Delta Kesara SD7909764 Installation Manual

Delta Kesara SD7909764 Installation Manual

Frameless sliding shower and bathtub doors
Hide thumbs

Advertisement

Table of Contents

Kesara
Frameless Sliding
Shower
and
Bathtub Doors
5/16 inch glass (8mm)
Puertas para ducha
y bañera corredizas
sin marco
Vidrio de 5/16 pulg. (8 mm)
INSTALLATION GUIDE / GUÍA DE INSTALACIÓN
CAUTION identifies a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury and/or
property/product damage.
IMPORTANT identifies information critical to installation,
operation, or maintenance.
NOTE indicates helpful advice to make installation, operation or
maintenance proceed well.
CAUTION: To reduce the risk of breakage, keep corner protectors on glass while installing. Avoid contact between
shower door and metal parts and/or hard surfaces. Always ensure glass panels are placed on padded surfaces.
PRECAUCIÓN: Durante la instalación, coloque vidrio o protectores de esquinas para reducir el riesgo de romperse. Evite el
contacto entre la puerta de la ducha y las piezas metálicas y/o superficies duras. Asegúrese siempre de que los paneles de
vidrio estén colocados sobre superficies acolchadas.
Consult your local plumbing codes prior to installation.
Consulte los códigos de fontanería locales antes de la instalación.
NOTE: Installation widths: 60" Tub/shower: 53"minimum – 60" maximum,
NOTA: Installation widths: para ducha/bañera de 60" (152,40 cm): mínimo 53" (134,6 cm) – máximo 60" (152,4 cm),
ducha de 48" (121,92 cm): mínimo 44" (111,76 cm) – máximo 48" (121,92 cm).
Minimum Required Clearance Heights for Installation:
For Shower: 76 Inches (193.04 cm)
For Tub: 63.75 Inches (161.92 cm)
Minimum Required Installation Wall Heights
for Installation:
For Shower:
73 Inches (185.42 cm)
For Tub:
60.75 Inches (154.30 cm)
Minimum Sill Depth:
3.15 Inches (8.0 cm)
CP 7733727
48" Shower: 44" minimum – 48" maximum.
• BEFORE BEGINNING, READ ALL INSTRUCTIONS WITH PARTICULAR
ATTENTION TO SAFETY INFORMATION AND TO ENSURE YOU HAVE
ALL PARTS, TOOLS AND PROTECTIVE EQUIPMENT NEEDED TO SAFELY
INSTALL YOUR UNIT.
• PLEASE DO NOT CONTACT STORE FOR REPLACEMENT PARTS
• PLEASE VISIT www.deltashowerdoors.com FOR ASSISTANCE AND PARTS
• ANTES DE COMENZAR, LEA TODAS LAS INSTRUCCIONES PRESTANDO ATENCIÓN
ESPECIAL A LA INFORMACIÓN DE SEGURIDAD Y ASEGÚRESE DE TENER TODAS
LAS PIEZAS, HERRAMIENTAS Y EQUIPOS DE PROTECCIÓN NECESARIOS PARA
INSTALAR SU UNIDAD DE FORMA SEGURA.
• POR FAVOR, NO CONTACTE A LA TIENDA PARA SOLICITAR PIEZAS DE REPUESTO
• PUEDE VISITAR www.deltashowerdoors.com PARA SOLICITAR AYUDA Y
HACER CONSULTAS SOBRE PIEZAS.
ADVERTENCIA identifica situaciones potencialmente peligrosas
que, de no evitarse, podrían provocar lesiones leves o
moderadas y/o daños a la propiedad/producto.
IMPORTANTE identifica información esencial para la instalación,
funcionamiento, o mantenimiento.
NOTA indica consejos útiles para una correcta instalación,
funcionamiento o mantenimiento.
Alturas mínimas de separación necesarias para la instalación:
Para la ducha: 76 pulgadas (193,04 cm)
Para la bañera: 63,75 pulgadas (161,92 cm)
Alturas mínimas de la pared necesarias para la instalación:
Para la ducha:
73 pulgadas (185,42 cm)
Para la bañera:
60.75 pulgadas (154,30 cm)
Requisitos mínimos
de profundidad del
bordillo:
3.15 pulgadas (8,0 cm)
DESIGNED AND DISTRIBUTED BY LIBERTY HARDWARE MANUFACTURING CORPORATION
STOP
PARE
JULY 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kesara SD7909764 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Delta Kesara SD7909764

