- Page 1 L12200 Lithium-ion Battery for Off-Grid Application L12200 Lithium-ion Battery for Off-Grid Application Version：V1.0 Released Date：2024 -02-24 Document Number：L12200-V1.0-202402...
-
Page 2: Foreword
L12200 Lithium-ion Battery for Off-Grid Application FOREWORD Overview This manual describes the installation, parameter settings battery maintenance etc. Please keep the manual in safety for more information. Readers This document provides technical details regarding the tools and infrastructure used by the following users: Sales engineer ... -
Page 3: Table Of Contents
L12200 Lithium-ion Battery for Off-Grid Application CONTENT FOREWORD ..........................2 CONTENT ..........................3 1 OVERVIEW ..........................4 1.1 Product model ........................4 1.2 Product profiles ........................4 1.3 Product structure ....................... 4 2 INSTALLATION GUIDE ......................5 2.1 Installation precaution notes ....................5 2.2 Installation preparation ..................... 7 2.3 Installation method ...................... -
Page 4: Overview
The L12200 Lithium-ion Battery is one of the new energy storage products developed and manufactured for off-grid application. It can be used to support reliable power for various types of devices and solar systems. L12200 is especially suitable for off grid solar system. -
Page 5: Installation Guide
L12200 Lithium-ion Battery for Off-Grid Application 2 INSTALLATION GUIDE 2.1 Installation precaution notes Comply with local laws and regulations When operating the equipment, make sure to certain to comply with local laws and regulations. Personnel requirements Technicians responsible for installation and maintenance must first undergo rigorous training. - Page 6 L12200 Lithium-ion Battery for Off-Grid Application To facilitate the operation and maintenance of the battery, a minimum of 30-50cm should be left around the battery, with approximately 50cm left for the upper space. The installation space is better to be fitted with an exhaust fan to ensure good ventilation.
-
Page 7: Installation Preparation
L12200 Lithium-ion Battery for Off-Grid Application Power check Before installation, make sure that the load capacity of the supply wire meets the requirements of the new equipment. Check that the voltage and frequency of the power supply matches the nameplate on the equipment and that the current carrying capacity has not decreased due to ageing of the wire. - Page 8 L12200 Lithium-ion Battery for Off-Grid Application Wire cutters Needle-nosed pliers Marking pen Working gloves Ladder (2m) Flashlight Tape measure Impact drill Table2-2 Tools for delivery and unpacking The appearance of the tools, parameters, and names Leverage Manual forklifts Electric forklift Sling (weight≥400kg)
-
Page 9: Installation Method
L12200 Lithium-ion Battery for Off-Grid Application 2.3 Installation method Connection (Red: Positive terminal of battery Black: Negative terminal of battery) It can support up to 4 series battery packs or 4 parallel battery packs (cannot be connected in series and parallel at the same time) for extended voltage and power. -
Page 10: Maintenance
L12200 Lithium-ion Battery for Off-Grid Application 3 MAINTENANCE To ensure that the lithium-ion battery pack achieves the longest possible service life, the service technician should carry out regular inspections and maintenance. Maintenance records should be complete and routine so that subsequent verification of the battery pack's management parameters can be tracked. -
Page 11: Problem-Solving Solutions
L12200 Lithium-ion Battery for Off-Grid Application Check the charging and discharging data at least once every six months . 3.3 Problem-solving solutions 1) Identify the problem： Whether the battery can be charged/discharge; Preliminary solution: The battery cannot be charged or discharged, please check the battery parameters: a) Temperature: If the temperature is higher than 50 ℃... -
Page 12: Specification
L12200 Lithium-ion Battery for Off-Grid Application 4 SPECIFICATION 4.1 Technical specifications Technical data for a single battery is shown in table 4-1. Table 4-1 technical data Item Specification Model L12200 Rated Capacity 200 Ah Nominal Voltage 12.8 V Discharge Ending Voltage 10±0.5 V... -
Page 13: Environment Protection
L12200 Lithium-ion Battery for Off-Grid Application 5 ENVIRONMENT PROTECTION 5.1 Recycle This symbol indicates that the product cannot be classified with other wastes. To prevent potentially hazardous substances from being disposed of in a way that endangers the environment and human health, please refer to the classification of waste recycling to promote the sustainable use of material resources..
