TI-95
Tire Inspector
Air Operated Unit
buyTSI.com - 800.223.4540
READ INSTRUCTIONS THOROUGHLY BEFORE OPERATING
Tire Service International, LLC
Contact us for any assistance
3451 S. 40TH ST.
Phoenix, AZ 85040
800.223.4540
Office: 602.437.5020
Email: sales@buytsi.com
Fax: 602.437.5025
Revised: March 2024
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TSI Instruments Tire Inspector TI-95
Summary of Contents for TSI Instruments Tire Inspector TI-95
- Page 1 TI-95 Tire Inspector Air Operated Unit buyTSI.com - 800.223.4540 READ INSTRUCTIONS THOROUGHLY BEFORE OPERATING Tire Service International, LLC Contact us for any assistance 3451 S. 40TH ST. Phoenix, AZ 85040 800.223.4540 Office: 602.437.5020 Email: sales@buytsi.com Fax: 602.437.5025 Revised: March 2024...
-
Page 2: General Description
General Description The Tl-95 Tire Inspector is designed to inspect non-mounted tires from 13” to 24.5” in rim diameter using expanding rims sold separately. The Tl-95 allows the operator to inspect tires for sidewall, tread and bead leakage on non- mounted tires. -
Page 3: Main Components
Main Components Expanding Rim Storage Rack Expanding Hub Knob for tire to inflate and deflate Inspect tire sizes ranging from 13” through 24.5’’ with seven different Expanding Rims (Sold separately) Knob for expanding hub to inflate and deflate Valve and gauge to control air in tire Air inlet Valve and gauge... - Page 4 Operating Instruction Connect air supply to 1/4” hose fitting. All pressures are pre-set for 30 PSI for Tire Pressure and 80 PSI for Expanding Hub and Rim. Select the correct size Expansion Rim and mount onto Expansion Hub. Clean both Tire Bead inside diameter flanges. Use an oil soap on the Expanding Rim Belt to assist tire to slide into position.
-
Page 5: Maintenance
Maintenance The TSI Hub assembly is designed and manufactured for long-term trouble-free operation. It is a time and labor saving unit that will deliver many years of service if a reasonable cleaning and maintenance schedule is practiced. Caution: Before performing any disassembly disconnect air supply to machine. Disconnect air hoses connected to the air swivel assembly. -
Page 6: Scheduled Maintenance
Scheduled Maintenance Daily Lube belt with oil soap tire lube as needed Check the four expandable rim locks to ensure they are in the locked position Look inside the hub to see the locking tab is engaged Weekly In addition to the daily maintenance the following maintenance is recommended weekly. Detach 2 Air Supply Hoses and remove expandable rim Remove paddles Clean out the paddle slots using air pressure... -
Page 7: Repair Parts List
Repair Parts List Item Description 10676 In-Line Water Extractor 11554-160 Gauge, 2” x 160 PSI x 1/4 NPT 11554-60 Gauge, 2” x 60 PSI x 1/4 NPT 15.190 Regulator - Air PSI 125 MAX 252.190 Valve Mini Push Pull 4885 Paddle, plain Expandable Hub 4900 Cylinder, Exp Hub Assy. -
Page 8: California Proposition 65
California Proposition 65 California’s Proposition 65 entitles California consumers to special warnings for products that contain chemicals known to the state of California to cause cancer and birth defects or other reproductive harm if those products expose consumers to such chemicals above certain threshold levels. WARNING: Some of Tire Service International’s products can expose you to chemicals including chromium compounds, which are known to the State of California to cause cancer, birth defects or other reproductive harm.