Summary of Contents for Delta Kesara SD7909764

  • Page 1 STOP Kesara PARE Frameless Sliding • BEFORE BEGINNING, READ ALL INSTRUCTIONS WITH PARTICULAR Shower ATTENTION TO SAFETY INFORMATION AND TO ENSURE YOU HAVE ALL PARTS, TOOLS AND PROTECTIVE EQUIPMENT NEEDED TO SAFELY Bathtub Doors INSTALL YOUR UNIT. • PLEASE DO NOT CONTACT STORE FOR REPLACEMENT PARTS 5/16 inch glass (8mm) •...

  • Page 2: Before You Start

    For optimal maintenance it is recommended that the glass panels be squeegeed on a regular basis after the shower is used. For further inquiries, contact Delta Shower Doors Customer Care Team at customersolutions@deltashowerdoors.com or call 1-800-964-4850. PRECAUCIÓN: Los montantes deben estar en esta ubicación a cada lado de la instalación de la puerta. Otras 2"...

  • Page 3: Antes De Comenzar

    Para el mantenimiento óptimo se recomienda que se limpien los paneles de vidrio con regularidad después de utilizar la ducha. Si tiene otras preguntas, póngase en contacto con Delta Shower Doors Customer Care Team en customersolutions@deltashowerdoors.com o llame al 1-800-964-4850.
  • Page 4 DOOR ASSEMBLY / MONTAJE DE LA PUERTA TRACK ASSEMBLY CARTON PARTS IDENTIFICATION / IDENTIFICACIÓN DE LAS PARTES DE LA CAJA DEL MONTAJE DE LOS RIELES Y LA MANIJA CAUTION: To reduce the risk of breakage, which may result in personal injury, property damage or product failure, DO NOT set glass panels on a hard surface or on their edge.
  • Page 5 DOOR HANDLE HARDWARE / COMPONENTES DEL ASA DE LA PUERTA HARDWARE / HERRAJE NOTE: Handle styles may vary depending on design. Ensure each component is identified based on your purchase. NOTA: Los estilos de manija pueden variar Tile Anchor según el diseño. Asegúrese de que Anclaje para cada componente se identifique en M5 x 10...
  • Page 6 Atención al Cliente de Delta Shower Doors al 1-800-964-4850. Using a pencil or other marking tool (such as painters tape), mark distance “A”...
  • Page 7 PARA EL RECINTO DE LA BAÑERA Si no tiene un montante en esta zona para ambas paredes laterales, llame al equipo de Atención al Cliente de Delta Shower Marque los dos orificios intermedios en la plantilla del collarín (D) y Doors al 1-800-964-4850.
  • Page 8 For ceramic tiles, insert tile wall anchors (GG). If your center guide (C) hangs off the edge of your sill, call Delta If needed, gently use a rubber mallet to assist in install. Shower Doors Customer Care Team at 1-800-964-4850.
  • Page 9 Center Guide Base Bracket Installation CAUTION Find the center of the dam strip (H) by measuring sidewall-to- sidewall and dividing by 2. This will be Measurement "B". Wear safety glasses and cut-resistant, non-slip gloves when drilling or cutting to avoid risk of injury. Sidewall to sidewall PRECAUCIÓN ÷...
  • Page 10 C” ________fmeasurement “C” PRECAUCIÓN For any questions about this step, please call Delta Shower Doors Customer Care Team at 1-800-964-4850. Para evitar riesgos de lesiones al taladrar o cortar, use gafas de seguridad y guantes antirresbalantes y resistentes aal corte.
  • Page 11 Installing The Dampers Place top track wall bracket (F) into position. Place damper template (B) into position at one end of top track Secure to side wall using two pan head screws (AA). (A). Ensure damper template is seated flush against end of top Hand tighten until fully secure.
