- Page 1 OPERATING MANUAL Wall-mounted and channel penstocks Cat. no. 2801 and 2802 OPERATING MANUAL 02-2024...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTENDED USE ............................3 TECHNICAL DESCRIPTION ........................3 PRODUCT IDENTIFICATION MARKING .................... 3 STORAGE AND TRANSPORT ......................... 4 INSTALLATION ............................4 OPERATION AND MAINTENANCE ....................... 5 SAFETY ................................ 5 WARRANTY ..............................6 OPERATING MANUAL 02-2024... -
Page 3: Intended Use
Installation length: see JAFAR technical files, The structure of 2801 wall-mounted penstock and the 2802 channel penstock is built of rigid and durable stainless steel. The product is fullway, without any dead zones. The disc is moved by a single or double spindle screw mechanism, ... -
Page 4: Storage And Transport
4. STORAGE AND TRANSPORT Products are packed on EURO pallets (1200x800) or on special pallets for oversized products. Penstocks should be stored in clean rooms free from bacteriological or chemical contaminants, at a room temperature between -20 and 70°C. Protect the rubber parts from prolonged exposure to UV radiation. Store the elements ensuring protection against mechanical damage. -
Page 5: Operation And Maintenance
Operating Manual may cause death, severe bodily injury or substantial property damage. Fabryka Armatur Jafar S.A. shall not be liable for any accidents or emergencies related to incorrect installation or operation of the product. Note that the valve installation could be pressurized or contain various type of stray gas or aggressive liquids. -
Page 6: Warranty
The product assembled, installed and operated in conformity with this Operating Manual and the data sheet is covered by a guarantee from the manufacturer. The warranty terms, conditions and period are specified in the Warranty Certificate available from www.jafar.com.pl. The manufacturer may provide this product with custom materials and modifications on order. The final selection...
