- Page 1 Cordless Scanning System SCANTEAM® 2070 Base IMAGETEAM™ 3870/75 Linear Imager SCANTEAM® 5770 Laser ™...
- Page 2 Hand Held Products, Inc. d/b/a HHP (“HHP”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HHP to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HHP.
- Page 3 Cordless Quick Start Guide Introduction The cordless scanning system consists of the SCANTEAM 2070 Base unit and at least one IMAGETEAM 3870 Cordless Linear Imager, IMAGETEAM 3875 Cordless Linear Imager, or SCANTEAM 5770 Cordless Laser Scanner. Up to nine IT3870, IT3875, or ST5770 scanners may be associated with one base.
- Page 4 This guide contains the following information: • Charge pack and charging Information • Associating the cordless scanner to a base • Customer support information • Limited warranty and warranty durations About the Charge Pack (CLESS/NIMH/S) Power is supplied to the cordless scanner by a rechargeable charge pack that snaps onto the bottom of the scanner.
- Page 5 Proper Disposal of the Charge Pack When the charge pack has reached the end of its useful life, the charge pack should be disposed of by a qualified recycler or hazardous materials handler. Do not incinerate the charge pack or dispose of the charge pack with general waste materials. Contact the Product Service Department (see page 7) for recycling or disposal information.
- Page 6 Conditioning the Charge Pack • Charge packs are shipped uncharged and need to be conditioned for full capacity and longer life. • Charge the charge pack for 12 hours for the first two times to fully condition the pack. (Fully discharge in between each initial charge.) •...
- Page 7 IMAGETEAM 3875 You may automatically discharge the IT3875 charge pack by scanning the following bar code. The scanner remains operational during the discharge; however the status LED flashes like a “heartbeat.” IT3875 Charge Pack Discharge Associating the Cordless Scanner to a Base Important: Make sure the cordless scanner’s charge pack has been fully charged.
- Page 8 The IMAGETEAM 3875 includes a keypad and display. In addition to having all of the functionality of HHP’s other cordless scanners, the IT3875 allows you to key in data and run scripts that are shipped with the scanner. Two PC tools also are available to help generate custom applications: IQ App Loader™...
-
Page 9: Obtaining Factory Service
HHP provides service for all its products through service centers located in Charlotte, North Carolina, Hong Kong, the Netherlands, and the United Kingdom. To obtain warranty or non-warranty service, return the unit to HHP (postage paid) with a copy of the dated purchase record attached. - Page 10 For service in Japan, please contact your HHP representative (at the address that follows) or your local distributor. Japan Office Hand Held Products, Inc. Bon Marusan 8F 3-5-1 Kanda-Jinbocho Chiyoda-ku Tokyo 101, Japan Telephone: +81-3-5212-7392 Fax: +81-3-3261-7372 For service in Latin America, please contact your HHP representative (at the address that follows) or your local distributor.
-
Page 11: Limited Warranty Durations
HHP’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HHP product which is (i) improperly installed or used; (ii) damaged by accident or negligence, including failure to follow the proper maintenance, service, and cleaning schedule;... -
Page 12: Statement Of Agency Compliance
Statement of Agency Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 13: R&Tte Directive
R&TTE Directive The IMAGETEAM 3870, IMAGETEAM 3875, SCANTEAM 5770, and SCANTEAM 2070 are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC). This equipment has been assessed to the following standards: ETS 300 328 ETS 300 826 (November, 1997); EN 60950: 1992, Incl Amdt 1-4, 11. - Page 14 Enlarged Views of Regulatory Labels - IT3870 Manufactured MAY 2002 Model # IMAGETEAM 3870 3870XX-XX Item # 12345 S / N SW 1.6/1.08 Hand Held Products, Inc. Skaneateles Falls, NY 13153, USA See User Guide for Patent Information Made in USA IT3870 Scanner Left Side View IT3870 Scanner...
- Page 15 Enlarged Views of Regulatory Labels - IT3875 Manufactured AUGUST 2002 Model # IMAGETEAM 3875 3875XX-XX Item # 12345 S / N SW 1.6/1.08 Hand Held Products, Inc. Skaneateles Falls, NY13153, USA See User Guide for Patent Information Made in USA IT3875 Scanner Left Side View IT3875 Scanner...
-
Page 16: Right Side View
Enlarged Views of Regulatory Labels - ST5770 Manufactured MAY 2000 Model # SCANTEAM 5770 3870XX-XX Item # 12345 S / N SW 1.6/1.08 Hand Held Products, Inc. Skaneateles Falls, NY 13153, USA See User Guide for Patent Information Made in USA ST5770 Scanner Left Side View ST5770... - Page 17 Enlarged Views of Regulatory Labels - ST2070 ST2070 Base - Bottom This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that can cause un- desired operation.
-
Page 18: Sample Symbols
Sample Symbols UPC A 0 123456 7890 Interleaved 2 of 5 Code 128 1234567890 Code 128 EAN 13 9 780330 290951 Code 39 Codabar BC321 A13579B Code 11 with 2 Check Characters 0123456789... - Page 19 Sample Symbols PDF417 MicroPDF417 PDF417 Test Message MicroPDF417 Test Message Matrix 2 of 5 Code 93 6543210 Code 2 of 5 123456-9$ RSS-14 123456 (01)00123456789012 UCC Composite • Symbology with RSS Limited (01)12345678901231(10)123456789(11)001205(3202)001234...
- Page 20 3870/75/5770/QS Rev C...