  • Page 12 Secure damper assembly to top track (A) with screws (CC) and CAUTION nuts (DD). Hand tighten to secure. Wear safety glasses and cut-resistant, non-slip gloves when drilling or cutting to avoid risk of injury. Repeat for all four dampers. NOTE: Nuts (DD) are captured within Damper Assembly. PRECAUCIÓN Asegure el conjunto de amortiguadores al carril superior (A) con tornillos (CC) y tuercas (DD).
  • Page 13 Si observa algún desgaste o daño en los paneles de pisos de hormigón) ya que podría romperse. vidrio, llame al equipo de Atención al Cliente de Delta Shower Doors al 1-800-964-4850.
  • Page 14 After testing the fit, apply a small bead of 100% clear silicone into Installing Roller Brackets base of glazing end caps (M, N). Glazing channels (L) should not need Remove screw (O1) and cover (O2) from roller this additional adhesive. assembly (O).
  • Page 15 CAUTION CAUTION Inside door / Puerta interior To reduce the risk of personal injury or glass breakage, all To reduce the risk of personal injury and glass breakage, all seal components must be installed during assembly and use. bushings and gaskets must be installed as instructed. PRECAUCIÓN PRECAUCIÓN Todos los componentes de sellado se deben instalar durante el...
  • Page 16 CAUTION CAUTION CAUTION Risk of injury or product damage. During installation, tempered Risk of injury or product damage. Risk of injury or product damage. glass should not come in contact with metal parts or hard surfaces • During installation, tempered glass should not come in contact •...
  • Page 17 Risk of injury or product damage. During installation, tempered glass should not come in direct contact with metal parts or hard surfaces (such as tile/concrete flooring) or it may shatter. CAUTION PRECAUCIÓN CAUTION Outside door / Puerta exterior Risk of injury or product damage. During installation, tempered To reduce risk of personal injury and glass breakage, screws and Riesgo de lesión o daño del producto.
  • Page 18 Distance from bottom of glass panels to top of sill should be CAUTION between 0.25" (0.6 cm) - 0.375" (1.0 cm). NOTE: For optimal water retention, the inner panel should be closest Risk of injury or product damage. During installation, tempered to the shower head.
  • Page 19 Carefully slide both door panels to the left and install center CAUTION Raise damper catch / guide right bracket (C4) onto end of center guide (C) securing with screw (C5). Elevar el enganche To reduce the risk of breakage, which may result in personal injury, del amortiguador Hand tighten until secure using provided 2.5mm hex wrench.
  • Page 20 CAUTION CAUTION To reduce the risk of personal injury or glass breakage, all To reduce the risk of personal injury or glass breakage, all bushings and gaskets must be installed as instructed. bushings and gaskets must be installed as instructed. PRECAUCIÓN PRECAUCIÓN Para reducir el riesgo de sufrir lesiones personales o de que se...
  • Page 21 CAUTION: Do Not force the door panel to move, as doing so may result in breakage and risk of injury. If the following steps do not resolve the curing time. associated symptoms or for any questions, call Delta Shower Door Customer Care Team at 1-800-964-4850. Utilice masilla de silicona transparente para sellar el interior de la...

  • Page 22: Solución De Problemas

    PRECAUCIÓN: No fuerce el panel de puerta al mover, de hacerlo puede romperse y provocar lesiones. Si los siguientes pasos no resuelven los síntomas asociados, o en caso de preguntas, llame a atención al Delta Shower Doors Customer Care Team al 1-800-964-4850.
