1. Specifications
Working temperature: -20°c to 60°c
Output: 3-5 channels
Grayscale: 1024 levels
External dimension: L160*W46*H25 mm
(L6 1/4*W1 3/4*H1 in)
RF frequency: 2.4GHz
Short circuit protection: Yes
PWM frequency: 2KHz, 21.6KHz
TUYA APP for IOS/Andriod
2. Controls, indicators and connections
Key
Button
Dip
Switch
Power
1. Signal indicator status and description: it will light up when operating the remote control; it wil stay on after a
successful WIFI connection.
2. DIP switches 1 through 3 are used to set the load output type, corresponding to the following:
DIM
1
2
3
OFF
OFF
OFF
Note: After setting the load output type, the WIFI control function needs to be reset, and the "add device"
operation should be preformed again in the APP. If the type is switched in the power-on state, the contoller will
automatically reset, and will directly enter the EZ distribution network state after the load light flashes quickly.
For more connection instructions, please refer to the "Direction for use - WIFI Network Operation" section.
3. DIP switch 4 is used to set the PWM frequency of the load output: OFF-2KHz (factory default value),
ON-21.6KHz as per the following diagram
Operation Instructions of WIFI Controller
MODEL: GL-RFCONT-RGBW-TU
RF 2.4GHz/Tuya APP Control
Input/Output Voltage: 12-24VDC
Max. Output of Current: 4A*5CH
Wireless-sync-controlled
Scan Install APP
Made in P.R.C
CCT
4
1
2
3
4
X
ON
OFF
OFF
X
PWM=2KHz
1
X
Default
2-1698 Cary Road, Kelowna, BC, V1X 2B9
(250) 878-3542 | info@glimmerlighting.com | www.glimmerlighting.com
WIFI LED CONTROLLER (12/24 VOLT)
Supply voltage: DC12~24V
Connecting Mode: Common anode
Speed stage: 1024 levels
Net weight: 110g
RF distance: <20m
Memory function: Yes
Max. Output current: PWM=2KHz:4A/CH, PWM=21.6KHz:3A/CH
Max. Output power: 12V: <240W, 24V:<480W
Or at 12 volts 48 watts/channel
24 volts 96 watts/channel
WIFI LED CONTROLLER
tc:85°C
ta:-20°C~45°C
8mm wire preparation
1~2.5²/17~13AWG
Fig. 1
RGB
RGBW
1
2
3
4
1
OFF
ON
OFF
X
ON
ON
PWM=21.6KHz
2
3
4
1
2
3
X
X
OFF
X
X
X
PART NUMBER: GL-RFCONT-RGBW-12V
RGBCW
2
3
4
1
2
3
OFF
X
X
X
ON
4
ON
Output
4
X
1
Advertisement
Summary of Contents for Glimmer LIGHTING GL-RFCONT-RGBW-12V
- Page 1 WIFI LED CONTROLLER (12/24 VOLT) PART NUMBER: GL-RFCONT-RGBW-12V Operation Instructions of WIFI Controller 1. Specifications Supply voltage: DC12~24V Working temperature: -20°c to 60°c Connecting Mode: Common anode Output: 3-5 channels Speed stage: 1024 levels Grayscale: 1024 levels Net weight: 110g External dimension: L160*W46*H25 mm RF distance: <20m...
- Page 2 WIFI LED CONTROLLER (12/24 VOLT) PART NUMBER: GL-RFCONT-RGBW-12V 3. Direction for use 1) WIFI controlled by Tuya Application for smart control. ie: group control, scene control, timer control, music control and so on. Scan QR code from controller to download Tuya application (page 4) Create an account or register your controller to an existing account WiFi- Smart Controller can be added using “EZ Mode”...
- Page 3 WIFI LED CONTROLLER (12/24 VOLT) PART NUMBER: GL-RFCONT-RGBW-12V 3) Wireless-synchronization function RF remote will transmit a control signal to eachother. Multiple receivers in same zone will wirelessly sync. Not only static mode, but also dynamic mode, to achieve wired-like operation experience. It is flexible enough to com-...
- Page 4 WIFI LED CONTROLLER (12/24 VOLT) PART NUMBER: GL-RFCONT-RGBW-12V Application Circuit of RGB MODEL NUMBER: GL-RFCONT-RGBW-TU WIFI LED CONTROLLER MODEL: GL-RFCONT-RGBW-TU RF 2.4GHz/Tuya APP Control Input/Output Voltage: 12-24VDC Max. Output of Current: 4A*5CH Wireless-sync-controlled tc:85°C ta:-20°C~45°C 8mm wire preparation Scan Install APP Made in P.R.C...
