Summary of Contents for Pioneer Athletics STARLINER V-5
- Page 1 Featuring Pioneer’s Exclusive “Plug & Stripe” Technology INSTRUCTION MANUAL & PARTS LISTING STARLINER V-5 800-877-1500 www.pioneerathletics.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS THE STARLINER ™ Before You Use Your Striper ....... . 1-3 Charging and Battery Operations . -
Page 3: Before You Use Your Striper
Congratulations on the purchase of your new StarLiner. Inside the box, you will find: • StarLiner Electric Striping Machine • Battery • Side Spray Box with Hose • Water/Flush Bottle • PHD Ultra-Friendly Cleaner • Envelope Containing: • Clean-out Hose •... - Page 4 Step Two Handle Setup Loosen the wing nuts located at mid-handle. Remove the lower wing nuts and bolts from StarLiner frame. Straighten the handle and tighten the mid-handle wing nuts. Align the lower bolt holes on the handle and frame. Reattach the bolts and wing nuts.
- Page 5 Step Four Paint line connection Connect the spray box paint line by pushing the white quick-connect onto the male connector on the front of the StarLiner. You will hear an audible click when a positive connection is made. Be sure the paint hose does not interfere with or become pinched by the tire or any moving parts.
- Page 6 You are now ready to test the operation of your StarLiner. We recommend trying the StarLiner with water before using paint. Connect the clean-out hose to the quick connect on the StarLiner. You will hear an audible click when the hose is connected properly. After connecting, place the clean-out hose in the bottle filled with water.
-
Page 7: Parts List & Parts Explosion Drawings
PARTS LIST - STARLINER (Model V-5) ITEM PART DESCRIPTION ITEM PART DESCRIPTION 1000 Switch (Handlebar) 1035 Slide Arm Assembly 1003 Wheel 1040 Hose Panel to Spray Box (32”) Circuit Board 1029 Panel Mount Connector 1025 Switch - High / Low 1018 Hose Container to Pump (14”) 1005... - Page 8 PARTS LIST - STARLINER (Model V-5)
-
Page 9: Cleaning
Cleanout of the StarLiner The StarLiner is shipped with a clean-out hose, an empty water bottle, and a quart of PHD Ultra-Friendly cleaner. Use the empty water bottle to combine water and a few ounces of PHD Ultra-Friendly to make the cleanout solution. Once you are finished striping, it is recommended that you flush the StarLiner free of paint. -
Page 10: Striping Tips
Striping Tips • When striping, it is recommended to have the StarLiner in motion before turning it on. This will eliminate the possibility of having a large “blob” of paint on the grass at the beginning of your line. • Always test in an off area to be sure you are familiar with all functions of the StarLiner. -
Page 11: Trouble Shooting The Starliner
Troubleshooting If the StarLiner will not start: • Make sure the battery is charged. • Check the fuse. • Make sure the tip is not clogged. The spray pattern is too narrow or wide: • Adjust nozzle assembly up or down. •... - Page 12 High/Low Switch The only issue is if the battery comes loose and slides over, hitting and breaking the switch. Fuse There are several ways the fuse can blow, including: • The wires are attached in reverse. This means that the fuse wire is attached to the black terminal on the battery.
-
Page 13: Limited Warranty
LIMITED WARRANTY For a period of six months from date of purchase, PIONEER MANUFACTURING COMPANY will replace for the original PURCHASERS, any part or parts* of the Star- Liner, found upon examination by a PIONEER FACTORY-trained representative, to be defective in material or workmanship or both; this is the exclusive remedy. This warranty is pro-rated as to cover 100% of the cost of materials, parts and labor for the first six months.The customer is responsible for all remaining costs. - Page 14 FOR REPAIRS INCLUDING WARRANTY REPAIRS: Call 800-877-1500 for repair cost estimates, and full service information. INCLUDE RETURN AUTHORIZATION CODE NUMBER BEFORE SENDING YOUR UNIT. SEND YOUR UNIT WITH FREIGHT PREPAID TO: PIONEER ATHLETICS 4529 Industrial Parkway Cleveland, Ohio 44135...
- Page 15 DATE PURCHASED: SALES REPRESENTATIVE: PREFERRED NOZZLE TIP: NOTES:...
- Page 16 ATHLETIC FIELD MARKING PAINT Featuring “Plug & Stripe” Technology Features: • Ready-to-use paint comes in a self-sealing container. Just “Plug paint container into paint line and “Stripe” away • Brilliant white lines featuring Pioneerʼs Halogen 2000 Optical Brighteners ® • Stackable container size makes for easy storage and striping Coverage (undiluted): up to 2000 linear feet of four...
