DO NOT DISCARD INSTRUCTIONS. THIS MANUAL MUST REMAIN WITH THE UNIT FOR FUTURE REFERENCE.
THIS EMERGENCY INFORMATION MUST BE PROMINENTLY DISPLAYED.
SECTION 1– INSTALLATION INSTRUCTIONS
When sold in the Commonwealth of Massachusetts this unit must be equipped with an interlock
to prevent operation, only if the hood system is operational. Installation of the interlock is the
responsibility of the installer—it is not supplied by the factory.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
FOR YOUR SAFETY
Do not store or use gasoline, or other flammable vapors, and liquids, in the vicinity of this, or any other appliance.
IMPORTANT
Contact your local gas supplier for instructions, if you smell gas near this equipment.
© Town Food Service Equipment Company, Inc. No part of this booklet, or it 's illustrations, may be copied, or reproduced, without written authorization from Town Food Service Equipment Co., Inc.
Scan the QR code to
watch the Town Wok Range Video
on townfood.com!
TOWN WOK RANGE OWNER'S MANUAL
FOR COMMERCIAL USE ONLY
Wok Range Manual|rev 05.22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoDeck and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Town Food Service Equipment EcoDeck

Summary of Contents for Town Food Service Equipment EcoDeck

  • Page 1: Section 1- Installation Instructions

    Contact your local gas supplier for instructions, if you smell gas near this equipment. © Town Food Service Equipment Company, Inc. No part of this booklet, or it ’s illustrations, may be copied, or reproduced, without written authorization from Town Food Service Equipment Co., Inc.
  • Page 2 YORK AND MASTERRANGE PARTS IDENTIFICATION _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ A REMOVABLE FLUE RISER CAP H CANTONESE CHAMBER RING B BACKSPLASH PLATE SHELF C SWING FAUCET WATER-WASH CONTROL VALVE D 3-PIPE WOK COVER/STRAINER RACK K DRIP TRAY MANUAL FAUCET PILOT LIGHT CONTROL VALVE M KNEE-OPERATED GAS VALVES SIDESPLASH G MANDARIN CHAMBER RING...
  • Page 3 ECODECK PARTS IDENTIFICATION _________________________________________________________________________________ _________________________________________________________________________________ G CANTONESE CHAMBER RING BACKSPLASH SWING FAUCET AUTOMATIC, TIMED-CYCLE DECK WASH 3-PIPE WOK COVER/STRAINER RACK FLOW-CONTROL MANUAL FAUCET PLATE SHELF SIDESPLASH FRONT ACCESS SINK (WASTE) BASKET MANDARIN CHAMBER RING KNEE-OPERATED GAS VALVES NEW PRODUCT...
  • Page 4 CONGRATULATIONS ON YOUR PURCHASE OF AN ECODECK, YORK OR MASTERRANGE WOK RANGE It will give you many years of trouble-free use, if it is properly used and maintained. Please call our customer service department at 718/388-5650 if you have questions regarding equipment operation, or care.
  • Page 5 • Minimum spacing of 6 to combustible construction is required, along back and side walls. Clearances for ” non-combustible construction are the same as combustible clearances. For use only on non-combustible floors. • Materials such as wood, compressed paper and plant fibers, that will ignite and burn, must not be exposed near range, especially at rear.
  • Page 6 UNITS WITHOUT SAFETY VALVES LIGHTING AND SHUTDOWN INSTRUCTIONS Be sure that all piping is gas tight, and that all air is purged from lines. With main burner valve in off position (figure 3), using a screwdriver, turn pilot screw counter-clockwise to on (figure 2) and light pilot, located in the combustion chamber.
  • Page 7 BACKSPLASH REMOVAL AND REINSTALLATION _________________________________________________________________________________ _________________________________________________________________________________ gutter gutter faucet manifold figure 2 figure 3 figure 1 figure 6 figure 4 figure 5 backsplash “ J ” gutter “ J ” figure 8 figure 7 Some installations require the backsplash to be removed, so the range can fit through a 34” door. Town ranges are manufactured with removable backsplashes.
  • Page 8 FLUE RISER EXTENSION INSTALLATION _________________________________________________________________________________ _________________________________________________________________________________ Ranges, with optional Flue Risers, have stainless steel extensions that cover the tops of the flue risers. Locate the parts in the boxed marked “ RANGE ACCESSORIES ” . 1) Take assembled flue collar and turn with kink to rear (figure A). 2) Place flue collar on top of chimney extension, as illustrated (figure B).
  • Page 9 4) Install the stainless tubular wok cover rack. Male and female ends mate to become a continuous length. Remove the bolts from the brackets, and install the tubing, with threaded ends. Use the bolts removed from the brackets at the endsplashes. (figures 5, 6 and 7). 5) The range position may have to be adjusted to align the bolt holes, in the serving shelf, with the figure 6...
  • Page 10 SPLICE FIELD JOINT INSTALLATION INSTRUCTIONS SPLICE FIELD JOINT INSTALLATION INSTRUCTIONS _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ Range decks have a “tongue and groove,” so there is no standing seam between range decks. The decks and backsplashes are joined. The gutters are separate, but interlock. 1) Uncrate the ranges and place them on pallet jacks.
  • Page 11 figure 4 figure 7 figure 5 figure 8 figure 6 figure 9...

