Summary of Contents for FLIT FLIT-16 BATTERY
- Page 1 FLIT-16 BATTERY INSTRUCTIONS MBP-BI36S7M02.L8 E-Bike Battery Pack User Manual...
- Page 2 FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 FCC Notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 IC Statement This device complies with Industry Canada license-exempt RSS Standard(s). Operation is subject to the following two conditions. • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation.
- Page 5 Do not subject the battery to strong shocks or throw it, as this may result in overheating, bursting, or fire. • Use the FLIT specified charger and observe the specified charging conditions when charging the specified battery. Not doing so may cause overheating, bursting, or ignition of the battery.
- Page 6 • Do not deform, modify, disassemble, or apply solder directly to the battery. Doing so may cause leakage, overheating, bursting, or ignition of the battery. • Do not use the battery if it has any deep gouges or other external damage. Doing so may cause bursting, overheating, or problems with operation.
- Page 7 Product Appearance Right Hand View LED Indicator Power Button/Battery Level Button Page 6 of 15...
- Page 8 Left Hand View Charging port Front End View Power and Communication Port Page 7 of 15...
- Page 9 (see image on page 7). • To charge the battery when it is removed from the FLIT- 16, plug the charger both into the charging port on the battery and into a power outlet. The small arrow on the...
- Page 10 Charge Indicator • If the battery is powered on, you can press the power button to see the battery level. Power Button Battery Level Indicator 1 Battery Level Indicator 2 Battery Level Indicator 3 Battery Level Indicator 4 & Warning Indicator Battery Level Indicator: White Warning...
- Page 11 Charge Remaining when Battery is not Charging Battery Level Indicator Battery Level (4,3,2,1) 75 - 100% 50 - 74% 25 - 49% 10 - 24% 0 - 9% ：No light ：Lit Up ：Blinking Charge Indicator When Battery Is Charging Battery Level Indicator Battery Level (4,3,2,1) 100%...
- Page 12 Warning Indicator If an error occurs, the battery level indicator LEDs will show a warning pattern. You can diagnose the error by finding the warning pattern in the table below: Battery Level Indicator Error Solution (4,3,2,1) Remove the charger from the battery.
- Page 13 Battery Level Error Solution Indicator (4,3,2,1) An error Turn the battery occurred during off and then on discharging. again. The battery Charge the voltage is below battery for at the normal least 30 minutes. range. Battery Contact the malfunction. manufacturer. Internal error Contact the (level 1).
- Page 14 Product Specification MBP-BI36S7M02.L8 Model Voltage/Current 36V / 12A Capacity 6.4Ah / 230.4Wh Dimension Ø63.4 x 350 mm Weight 1.5 Kg Charging Time < 6 hours (2A Charger) Page 13 of 15...
- Page 15 Company Information Address: Flit (Cambridge) Limited Future Business Centre Kings Hedges Road Cambridge United Kingdom CB4 2HY E-mail: support@flit.bike Website: flit.bike/contact-us/ Page 14 of 15...
- Page 16 Page 15 of 15...
