DigiTrak Falcon® transmitters
The Falcon family of transmitters come in wideband, single-band, and Sub-K®
rebar with a variety of features, power modes, and depth/data ranges. The
battery and power mode you choose for your transmitter will affect the depth
and data range available for your job.
Find your Falcon transmitter product ID
The product ID of your transmitter (Tx) is on the etching. Use the product ID to
look up your transmitter's available power modes, battery life, depth, and data
ranges in the charts in this quick start guide.
Choose the best battery for the job
Use only real DCI SuperCell™ and LiR batteries for High power mode and 19-
and 24-inch Standard power. You can use 2 C-cell alkaline batteries for 15-inch
Low and Standard (Std) power, but the SuperCell is best for extreme conditions
and longer battery life. 8-inch transmitters only use Li CR123 and 6-inch
transmitters only use Li AA or Alkaline AA. Always install a fully charged battery.
Recommended LiR Manufacturer
Klarus
Fenix
Acebeam
For V2 transmitters, choose power mode for the job
For V2 Txs, you can choose:
•
High power mode for a strong signal with greater depth and data range.
•
Standard power mode for best balance of battery life and depth.
•
Low power mode for extended battery life. For Falcon+ locators, Low power also
gives you a faster pitch and roll update rate.
© 2024 Digital Control Incorporated
All rights reserved. 402-2051-99-F Eng+Met
Part Number
21GT-50
ARB-L21-5000
IMR217000NP-510A
digital-control.com
- 1 -
1. Etching
2. Colored label
3. IR Port
Advertisement
Related Manuals for Digital Control DigiTrak Falcon FT5XLp V2
Summary of Contents for Digital Control DigiTrak Falcon FT5XLp V2
- Page 1 Standard power mode for best balance of battery life and depth. • Low power mode for extended battery life. For Falcon+ locators, Low power also gives you a faster pitch and roll update rate. © 2024 Digital Control Incorporated digital-control.com All rights reserved. 402-2051-99-F Eng+Met...
- Page 2 - 2 - Blue tube V2 transmitters battery, depth, and data range Power Li CR123 Data Range Mode SuperCell w/FTA Alkaline or LiAA Depth 24-in High 14 hrs 8 hrs 180 ft/55 m 220 ft/67 m FT5XLp 40 hrs 18 hrs 160 ft/49 m 185 ft/56 m 120 hrs...
- Page 3 - 3 - 1Faster updates for low power with Falcon+ locators and F1 locators with QSP 2FT2L+ V2 is only compatible with Falcon+ locators 3 FT1 and FT1s V2's have low and standard power only 4 Data Range is based on Max Mode™ The battery types listed are the only types recommended for that product ID and size.
- Page 4 DCI logo, DigiTrak, DigiTrak Falcon, F2, F5, and Sub-K are registered trademarks and DigiGuide, Falcon Noise Bar logo, Max Mode, and SuperCell are common law trademarks of Digital Control Incorporated. Additional trademark registrations are pending. U.S. and foreign patents apply to the product covered by this guide. For details, please visit www.DigiTrak.com/patents.
