Important Notes - eSSL EM lock Installation Manual

1. Use jacketed cable for all wire runs. Refer to the SDC wire gauge
chart for proper lock power wire size (18 AWG gauge minimum).
2. Use only shielded cable for all signal wires. 22 AWG gauge
(minimum) may be used for signal wires up to 1,000 feet.
3. All wires must be colored coded
4. Use properly fused power source only.
Electrical Instruction:

IMPORTANT NOTES
