Page 1: Table Of Contents
Standard Installation & Troubleshooting PDD-10R-Wi-FF Wireless Underfloor Air Terminal (Variable Volume) Control Locations & Initial Setup ......2 Pairing Process ............3 Installation Process ..........4 Maintenance & Commissioning Mode ......5 General Troubleshooting & Red LED Status ....6 Index (Indicators & Functionality) ......7-8 Diffuser Troubleshooting ..........9 IC / FCC Compliance...
Page 2: Control Locations & Initial Setup
(table, etc.) with the diffuser grille face-up (matching installation orientation). A maximum of thirty-two (32) diffusers can be connected in a single zone. FIGURE 1 AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 3: Pairing Process
Repeat Steps 2 & 3 for each remaining diffuser, until all diffusers in the zone are paired (up to a maximum of 32). AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 4: Installation Process
FLOOR PANEL It is recommended by manufacturer to place receiver antenna with wire FIGURE 3 connection face-up as shown. AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 5: Maintenance & Commissioning Mode
To exit ‘Identify Mode’, press the button the concentrator and the LED will stop blinking. Within 5 minutes, the LED on the diffusers will turn off and the diffuser will resume normal operation. AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 6: General Troubleshooting & Red Led Status
LED flashes five (5) times Motor control board issue Replace motor control board every 4 seconds AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 7: Index (Indicators & Functionality)
Clears all stored network information, then Factory Reset > 10 Seconds No LED State Specified returns to idle mode. AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 8 No LED State Specified returns to idle mode. * NOTE: flashing only occurs in Pairing Mode or Identify Mode. AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 9: Diffuser Troubleshooting
If motorized damper plate still doesn’t move, disconnect the battery and replace the motor. If wireless diffuser still does not function correctly, please contact the manufacturer for additional technical support. AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
Page 10: Ic / Fcc Compliance
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. PRODUCT PATENTED AirFixture ©2023 AirFixture, LLC 51 Kansas Avenue | Kansas City, KS 66105 | P: 913.312.1100 | F: 913.312.1105 | www.airfixture.com V230403...
