Kohler Archer K-1122-GHRAW Manual

Features
•
Bask heated surface creates spa-like relaxation with
®
soothing warmth on your back, shoulders, and neck
•
Three heat settings allow you to customize the surface
temperature
•
120 airjets release thousands of heated bubbles that
surround and support the body in a warm massage
•
Automatic and manual purge cycles remove residual water
from air channels after use
•
Variable-speed blower lets you adjust massage intensity to
18 levels
•
Comfort Depth design offers a convenient 19" step-over
®
height while retaining the same depth as a standard 21" bath
•
Integral lumbar support
•
Slotted overflow allows for deep soaking
•
Integral apron
•
Integral flange helps prevent water from seeping behind wall
and simplifies alcove installation
•
Textured bottom surface
•
Coordinates with other products in the Archer collection
•
Built-in 600W BubbleMassage
before it enters the bath
•
Automatic and manual purge cycles remove residual water
from air channels after use
•
Built-in 60W electric heater included to keep bath surface
warm
Material
•
Acrylic
Technology
•
Auto-shutoff timer on blower allows users to enjoy Heated
BubbleMassage experience for 60 minutes before turning
™
off
•
User interface: two separate electronic keypad controls for
Heated BubbleMassage
Installation
•
Right drain
•
Alcove
Required Products/Accessories
K-7271 Brass Slotted Overflow Bath Drain
or
K-7272 PVC Slotted Overflow Bath Drain
Recommended Products/Accessories
K-23726 Drain treatment
K-23732 Tub & shower cleaner
K-31797 Slotted overflow bath drain kit
1-800-4KOHLER (1-800-456-4537)
K-31795 Slotted overflow above-the-floor bath drain kit
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to
7-8-2024 23:01 - US
60" x 32" alcove Heated BubbleMassage
heater warms humidified air
™
and Bask
™ ®
www.kohler.com
with Bask heated surface, right drain
®
Codes/Standards
ASME A112.19.7/CSA B45.10
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
UL 1795
CSA C22.2 No. 218.2
ADA
ICC/ANSI A117.1
IAPMO Certification
cUL Listed
UL Listed
KOHLER Plastic Baths and
®
Shower Bases Lifetime Limited
WarrantyKOHLER
Components Five-Year Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
NY Dune
95 Ice™ Grey
58 Thunder™ Grey
7 Black Black™
USA or www.kohler.ca Canada
Archer
air bath
™
K-1122-GHRAW
Hydrotherapy
®
®
