MDP-SC Series User Manual
M
I Corporation
2
Industrial Monitor
MDP-SC
User Manual
Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product.
M2I Corporation
1 / 19
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14055, Korea
Tel: +82-31-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr
Advertisement
Table of Contents
Summary of Contents for M2I MDP-SC Series
- Page 1 Industrial Monitor MDP-SC User Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product. M2I Corporation 1 / 19 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14055, Korea Tel: +82-31-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 2: Table Of Contents
MDP-SC Series User Manual Index Chapter 1 Safety Precautions ................................. 3 Chapter 2 Overview ....................................5 2.1 Introduction of Products ............................... 5 2.2 Package Contents ................................5 2.3 Explanation of Model Name ............................5 Chapter 3 General Specifications ................................. 5 3.1 Power Specifications ............................... -
Page 3: Chapter 1 Safety Precautions
MDP-SC Series User Manual Chapter 1 Safety Precautions ■ Before using the product To use the product safely and effectively, please read the contents of this manual thoroughly before use. Please keep to the safety precaution, for it is to prevent accidents and potential danger from occurring. Safety precaution is classified into ‘Warning’... - Page 4 MDP-SC Series User Manual ■ Installation Precautions Do not install the location which exceeds allowed temperature. Product can be damaged or shorten the life. Especially Install environment as below should be avoided. Do not Install product to the place which the ambient temperature is out of limits, from -10℃ to 50℃ or on the surface of control board which high pressure equipment is installed.
-
Page 5: Chapter 2 Overview
MDP-SC Series User Manual Chapter 2 Overview 2.1 Introduction of Products This Industrial Monitor is required in an industrial field. It displays demanded screen features from multiple devices through HDMI connection, and a touch sensor can be connected to outer device by USB. -
Page 6: Display Specifications
MDP-SC Series User Manual 3.2 Display Specifications Display Color 16M Color Backlight Type Backlight Life Minimum 50,000 Hours Resolution Max. 1920 x 1080 Scaling Up / Down Scaling Supported 3.3 Touch Specifications Operating Method Integrated, Capacitive Touch Sensor Connection Method USB Type A to Type A Cable 3.4 OSD Button (Screen Menu) -
Page 7: Chapter 4 Part Names And General Specifications
MDP-SC Series User Manual Chapter 4 Part Names and General Specifications 4.1 External Dimension (mm) Model MDP-SC1200WD 321.4 252.4 67.5 MDP-SC1500WD 406.4 286.4 MDP-SC1900WD 477.4 328.4 71.4 M2I Corporation 7 / 19 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14055, Korea... -
Page 8: Part Names And Specifications
MDP-SC Series User Manual 4.2 Part Names and Specifications 4.2.1 Front Name Description ① Status LED ② USB HOST USB Connector to use Mouse of Keyboard, Output Power 5V/0.5A ③ Front USB Cover Front USB Cover ④ Touch Panel Capacitive Touch Sensor ⑤... -
Page 9: Chapter 5 External Device Interface
MDP-SC Series User Manual Chapter 5 External Device Interface In order for the main unit to communicate with an external device, it is necessary to connect the two devices by referring to the following. 5.1 USB Specifications Type Item Specification USB Interface USB 2.0... -
Page 10: Chapter 6 Installation
MDP-SC Series User Manual Chapter 6 Installation 6.1 Installation Requirements (1) It should be installed within -10 ~ 50°C and 10~80% relative-humidity, otherwise the screen may be changed or cause malfunction and damage. (2) Be sure that heat from surrounding equipment does not cause product to exceed its standard operating temperature. - Page 11 MDP-SC Series User Manual 6.2.2 Clamp Fixing Install clamps with this product should be installed as follows to maintain the IP performance of the device. (1) Insert the clamp into the slot of the product. (2) Screw the unit into the panel cut with a screwdriver.
-
Page 12: Front Usb
MDP-SC Series User Manual 6.2.3 VESA Bracket Mount Use M4 x 10mm screw to connect the monitor with VESA bracket. Please refer to user manual with VESA bracket. (1) Put the monitor on stable and flat ground with spread cotton or cushion. -
Page 13: Chapter 7 Osd Setup
MDP-SC Series User Manual Chapter 7 OSD Setup 7.1 Rear OSD Setup Buttons Screen settings of this product can be done by rear OSD Menu Buttons. Button Shape Name Description Screen Change Screen change between HDMI and DP Switch Menu Switch... - Page 14 MDP-SC Series User Manual 7.2.2 Color - Color Temp: Setting a temperature level of screen. (6500K, 7500K, 9300K, User Define) - Red [0 ~ 100]: Setting a level of red color. - Green [0 ~ 100]: Setting a level of green color.
-
Page 15: Chapter 8 Wiring
MDP-SC Series User Manual 7.2.4 Setup - Reset [Off, On]: Reset settings of OSD. - Display Size [16:9, 4:3]: Force adjustment of screen ratio. - Mute [Off, On]: Mute the audio or cancel the mute. - Volume [0 ~ 100]: Setting the volume level. -
Page 16: Ground Wiring
MDP-SC Series User Manual (3) Wiring of power is as follows. 8.2 Ground Wiring (1) The product has enough anti-noise measure, so except that there are many noises. Specially, the ground is not needed. When doing ground, please refer to the followings. -
Page 17: Fixing Communication Cable
MDP-SC Series User Manual 8.3 Fixing Communication Cable Caution: To prevent a disconnection or spark when USB cable gets away from the port, the cable must be fixed. User must be well-informed about below process. (1) Insert a cable connector into a cable clamp as below image. -
Page 18: Chapter 9 Maintenance
Check the touch pad there is no damage, scratch or pollution by eye. 9.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation, which is indicated on the product label. -
Page 19: Chapter 10 Products And Warning Label
I Corporation 2024.08 www.m2i.co.kr - Please read related contents in this manual when you use M2I product, and operate the product staying safe with appropriate handling. - This manual should be stored in secured and appointed place so that it can be read in any needs.
