- Page 1 O&M Manual Revision 1.0 Manual Barrier Made in...
-
Page 2: Table Of Contents
Index 1. Inductions and warnings Page 03 2. Delivery, Movement and transport Page 04 3. Lifting plan Page 05 4. General Layout Page 06 5. Foundations Page 07 6. Installation Page 08 7. Operation/Control Page 09 8. Maintenance Page 10 9. -
Page 3: Inductions And Warnings
Introduction and Warnings This equipment is part of a large range of traffic flow products. They are designed to be easy to install, as all settings have been adjusted in our factory. Any of the instructions in this manual should only be followed by a qualified service engineer or a competent person. -
Page 4: Delivery, Movement And Transport
Delivery,Movement& Transportation This article describes how your equipment will be delivered to you, specifications on the transportation used and advice including health & safety on movement of the equipment. The manufacturer will use a qualified transport company to deliver the product conforming to the necessary regulations as detailed below: ? All drivers are qualified ? All drivers are tested once yearly ( If applicable ) -
Page 5: Lifting Plan
Lifting and Handling WARNING Always take safety precautions when lifting and handling heavy objects, in accordance with Manual Handling Operation Regulations 1992. Always wear correct safety equipment in the vicinity of equipment being off loaded. It is important to use the correct nylon slings with a SWL of 2 tonne for each sling. HANDLING For delivery, manual barriers are always delivered with the boom removed, and the pedestal supplied with the balance weight arm locked in the upright position for maximum stability... -
Page 6: General Layout
General Layout Shown below is a layout of a typical D1500 barrier,... -
Page 7: Foundations
Foundations All foundations should be installed as per drawing supplied as base sizes will vary depending on the size of the barrier. (Contact your supplier if you have not been issued one.) All foundations should be installed 10 x days prior to the gates being installed. If details of the base have not been specified, we recommend a concrete mix to BS EN 206-1:2000 “Concrete specification, Performance, Production and Conformity”... -
Page 8: Installation
Installation It is preferable that installation takes place when expected through traffic is at a minimum. Position the barrier pedestal, still in its vertical position, onto its prepared concrete base. The locking pin should be at the rear and the stop bracket at the front (facing the road). Approximately align the pedestal, so that its centre line is in the position across the road where it is anticipated the pole will be when in the down position. -
Page 9: Operation/Control
Adjustments and Operation Making Adjustments. Before despatch; the balance weights are pre-set to balance the pole as supplied and therefore, should require no further adjustment. However, should it be necessary to shorten the pole from the length supplied due to unforeseen circumstances, it may be necessary to adjust the balance weights accordingly. -
Page 10: Maintenance
Remove cordoned off area. ii. Depart the site leaving the area clean and tidy. The only moving component on a D1500 Manual Rising Arm Barrier is the pivot shaft and bearings. The bearings are “Sealed for Life” Plummer Blocks however, it is recommended that routine maintenance is carried out throughout the life of the equipment to inspect the Pivot Shaft, Bearings and other components e.g. -
Page 11: Changing A Pole Arm Adaptor
Changing a pole arm adaptor Pole arm adaptor change. To Change a pole arm adaptor follow the below steps, 1, Make sure the barrier shaft/balance weight is in the upright position and the slide lock lock in place 2, Now remove the existing adaptor using a 19mm spanner to remove the 3 x M12 bolts as indicated below. -
Page 12: Service Log
Service log This Manual must be completed in accordance with the guidelines below, at any point service/repair work is carried out on the product. This is to achieve two things; 1. To keep a history of the product for yourself and your supplier/manufacturer. 2. -
Page 13: Technical Data
Technical data Specification Maximum Span St 7.0 Metres HD 9.0 Metres Boom diameter Std 76mm HD 100mm Finish Polyester powdercoated Dimensions 250mm Square box 400 x 400 Base plate Pole height - 1metre from Base plate to centre. Total barrier height - 1150mm Optional extras Bottom skirt...
