BirdBike VA00066 User Manual

Please read this manual very carefully before using the product. The manual contains important instructions for the safe
use and longevity of your bike. If you need any type of support or warranty information for your Bird Bike, please contact
the local dealer or retailer where you purchased the product.
Install the display
For the final step before powering on your Bird Bike, reinstall the display back
into the handlebar so that the Bird logo is at the bottom. Be sure to not pinch
the cable inside of the handlebar while reinstalling. Once reinstalled, use
the 2.5mm Allen key to replace and tighten the screw under the display to a
maximum torque of 1.5 N.m (stop when you feel light resistance). Ensure the
display edges are flush with the handlebar before tightening the screw. If not
flush, remove display and ensure the cables are not pinched below the display.
Connect the one end of the power cable coming from the bottom of the
display to the other end of the power cable that is coming out of the bottom
of the frame. At this point you can power on your Bird Bike, but be sure to read
through the rest of this manual before riding.
Error Code Cause
0x13 or 0x32 Full battery
charge alert
0x14 or 0x31 Low battery
charge alert
0x15 High vehicle
temperature
0x16 Low vehicle
temperature
Model: VA00066/VA00071/VA00119 (Grey), VA00067/VA00072/VA00120 (White)
2.5 mm
Allen key
Solution
Regular function of the e-bike will not be interrupted. Discharge the battery by riding the e-bike to
clear error. If error 0x13 still appears after the battery is less than 100%, contact customer support or
your BirdBike retailer.
Regular function of the e-bike will not be interrupted. Charge the battery to eliminate.
Place vehicle in a cool environment. Wait until vehicle temperature is less than 45 degrees C. Error
0x15 will be cleared.
• Higher than 45 degrees C: error 0x15 triggered, but e-bike and battery function are regular.
• Higher than 50 degrees C: error 0x15 triggered, electric assist will function, cannot charge battery.
• Higher than 65 degrees C: error 0x15 triggered, electric assist will not function, cannot charge
battery.
Place vehicle in a temperate environment. Wait until vehicle temperature is greater than 5 degrees C.
Error 0x16 will be cleared.
• Less than 5 degrees C: error 0x16 triggered, but e-bike and battery function are regular.
• Less than 0 degrees C: error 0x16 triggered, electric assist will function, cannot charge battery.
• Less than -20 degrees C: error 0x16 triggered, electric assist will not function, cannot charge
battery.
V-Frame User Manual - Supplemental Information
Max torque
1.5 N.m
