Summary of Contents for Alpha Technologies Continuity 1000 Series
- Page 1 Alpha Continuity Battery Pack User Manual Document #: 0320004-J0 Effective 02/2011...
- Page 3 This document, the software it describes, and the information and know-how they contain constitute the proprietary, confidential and valuable trade secret information of Alpha Technologies, and may not be used for any unauthorized purpose, or disclosed to others without the prior written permission of Alpha Technologies.
-
Page 4: Table Of Contents
Contents 1. Important Safety Instructions ...................... 1 2. Overview of the Front and Rear Panel .................... 3 2.1. Front and Rear Panel Descriptions .................... 3 3. Installation and Operation ........................ 4 3.1. Unpacking ............................. 4 3.2. Selecting an Installation Position .................... 5 3.2.1. Tower Installation – Standalone Unit .................. 6 3.2.2. Tower Installation – Combined with UPS ................ 7 3.2.3. Rack Mount installation ....................... 8 3.2.4. Connect DC Cable ......................... 10 3.2.5. Storage Instruction ....................... 11 3.2.6. Replacing the Battery ...................... 11 3.3. Specification .......................... 12 3.4. Recycling Used Batteries ...................... 12 ... -
Page 5: Important Safety Instructions
Important Safety Instructions Save These Instructions This section contains important instructions that must be followed during the installation and maintenance of the equipment and batteries. Read all of the instructions before operating the equipment, and save this manual for future reference. - Page 6 This battery pack is intended to be connected to an UPS. There will be a DC voltage at the connector terminals. Do not try to repair the unit yourself, contact your local supplier or your warranty will be void. ...
-
Page 7: Overview Of The Front And Rear Panel
Overview of the Front and Rear Panel 2.1. Front and Rear Panel Descriptions Screw Cover To replace batteries, remove the front covers and the screws inside the covers. EXT.BAT. +/- To the DC terminal of the second (or next) connected battery pack. UPS BAT. -
Page 8: Installation And Operation
Installation and Operation Note: The packing condition and the external outlook of the unit should be inspected carefully before installation. Retain the packing material for future use. 3.1. Unpacking 1. Take the battery pack out of the foam. 2. Remove the packing materials. WARNING: The battery pack module is approximately 32 to 36 kgs (70 to 80 lbs); be cautious when unpacking and ... -
Page 9: Selecting An Installation Position
3.2. Selecting an Installation Position The battery cable is provided with an 8 inch cable. Plan to install the battery pack within 3 to 4 inches from the UPS or another battery pack. It is necessary to select a proper environment to install the unit, in order to minimize the possibility of damage to the battery pack and extend the life of the batteries. -
Page 10: Tower Installation - Standalone Unit
3.2.1. Tower Installation – Standalone Unit STEP 1 STEP 2 0320004‐J0 Rev A Page 6 ... -
Page 11: Tower Installation - Combined With Ups
3.2.2. Tower Installation – Combined with UPS STEP 1 STEP 2 0320004‐J0 Rev A Page 7 ... -
Page 12: 3.2.3. Rack Mount Installation
3.2.3. Rack Mount installation STEP 1 STEP 2 0320004‐J0 Rev A Page 8 ... - Page 13 STEP 3 STEP 4 0320004‐J0 Rev A Page 9 ...
-
Page 14: Connect Dc Cable
3.2.4. Connect DC Cable Second Battery pack First Battery pack UPS 0320004‐J0 Rev A Page 10 ... -
Page 15: Storage Instruction
3.2.5. Storage Instruction For extended storage in a moderate climate (-5 to +30 °C / 23 to +86 °F), the batteries should be charged for 12 hours every 6 months by plugging in to a UPS. Repeat this every 3 months at higher temperatures (+30 to +45 °C / +86 to +113 °F). -
Page 16: Specification
3.3. Specification UPS 1000VA 2000 VA 3000 VA Battery Pack Model BBC-AIDCO-1000 BBC-AIDCO-2000 BBC-AIDCO-3000 Part Number 0320004-001 0320005-001 0320006-001 Nominal System 36VDC 72VDC Voltage +(Red) +(Red) G(Green) DC Sockets Diagram G(Green) -(Black) -(Black) DC Plug Diagram Dimensions W x D x H, mm Unit 440 x 650 x 88 Shipping... - Page 20 Fax: +55 11 2476 0150 Fax: +370 5 210 5292 Fax: +852 2199 7988 Due to continuing product development, Alpha Technologies reserves the right to change specifications without notice. Copyright ©2011 Alpha Technologies. All rights reserved. Alpha® is a registered trademark of Alpha Technologies.
