PT-40 PT-60 PT-80 PT-40 PT-60 PT-80 DM(W) DM(W) DM(W) DM(W) DM(W) DM(W) １ １ １ １ １ １ lid set paint inlet １ １...
- Page 22 〒223-8501 横浜市港北区新吉田町 3176 3176,Shinyoshida-Cho, Kohoku-Ku, Yokohama 223-8501, Japan No.9712-4 コード No.04199202...
- Page 23 ご使用前の 対 象 形 式 P T - 1 0 D ・ 1 0 D M P T - 2 0 D ・ 2 0 D M 注意 P T - 4 0 D ・ 4 0 D M P T - 6 0 D ・ 6 0 D M P T - 8 0 D ・...
