J.W. Speaker 8690 Installation Instructions

INSTALLATION INSTRUCTIONS
To properly install this headlight you should have a good understanding of automotive electrical procedures and systems,
and proficiency in the installation of headlights. IF YOU DO NOT, PLEASE SEEK PROFESSIONAL ASSISTANCE.
BEFORE INSTALLATION:
Estimated Time: 60 minutes
Tools Needed: Adjustable Wrench
Wire Functions: Black = Ground
White = High Beam
Yellow = Low Beam
Red = Front
*Front position light is a requirement outside the
United States. If your bike is operated in the United
States you do not need to connect this wire unless
your bike is equipped with a front position light.
In the Box: (x1) Model 8690 Headlight
Input Voltage: 12V DC
Operative Voltage: 9-16V DC
REGULATORY COMPLIANCE:
PRODUCT WARRANTY:
If you have issues with a J.W. Speaker product, please
contact the authorized retailer where you purchased it.
6544360b Rev: 09/15/2016 J.W. Speaker Corporation Germantown, WI U.S.A. www.jwspeaker.com speaker@jwspeaker.com
Position*
PRE-INSTALLATION INSTRUCTIONS:
1. Read all safety notes and mounting guidelines before
installing the product. Verify that all parts listed under "In the
Box" are present and complete.
2. Inspect the product for damage. DO NOT install the product if
there is any damage. Contact the authorized retailer where you
purchased it to initiate a warranty claim if there is damage.
3. Verify that all power supply and/or charging systems comply
to the specified voltage limits for the light.
INSTALLATION INSTRUCTIONS:
1. Turn off the motorcycle and disconnect the battery.
2. Remove the existing headlight from the motorcycle. Be careful
not to damage the vehicle and keep all hardware that attaches
the headlight to the motorcycle.
3. Check condition of all wires, connectors, mating connectors,
or gaskets. All connections should be adequately protected
against moisture. Shrink tubing is recommended.
4. Lay and secure the wiring so that no pulling or abrasion can
occur. Proper installation requires there to be a little slack near
the lamp to avoid pulling on the connector (which can create a
path for water ingress). Wires should be adequately secured to
avoid damage.
5. Carefully connect the wires or connector using the "Wire
Functions" and "Voltage" information above.
equipped with Front Position you should; terminate, seal,
or electrical tape the wire end to prevent corrosion and/
or shorting.
6. Install the headlight with the existing hardware, making sure
the J.W. Speaker logo is legible/right-side up.
7. Aim the lights (continued on next page).
Model 8690
If the bike is not
© Copyright 2016
