F-1HD-1D-TVI-TX/RX
Quick Setup Guide
Step 1: Connect Power
Connect Included Power Supplies to Transmitter (T) and Receiver (R)
"PWR" LEDs on both T and R indicate power is properly connected
Step 2: Connect Fiber
Connect Transmitter to
Receiver using Single
Mode Fiber (Not Included)
Distance up to 120km
"FIBER" LEDs on both T and R indicate fiber is properly connected
