Electric Powered Wheelbarrow
Operator's Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow
the safety rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when
required.Keep these instructions to assist in future servicing.
REV 05/20/24
Advertisement
Table of Contents
Summary of Contents for Redrock LBB04
- Page 1 Electric Powered Wheelbarrow Operator’s Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required.Keep these instructions to assist in future servicing.
-
Page 2: Specifications
No smoking, no naked flames, no sparks. instructions can cause serious injuries and even lead to death. Explosive gas. Corrosive (Battery acid). 1.SPECIFICATIONS Item No LBB04 Rating DC 24V/0.67HP/500W Load Capacity 150kg/330lbs Wheel Size 16 inch Battery Specification... - Page 3 3.SAFETY Intended Use The machine must only be used for its intended purpose! Any other use is deemed to be a case of misuse. To use the machine properly you must also observe and follow all safety regulations, the assembly instructions, operating and maintenance instructions lay down in this manual.
- Page 4 BATTERY: Improper use or the use of damaged batteries leaking vapors. Run to fresh air and seek medical attention in case of complaints. The vapors can irritate the respiratory tract. FIRE HAZARD! Never charge batteries near acids and flammable materials. Charge the battery only in an ambient temperature between 0°C to +40°C.
- Page 5 ASSEMBLY 1.Assemble the Base Frame ② Install the two handle connecting bend tubes (4) to ① Assemble left bend frame (2) and right bend frame left bend frame (2) and right bend frame (3) sepa- (3) to the front bend frame (1) according to the rately, align the hole sites and tighten them with 2 drawing, align the holes and fix the two positions pcs M8x40 bolt(A) and 2 pcs M8 nut (B).
- Page 6 ASSEMBLY 4. Assembly—Swivel wheel 5. Assembly—Lifting handle ① Assemble the two swivel wheels(8) onto the swivel ① Assemble the left lifting support bar(10) and right wheel bracket(7), align the hole sites and tighten lifting support bar(11) onto the lifting handle(9), the wheels with Mx40 bolt(A)and M8 nut(B).
- Page 7 ASSEMBLY 7. Assembly--Handle 8. Assembly—Battery box ① Align the bolt hole on back beam(18) with holes on ① Align the 4 holes on battery box(19) with the holes left handle(16) and right handle(17), then fix and on square tube(2) and swivel wheel bracket(7), fix tighten them with 4 pcs M6x40 bolt(I), 2 pcs wash- and tighten them with 4 pcs M8x45 bolt(L) and 4 er(K) 6 and 2pcs M6 nut(J).
-
Page 8: Operation
OPERATION Device to be operated in a perfect state only. Inspect the device visually every time it is to be used. Check in particular the safety equipment, electrical controls, electric cables and screwed connection for damage and if tightened properly. Replace any damaged parts before operating the device. 1.Operation Instructions Unplug battery before all maintenance and settings! Notice... -
Page 9: Maintenance
8. MAINTENANCE Unplug battery before all maintenance and settings! Serious injury due to unintentional or automatic activation of the machine! The machine does not require extensive maintenance. If malfunctions and defects occur, let it be Serviced by trained persons only. NOTICE Clean your machine regularly after every usage - it prolongs the machines lifespan and is a pre-requisite for a safe working environment. -
Page 10: Warranty
WARRANTY The warranty period starts from the purchase date, and the warranty does not cover product problems caused by not operating in accordance with the specifications of this manual. Except for wearing parts, the whole machine is guaranteed for 1 year. PARTS BREAKDOWN Part No. - Page 11 The presence of this logo on the product means that the disposal of the device is governed by directive 2012/19/EU dated July 4, 2012 on waste electrical and electronic equipment(WEEE). Any hazardous substance contained in electrical or electronic equipment can have a potential impact on the environment and health during its recycling.
- Page 12 Thank you for choosing RedRock products, if you have any questions, please contact online customer service. Size: 210x285mm 157克双铜 REV 05/20/24 3020549...
