Anviz L100KD Installation Manual

Installation Instructions
Product And Accessories
L100KD L100D
Outside panel
2 Rubber mats and 1 mounting plate
-1-
Installation
* See Note 1
Step 1
Insert dead bolt into the door as shown
in diagram. Make sure the arrow
points up. Fasten the screws.
Step 4
Keep outside panel in unlock status.
lock spindle
Insert the through the dead
lock spindle
bolt and make sure the
in the outside panel.
Note 1: Make sure the hole dimension is fit for bolt installation (Refer to chapter "New Door Preparation").
Note 2: Make sure the bottom screw rod get through the holes in dead bolt.
Note 3: Make sure the knob in the right position as it shown in "Thumb Turn".
-2-
www.anviz.com
Installation Guide
Home & Business Smart Lock
L100KD/L100D
Before Connecting, operating or adjusting this product, please read the instructions carefully.
Keep this manual in case you need it at a later date.
is registered trademark of Anviz Global Inc. in the United States and other countries. It cannot be used without the
permission of Anviz.
Inside panel and battery cover
Step 2
Install outside panel with rubber mat on
door, and route the wire through the hole
over the dead bolt.
Step 5
Remove the above 2 screws installed on
mounting plate. Adjust the knob as shown
in "Thumb Turn". Connect wire from the
plugs
Outside panel to Inside panel. Adjust the
outside knob in order that
inserted into thumbturn vertically.
Intelligent.Security
BIOMETRIC - RFID - SURVEILLANCE
(V3.1)
L100KD/L100D
RFID cards (L100D) and Emergency keys
Lock Spindle, Screwdriver and fixing Screws
Dead Bolt
(4 long screws for outside panel mounting,
2 short screws for inside panel mounting, 2 short
screws for bolt fixing.)
* See Note 2
Step 3
Install
wire through left hole. Install four screws on the
Mounting Plate
Recommend: DO NOT OVER TIGHTEN the two
screws above.
* See Note 3
Thumb Turn
Step 6
Fasten four screws to fix the inside panel. Turn
the knob to make sure that you can push the
dead bolt.
Install alkaline batteries and battery cover.
lock spindle is
RF Key
Mounting Plate with Rubber Mat and route
to fix the position.
