OPERATION MANUAL
OPERATION MANUAL
MITSUBISHI TRANSPORT REFRIGERATION UNIT
TFV2000DM-E
PEGASUS
MULTI TEMP
This operation manual is
intended to provide users
with a good knowledge to
use Mitsubishi Refrigeration
Unit safely.
Operate or service the
refrigeration unit only after
you have read this manual
and understand its
contents.
Carefully store this manual
in a xed place so that it is
immediately available for
your reference when you
need it.
TSJ012A193A
YEAR:2016