  • Page 12: Section 2 - Operation And Maintenance

    Contact your local gas supplier for instructions, if you smell gas near this equipment. © Town Food Service Equipment Company, Inc. No part of this booklet, or it ‘s illustrations, may be copied, or reproduced, without written authorization from Town Food Service Equipment Co., Inc.
  • Page 13 UNITS WITHOUT SAFETY VALVES LIGHTING AND SHUT DOWN INSTRUCTIONS Be sure that all piping is gas-tight, and that all air is purged from lines. With main burner valve in off position (figure 3), using a screwdriver, turn pilot screw counter-clockwise to on (figure 2) and light pilot, located in the combustion chamber.
  • Page 14 MAINTENANCE AND CARE _________________________________________________________________________________ _________________________________________________________________________________ If equipment requires service, contact your authorized gas service company to perform necessary repairs. Check the flue riser monthly, to be sure it is free of obstructions. Be sure to clean the air mixers, and orifices, of ring burners once per year.
  • Page 15 RANGE PARTS _________________________________________________________________________________ _________________________________________________________________________________ ECODECK/YORK REPLACEMENT FIBER CERAMICS number fits chamber interior dimension 225014N __ 13” _________ 11” (6 lbs.) 225016N __ 16” _________ 14” (7 lbs.) 225118N __ 18” _________ 16” (8 lbs.) 225020N __ 20” _________ 18” (9 lbs.) 225022N __ 22”...
  • Page 16 BURNERS AND PARTS _________________________________________________________________________________ _________________________________________________________________________________ ” PILOT INCLUDED WITH BURNER. BELOW BURNERS ARE NPT INLET. 16-TIP VOLCANO BURNERS number description 226917 226916N ____ 16-tip volcano, natural (12 lbs.) 226916P _____ 16-tip volcano, propane (12 lbs.) 226917 ______ replacement tip, natural gas 226918 ______ replacement tip, propane gas 226916C _____ replacement cover (4 lbs.) 226916N-...
  • Page 17 BURNERS AND PARTS _________________________________________________________________________________ _________________________________________________________________________________ AIR MIXER PARTS 226526 226119 FOR 2- AND 3-RING BURNERS number description 226110 _______ air mixer assembly, natural 226111 _______ air mixer assembly, propane 226117 _______ air mixer orifice, natural 226115 226609 226119 _______ air mixer orifice, propane 226115 _______ air mixer set screw AIR MIXER ASSEMBLY 226609 _______...

  • Page 18: Replacement Parts

    REPLACEMENT PARTS _________________________________________________________________________________ _________________________________________________________________________________ Autoflo™...the Original Swing Faucet. Beware of imitations! One-piece, cast brass body, with heat-proof internal parts, lets our faucet outlast all others. Look for “AutoFlo™” stamped on the faucet. number description 228800 ____ swing faucet, 11½” ” 228900 ____ wing faucet, 14”...
  • Page 19 SEE MORE PRODUCT VIDEOS ON TOWNFOOD.COM!

  • Page 20: Limited Warranty

    LIMITED WARRANTY Town warrants all wok ranges free from defects of workmanship, or material, for one (1) year from invoice date, with the exception of safety-pilot systems, which are covered by a 90-day warranty. Safety-pilot systems, installed without drip legs, are not covered by this warranty. Defective parts, returned prepaid, will be repaired or replaced, subject to our inspection, and returned freight collect.

This manual is also suitable for:

MasterrangeYork
