RALLYSAFE RALLY CAR FITTING KIT MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the RALLYSAFE and is the answer not in the manual?

Questions and answers

Summary of Contents for SAS RALLYSAFE

  • Page 1 RALLYSAFE RALLY CAR FITTING KIT MANUAL...
  • Page 2 P a g e RallySafe® Fitting Kit Manual – RALLY CAR Contents of Manual 1. RallySafe Fitting Kit Components 2. 12 Volt Power Supply 3. Connection Diagram 4. Antenna Installation 5. Internal WiFi 6. Unit Installation 7. Fitting Kit Care Instructions...
  • Page 3 Due to continuous ongoing development, information and specifications may change at any time without notice. RallySafe, and the companies that have contributed to it, shall not be liable for any use of the manual or information supplied.

  • Page 4: Connection Diagram

    12 Volt Power Supply (Please read carefully) RallySafe requires a continual reliable power supply from 9 to 28 volts DC. For your safety and continuity of service, it is imperative that the unit is connected to an un-switched supply on the battery’s positive terminal or the battery’s positive side of the isolation switch.

  • Page 5: Antenna Installation

    RallySafe unit location. The antenna is a semi water-resistant unit which adheres to the roof surface. (High pressure water against the antenna may cause damage, please be mindful when washing interior and exterior of vehicle –...
  • Page 6 Stick-on Antenna (Alternative): The antenna is mounted on the ROOF of the vehicle, preferably within easy cable reach of the final RallySafe unit mounting position allowing the cabling to then pass through the door seal and follow the cage bars back to the RallySafe unit location.

  • Page 7: Unit Mounting

    P a g e Unit Mounting The preferred methods for mounting the RallySafe unit are listed below: • RAM Flat Mount Base (50mm x 75mm) with ball, bolted through the dash with a 3mm aluminum backing plate. It should be in a central, protected location, and be easily visible and accessible by both the driver and co-driver/nav.
  • Page 8 Care must be taken to protect the roof-top antenna, unit-end antenna connections and power lead unit connection when a vehicle is washed before/after an event. In-house testing at RallySafe has shown that a single drop of water inside the unit-end connectors will cause communication failure.
