USER MANUAL
On Grid
Single Phase Hybrid
Solar Inverter
ULTRA PRO 5000W-48V
ULTRA 5000W-48V
Where SUN shined
Power always on
Monitor APP Download
Android
IOS
Cellcronic Technologies Pvt. Ltd.
www.cellcronic.com
Building No. 1, Daniyalpur chowk, Airport Road, Karnal, Haryana (132001)
contact@cellcronic.com
Advertisement
Table of Contents
Related Manuals for CELLCRONIC ULTRA PRO 5000W-48V
Summary of Contents for CELLCRONIC ULTRA PRO 5000W-48V
- Page 1 USER MANUAL On Grid Single Phase Hybrid Solar Inverter ULTRA PRO 5000W-48V ULTRA 5000W-48V Where SUN shined Power always on Monitor APP Download Android Cellcronic Technologies Pvt. Ltd. www.cellcronic.com Building No. 1, Daniyalpur chowk, Airport Road, Karnal, Haryana (132001) contact@cellcronic.com...
-
Page 2: Table Of Contents
Table Of Contents 3. Working Modes Information on this Manual Validity 3.1 Offgrid modes introduction Scope 3.2 Working modes related setting description 4. LCD Display and settings Target Group Safety Instructions 4.1 LED Display 4.2 LCD Display 1. Brief Introduction 4.3 Inverter Status Display 1.1 Features of the inverter 4.4 LCD Settings... -
Page 3: Information On This Manual
Do not open inverter cover or change SONAR series is a multifunctional, high frequency pure sine wave ECO Hybrid inverter solar inverter, features: any components without Cellcronic's authorization, otherwise the warranty commitment for the inverter will be invalid. -
Page 4: Interface Of The Inverter
1.3 Packing List 1.2 Interface of the inverter Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items in the package: LCD display Cross Head Expansion Screw Function buttons ECO Hybrid inverter X1 User Manual X1 Wi-Fi Module X1... -
Page 5: Installation
2. Installation 3. PV Connection: Please install separately a DC circuit breaker between inverter and PV modules. The recommended of DC breaker is 600V/25A. It's very important for system safety and efficient operation to use appropriate cable for PV module connection. To reduce risk of injury, please use the 2.1 Preparation proper recommended cable size as below: The system connection is as below:... -
Page 6: Battery Connection
50mm. Cellcronic inverter. Please check the compatible list in the Cellcronic website. Step2. Install the expansion tubes into the holes and tight them, then use the expansion screws (packaged Please follow below steps to implement lithium battery connection: together with the expansion tubes) to install and fix the wall-mounting bracket on the wall. -
Page 7: Ac Input/Output Connection
CT Clamp Ratio MPPT485/CT 1 2 3 4 5 6 7 8 The inverter support 3 ratios of CT clamp- 1000:1 , 2000:1 and 3000:1 . The CT ratio of the CTs in the accessory bag is 3000:1. If you are using a 3rd party CT, please ensure the CT ratio is one of them, and select the correct CT ratio setting in the inverter monitor page or on the inverter LCD. -
Page 8: Pv Connection
BAT+ BAT- All Cellcronic units can work with generator. Users can connect the generator output to ECO Hybrid inverters. GEN input terminal. The generator will be automatically started when battery voltage is lower than the cut-off value or there is charge 2.6 PV Connection... -
Page 9: Dry Contact Signal Control
Inverter 1 Phase L1 2.8 Dry Contact Signal control Grid or Generater AC Input Phase L1 The Dry port(NO2,COM2) could be used to deliver signal to external device when battery voltage CAN 1 reaches warning level. The GEN port(NO1,COM1) could be used to wake-up the Generator and CAN 2 AC Output Parallel line 1... -
Page 10: Working Modes
0 kWh 257.1 kWh Dragonview Parallel 48 W the PV can wake up the battery t https://www.cellcronic.com/ For more detailed guidance for paralleling system, please vis automatically And download the guidance 2.10 Power and EPS ON/OFF PV charge the battery and... -
Page 11: Working Modes Related Setting Description
3.2 Working Modes related setting description Working modes and Description Situation Setting 1 Setting 2 Setting 3 off grid inverter mode if P_Solar>=P_load, solar is used to take load and charge battery AC abnormal if P_Solar<P_load, solar and battery take the load together, system will discharge until battery lower than the Cut Off Voltage/SOC Hybrid Mode 1(charge first) Solar power will used to charge battery first,... -
Page 12: Lcd Display And Settings
1. SONAR can work as traditional off grid inverter or as a hybrid inverter. When disable PV&AC Discharge Setting Take load Jointly, it will work as a traditional off grid inverter, otherwise it will work as a hybrid Discharge Control According to SC Hybrid Setting Battery Warning Voltage... -
Page 13: Lcd Display
4.3 Inverter Status Display 4.2 LCD Display Normal status, running status 40 Warning Status, warning 29 Description Remarks Display the currently time/date by default(year/month/day/ hour/ minute” switching automatically). When press Up or Down buttons, Generally Information this area will display the firmware version information, serial number Display Area etc. -
Page 14: Lcd Settings
Step3: Then touch Enter button to set this item. 0- > Standard Battery 2->Pylon Battery Step4: Touch UP or Down button to change 6-> Cellcronic protocol Battery 8->Dyness Battery the settings. Step5: Touch Enter to confirm the setting or AC Output voltage Return the setting list is as below. - Page 15 Setting range: VOLT: 40.0-OnGrid EOD Volt Default: 42V Setting range: ConChr: 50.0-59.0Vdc CutOFF: CV voltage setting Default: 56.4V Cut off Voltage or SOC, depend (Only in Lead-acid SOC: 0-OnGrid EOD SOC on TEOd battery type) Default: 15% Setting range: VOLT: Cut off Volt-56V Default: 42V Setting range: Eod:...
- Page 16 AC charge setting AC Charge function: (The setting process Setting Range: Setting range: Feed-In Disable (default) must enable the AC 1.DIS: AC charge disable; 2.TIM: According to time; charging function, Feed-In 3.VOL: According to battery voltage; confirm the full Enable/disable 4.SOC: According to battery soc;...
- Page 17 External Grid CT (Latest Version Only) Setting Range: Setting Range: Green Function Disable Disable (default)/Enable (default) Power Save CT Offset Internal CT Offset Function Setting Range:-200~200W Green Function Enable enable/disable 20W (default) Setting Range: Fan1 Speed Percent ECO Mode Disable (default) ECO Mode Enable Setting Range: 20-100% 70% (default)
-
Page 18: Specifications
The APP is also available in the google play and apple APP store(Scan two code bar to download the APP). ULTRA 5KW-48V INVERTER MODEL ULTRA PRO 5KW-48V Please download the introduction of guidance by website: https://www.cellcronic.com/ Document Reference: Input Voltage Waveform Sinusoidal (utility or generator) 1. - Page 19 Battery Voltage Range 46.4V-60V(Li) 38.4V-60V(Lead_Acid) Battery Voltage, per cell Charging Current High DC Cut-off Voltage 59VDC(Li) 60VDC(Lead_Acid) 2.43Vdc(2.35Vdc) Voltage High DC Recovery Voltage 57.4VDC(Li) 58VDC(Lead_Acid) 2.25Vdc 100% 44.0Vdc(Settable) load < 20% Low DC Warning Voltage Warning Voltage @load < 20% -1.2V 20% ≤...
-
Page 20: Trouble Shooting & Error List
No master in parallel system contact us or battery manufacture there should be one master in the system Please contact Cellcronic for firmware update W008 Software mismatch Check if the load is short circuit, try to turn off the load...
