- Page 1 Teletube Sensor probe parts list and Assembly guide SR-TT-AG-2407 V1.2...
- Page 2 Rheonics. The information contained in this manual is subject to change without notice. TRADEMARKS Rheonics is a trademark of Rheonics, Inc. Other product and company names listed in this manual are trademarks or trade names of their respective manufacturers.
- Page 3 SR-Teletube Assembly Guide SR-TT-AG-2407 Table of Contents About Rheonics Teletube Sensors ..................... 3 Rheonics Teletube Sensor Probe - Parts List ................4 Assembly Tools Included ......................5 Assembly Instructions ........................ 6...
-
Page 4: About Rheonics Teletube Sensors
SR-TT-AG-2407 About Rheonics Teletube Sensors For installations where the insertion length required for the Rheonics SRV or SRD sensors is ultra- long (above 600mm), Rheonics offers the Teletube sensor variants. This variant allows the unit to be delivered in smaller parts that are assembled by the user prior to final installation on site. -
Page 5: Rheonics Teletube Sensor Probe - Parts List
SR-Teletube Assembly Guide SR-TT-AG-2407 Rheonics Teletube Sensor Probe - Parts List The next table details all parts that can be used for the assembly, depending on the sensor configuration some parts may not be included and quantities can vary. Part... -
Page 6: Assembly Tools Included
Note: The OR-TT is a standard O-Ring that is used for sealing all the G threaded in the Teletube assembly. This is available in various materials from Rheonics and third-party O-ring suppliers. Order the correct O-ring material that is compatible with your process fluid and operational temperature. -
Page 7: Assembly Instructions
SR-Teletube Assembly Guide SR-TT-AG-2407 Assembly Instructions Instruction Drawings Pictures Verify all parts for assembly and tools to be used. I. Prepare extension Tubes: If only one extension tube EXT-TT is delivered, no preparation is required, go to step 5. If multiple EXT-TT parts are delivered, follow next steps. Identify female and male G3/4”... - Page 8 SR-Teletube Assembly Guide SR-TT-AG-2407 Thread in the G3/4” male and female port until faces get in contact and O-Ring is compressed. Hand tightening is enough. Repeat the process (step 2 to 4) for all EXT-TT delivered in the assigned order. If there is a tube with a process connection, this one will be the last in...
- Page 9 SR-Teletube Assembly Guide SR-TT-AG-2407 B. For -TT-TR only Thread in the AT-TT G3/4” female port to the last EXT-TT G3/4” male port II. Sensor probe and cable Insert the sensor cable through the assembled extension tube. NOTE: If you used the AT-TT part the back-end will look different.
- Page 10 SR-Teletube Assembly Guide SR-TT-AG-2407 Thread in the sensor cable M12 connector to the M12 port at the sensor probe back end. Use the TOW-M12 tool for a secure connection Apply some TLG paste in the male G3/4" threads of the sensor probe. Not applicable for rentals.
- Page 11 SR-Teletube Assembly Guide SR-TT-AG-2407 A. For -TT-CAB Pass the cable through the CG-TT Cable Gland, add PTFE tape to the thread, and thread it in the AB-TT NPT 1/2” port. Your probe is now ready. Once assembly is installed, connect the sensor cable to the appropriate electronics unit (SME-XXX).
- Page 12 Tel: +1 713 364 5427 Website: https://rheonics.com ©2024 Rheonics, Inc. All rights reserved. Support Portal: https://support.rheonics.com The Rheonics logo is a trademark and service Support E-Mail: support@rheonics.com mark of Rheonics Inc. Photographs, excerpts, Sales E-Mail: info@rheonics.com trademarks, and logos are not endorsements and are used only for representation under fair use copyright laws.
