Summary of Contents for RG2i MClimate MC-LW-Flood
- Page 1 MClimate Flood Sensor LoRaWAN® User manual...
- Page 2 Scan the QR Code Bulgarian Czech to access MClimate За да разберете как се Chcete-li zjistit, jak инсталира MClimate nainstalovat MClimate Flood Flood Sensor LoRaWAN® Flood Sensor LoRaWAN®, Sensor LoRaWAN®, extended сканирайте QR кода или prohlédněte si kód QR nebo documentation посетете...
-
Page 3: Table Of Contents
Table of content What’s inside the box? What is in the box? Technical details, Safety instructions, Legal Notices & Compatibility Device Parts MClimate Flood Sensor LoRaWAN® Commissioning LED, Buttons and behaviour Installation... -
Page 4: Legal Notices & Compatibility
Technical specifications Safety Instructions Description: LoRaWAN® flood sensor Please read the safety instructions before Model: MC-LW-Flood installing the device! Failure to follow the Dimensions: 70 x 70 x 19mm recommended instructions in this manual may Weight: 33gr be dangerous or in violation of the law. The Frequency range: 863÷870MHz manufacturer MClimate Jsc., is not responsible LoRaWAN®... -
Page 5: Device Parts
Device parts LoRa Radio Serial number (QR and text) Module & Antenna Positive battery terminal Status LED XXXXXXXXXXXXXXXX LoRaWAN Flood Sensor Anti-tamper Input: 3.6 button Button Negative Buzzer battery Flood detection pins terminal Device on the inside, PCB top Device, back... -
Page 6: Commissioning
Commissioning Open your LoRaWAN® Network provider access panel and add the device using the supplied Serial Number, DevEUI, AppEUI (JoinEUI) and AppKey. The data is example. Do not use. Continue the Installation with the instructions of your LoRaWAN® Network provider. You can get DevEUI, AppEUI (JoinEUI) &... - Page 7 Commissioning In order to remove the top plastic cover, apply pressure with two hands on the device from the top and bottom sides. Then gently twist the device counterclockwise until you feel a soft click and lift the top plastic cover.
- Page 8 Insert a CR123A to power the device, it will automatically connect to a network. In order to see whether the device has connected to the network, please check section LED, Buttons and behaviour. CR123A 3VDC battery...
-
Page 9: Led, Buttons And Behaviour
LED, Buttons, Buzzer and behaviour The device has 1 Button, 1 Anti-tamper button, 1 LED and 1 Acoustic buzzer. The anti-tamper button is activated when the device is opened. A special uplink will be sent at the earliest convenience. The second button is used during commissioning in order to check if the device has connected to the network. - Page 10 Status LED Anti-tamper button Button Buzzer...
-
Page 11: Installation
Installation There are no special instructions regarding the installation. One must consider NOT installing the device directly under appliances (e.g. washing machine) as the metal parts will influence the RF performance. Instead, please keep the device 1-2cm away from the appliance.
