DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance,
please register your appliance on:
www.hotpoint.eu/register
Before using the appliance carefully read Safety Instructions.
PRODUCT DESCRIPTION
APPLIANCE
1
2
4
5
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1.
On-Off/Reset button with indicator light
2.
Tablet (Tab) button with indicator light
3.
Salt refill indicator light
4.
Rinse Aid refill indicator light
3
6
7
8
10
1
2
3
4
You can download the Safety Instructions and the User
Manual, by visiting our website docs.hotpoint.eu
and following the Instructions on the back of this
booklet.
1.
Upper rack
2.
Foldable flaps
3.
Upper rack height adjuster
4.
Upper spray arm
5.
Lower rack
6.
Cutlery basket
7.
Lower spray arm
8.
Filter Assembly
9.
Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
6
7
5
5.
Program selection knob
6.
Delay indicator light
7.
Delay button with indicator light
8.
Start/Pause button with indicator light / Drain out
8
EN
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint HSFE 1B19 B UK N
Summary of Contents for Hotpoint HSFE 1B19 B UK N
- Page 1 DAILY REFERENCE GUIDE THANK YOU FOR BUYING A HOTPOINT PRODUCT. You can download the Safety Instructions and the User In order to receive a more complete assistance, Manual, by visiting our website docs.hotpoint.eu please register your appliance on: and following the Instructions on the back of this www.hotpoint.eu/register...
- Page 2 FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER Rinse aid makes dish DRYING easier. The rinse aid dispenser A should After installation, remove the stoppers from the racks and the retaining be filled when the RINSE AID REFILL indicator light in the control elastic elements from the upper rack.
-
Page 3: Programs Table
PROGRAMS TABLE Duration Water Energy Available Program of wash program consumption consumption options (h:min) (litres/cycle) (kWh/cycle) 1 Eco 50° 4:00 11.5 0.84 2 Intensive 65° 2:30 15.0 1.50 3 Mixed 55° 2:25 15.0 1.35 4 Delicates 45° 1:30 11.0 1.00 5 Rapid 30’... - Page 4 OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED flashes rapidly 3 times. The option will not be enabled. DELAY TABLET (Tab) It is possible to delay the start time of the program by 2, 4...
-
Page 5: Loading The Racks
LOADING THE RACKS LOWER RACK UPPER RACK Load delicate and light dishes: glasses, cups, For pots, lids, plates, salad bowls, cutlery saucers, low salad bowls. etc... Large plates and lids should ideally be placed at the sides to avoid interferen- ces with the spray arm. -
Page 6: Daily Use
DAILY USE 1. CHECK WATER CONNECTION The machine will switch off automatically during certain extended periods of inactivity, in order to minimise electricity consumption. Check that the dishwasher is connected to the water supply and If the crockery is only lightly soiled or if it has been rinsed with that the tap is open. -
Page 7: Care And Maintenance
CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water. -
Page 8: Troubleshooting
Check water supply for leaks or other issues letting air inside. Policies, standard documentation, ordering of spare parts and additional product information can be found by: • Visiting our website: docs.hotpoint.eu and parts-selfservice.whirlpool.com • Using QR Code • Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
