BE Ag & Industrial SW42T Operations & Parts Manual

Tow behind lawn sweeper
Hide thumbs

Advertisement

Table of Contents

TOW BEHIND LAWN
SWEEPER MANUAL
SW42T
OPERATIONS & PARTS MANUAL
FOR MODELS:
• SW42T
PURCHASE DATE
MODEL NO.
SERIAL NUMBER
DEALER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW42T and is the answer not in the manual?

Questions and answers

Summary of Contents for BE Ag & Industrial SW42T

  • Page 1 TOW BEHIND LAWN SWEEPER MANUAL SW42T OPERATIONS & PARTS MANUAL FOR MODELS: • SW42T PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS GENERAL WARNINGS CONTROLS & FEATURES IDENTIFICATION ASSEMBLY INSTRUCTIONS OPERATION INSTRUCTIONS MAINTENANCE AND STORAGE PARTS BREAKDOWN & SPECIFICATIONS SW42T USER MANUAL...

  • Page 3: General Warnings

    This product requires assembly before use. See “Assembly” section for instructions. Because of the weight and/or size of the lawn sweeper, it is recommended that another adult be present to assist with the assembly. INSPECT ALL COMPONENTS closely upon receipt to make sure no components are missing or damaged. SW42T USER MANUAL...
  • Page 4 The tow-behind sweeper features a one-handed lever to adjust the brush height. It can be stored in a shed or garage with minimal space. The large hopper makes loading and unloading fast and convenient. Technical specifications on the lawn sweeper are provided in the “Specifications” section of this manual. SW42T USER MANUAL...

  • Page 5: Controls & Features Identification

    1. Hand Lever - Adjust the Brush Height. 2. Nylon Hopper - Holds all types of Debris. 3. Tires / Wheel - Semi pneumatic all terrain tires 4. Hitch - Pin-type design used only with approved vehicles. SW42T USER MANUAL...
  • Page 6 R Pin Ø4 Hex Bolt - M8x16 Clevis Pin Ø9.5x25 Nylon Lock Nut - M8 Clevis Pin Øx37 Nylon Lock Nut - M6 Clevis Pin Ø8x59.5 Hex Bolt - M6x12 Hitch Big Flat Washer - Ø8 Plastic Plug SW42T USER MANUAL...
  • Page 7 Lower hopper Side Tube Hex Bolt - M6x40 Rear Hopper Tube Hex Bolt - M8x20 Upper Hopper Side Tube Hex Bolt - M8x16 Rope Nylon Lock Nut - M8 Hex Bolt - M6x12 Nylon Lock Nut - M6 SW42T USER MANUAL...

  • Page 8: Assembly Instructions

    Note: Right Hand (RH) and Left Hand (LH) are determined from the operator’s position while seated on the vehicle. Step 2: 1. Assemble the RH hitch tube to the sweeper housing using M6x40 hex bolt and M6 lock nut. Only loosely tighten. 2. Repeat for the LH hitch tube. Loosely tighten. SW42T USER MANUAL...
  • Page 9 NOTE: if your vehicles hitch has 11 in. to 13 in. ground clearance use the other bracket (figure A). If your vehicles hitch has 8 in. to 11 in ground clearance use the other hitch bracket (figure B). SW42T USER MANUAL...
  • Page 10 1. Position the rear hopper so the brace holes are in the middle and the tube is facing down. 2. Slide the tube through the two sewn in loops at the top of the rear seam inside the bag. SW42T USER MANUAL...
  • Page 11 7. Place the lower hopper tube assembly in the bottom of the bag. 8. Attach the ends of the lower side tubes inside the upper side tubes using two Ø9.5x25 clevis pins. 9. From the inside of the bag insert the two hair cotter pins Ø3. SW42T USER MANUAL...
  • Page 12 13. Tip the hopper on its back to insert the two hopper support rods. 14. Place the ends of each rod into the upper and lower rear hopper tubes bending the rod just enough to fit into the holes in the tubes. SW42T USER MANUAL...
  • Page 13 16. Insert a Ø8x59.5 clevis pin through the lower hole in each of the upper hopper side tubes. 17. Attach a bag arm tube onto each clevis pin and secure it with a hair cotter pin Ø3. 18. Secure the rope to the top center of the hopper bag frame. SW42T USER MANUAL...

  • Page 14: Operation Instructions

    3. Attach the sweeper to the vehicle hitch using the spacers to make the bottom of the sweeper bag as level as possible with the ground. Note: For the best performance the bottom of the sweeper bag needs to be level with the ground with at least a 5” clearance. SW42T USER MANUAL...

  • Page 15: Maintenance And Storage

    Also, the wheels should be removed too clean gears every two years. After cleaning apply an even coat of light synthetic grease. SW42T USER MANUAL...
  • Page 16 • Collapse the hopper bag for storage, remove the two support rods from the rear of the hopper. • Lightly lubricate all sweeper surfaces and moving and moving parts to prevent rust. • Store indoors or protected area during severe weather and winter months. SW42T USER MANUAL...
  • Page 17 PARTS BREAKDOWN SPECIFICATIONS SP31105 SP3108 Frame Construction Steel Hopper Construction Nylon Mesh Hitch Type Pin Style Wheel Type Semi-Pneumatic Working Width 38” 42” Wheel Size 10” 10.5” SW42T USER MANUAL...
  • Page 18 Hitch Bracket Cotter Bearing Hitch Bracket (Straight) R Pin Ø3 Hitch Tube (L.H.) R Pin Ø2 Big Flat Washer (Ø10) Big Flat Washer Hex Bolt M10x85 Hex Bolt M8x20 Nylon Lock Nut M5 Slotted Pan Head Screw M5x16 SW42T USER MANUAL...
  • Page 19 SW42T USER MANUAL...
  • Page 20 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 SW42T USER MANUAL...
