User Manual

UE Series Drawing Monitor

Need help?

Do you have a question about the UE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UGEE UE Series

Page 1 User Manual UE Series Drawing Monitor...
Page 2 01/ Product Description 1.1 Product Overview 1.1.1 Drawing Monitor ① Indicator Light...
Page 3 a. Press the power button to turn it on, and then the blue light will be steady on, and press the power button again to turn it off b. Standby status, the light will be steady orange c. To enter the Drawing Tablet mode, you need to long press the power button for 3 seconds, and then light will flash blue and orange alternately.
Page 4 1.2 Connection 1.2.1 USB-C Connection Please connect the computer and the drawing monitor via theUSB-C to USB-C cable. lf the drawing monitor does not light up,please connect the drawing monitor via the USB-A to USB-C cableto the power adapter for power supply.
Page 5 1.2.2 3-in-1 Connection * Image is for illustration only * The 3-in-1 cable is not a standard and needs to be purchased separately. This cable is specifically designed for this product, please purchase it through official channels. Cables purchased through other channels may not be able to be inserted into the machine for normal use.
Page 6 *Image is for illustration only *For compatible phone models, please refer to the official website information 1.3 System Compatibility Windows 7 or later Mac OS X 10.12 or later Android 10.0 or later（USB3.1 DP1.2） Chrome OS 88 or later Linux...
Page 7 2) Navigate to the download page, then download and install the latest driver according to your device model. 3) After the driver is installed, a ugee icon will appear on the computer desktop. Run the driver program and set parameters. And test the product functionality.
Page 8 2.2.2 MacOS Unzip the file and run the .dmg file. Follow the steps below to install the driver.
Page 9 Step 1: Continue Step 2: Continue...
Page 10 Step 3: Accept Step 4: Install...
Page 11 Step 5: Enter password Step 6: Install driver...
Page 12 Step 7: Installation complete 2.2.3 Linux Deb: Enter the command "sudo dpkg -i", drag the installation file to the window, and execute the command. Rpm: Enter the command "sudo rpm -i", drag the installation file to the window, and execute the command.
Page 13 Tag.gz: Unzip the file, enter the command "sudo", drag install.sh to the window, and execute the command. 2.3 How to Use Driver 2.3.1 Connect to Device The driver will run automatically after being installed. If it does not run automatically, go to the driver folder and run it manually. Windows program path: Start→ugeeTablet Mac program path: Application→ugeePenTablet→ugeeTablet If the device is not connected or the connection fails, you will see the following...
Page 14 If the device is connected successfully, its product model will be displayed in the bottom right corner of the display, for example, EX12 as shown in the image. You can connect multiple devices via the driver at the same time. Click on drop- down menu to select device to activate.
Page 15 2.3.2.1 Pen Shortcuts Click the target button to open a pop-up window and customize key functions. You can select five types of shortcut keys: Mouse, Keyboard, Device, Run Application, and Disable. Mouse Control: Set mouse and keyboard combination keys. For example, if you select Shift and Left Click, you can execute the assigned shortcut command if the software supports this key combination.
Page 16 Keyboard: Set keyboard shortcut. For example, set it as Alt+A in 3D MAX so the alignment tool can be used. Clear: Clear all combination keys in the input box Delete: Delete the last combination key...
Page 17 Device: Execute selected function. Precision mode: It limits the Work Area to a small area. This function allows you to draw more precisely in the area. Run Application: Run the selected application. Pen pressure: After checking, you will not feel the pressure of the stylus when using it. Tilt: After checking, this will disable the tilt effect of the stylus.
Page 18 Windows Ink (for Windows only): Windows supports handwriting functions. If you need to use this function in Microsoft Office/Whiteboard or other software, please do not turn it off. 2.3.2.2 Pen Pressure Settings The sensitivity of the pressure can be adjusted by modifying the Pen Pressure curve or using preset pressure options.
Page 19 Screen: If multiple monitors are used in copy mode, the Work Area of the device will be mapped to all monitors. When the pen moves in the Work Area, the cursor on all monitors will move simultaneously. If multiple monitors are used in extended mode, go to monitor tabs to select one of the monitors that the Work Area of the device will be mapped to.
Page 20 There are two available options to set the monitor mapping area: Drag to select: Drag the cursor from one point to another on the Screen icon. Select screen area: Click once. Follow the prompt and select the upper left corner position and lower right corner position. Show monitor number: Identify all connected monitors.
Page 21 There are two ways to customize the handwriting area. Drag to select: Drag the cursor from one point to another on the Device . Select handwriting area: Click once. Follow the prompt and select the upper left corner position and lower right corner position with your stylus. Calibration Click on the crosshair cursor at the prompted position to calibrate the offset between the stylus and cursor.
Page 22 Rotation settings: You can set the device to 0 ° , 90 ° , 180 ° or 270 ° . Rotate the device to the corresponding direction after setting the rotation. 2.3.3.2 Pen Tablet/Display Shortcut Keys The position and number of keys will differ due to product model. EX12 is used here for illustrative purposes.
Page 23 2.3.3.3 Display settings Adjust the drawing monitor's color temperature, brightness, and contrast. 2.3.3.4 Desktop shortcut keys It is a module of shortcut keys displayed on the ugee drawing monitor or computer display (for the ugee drawing tablet).
Page 24 After the driver is installed, it can also be activated by the physical shortcut key on the drawing monitor/tablet (which can be customized in the driver shortcut key settings). For example: The default K8 button on the ugee UE16 drawing monitor can enable or disable the desktop shortcut key.
Page 25 2.3.4 Driver Settings Message: After closing, the key status prompt will not be displayed at the bottom of the screen when a key is pressed. Shortcut keys: After closing, disable the functions of all keys on the device.
Page 26 Import config: You can import configured shortcut keys and other settings. Export config: Export saved settings in a configuration file. A pop-up window will appear to notify you when the configuration file has been exported successfully. Diagnostic tool: If you encounter any issues while using the driver, please use the diagnostic tool to check hardware/environmental data for troubleshooting.
Page 27 settings, to their default values. Video tutorials: After clicking, navigate to the "Watch Tutorial" page through the computer's browser. User manual: After clicking, navigate to the "Search Model" page on the official website through the computer's browser. After clicking, navigate to the "FAQ" link on the official website through the computer's browser.
Page 28 and select the application path. Next, click OK to add the selected application. 2.3.5.2 Delete Application Click on the drop-down menu and select the application. Then click on the "x" in the top right corner to delete the application. 2.4 Uninstallation 2.4.1 Windows Go to Start ->...
Page 29 2.4.3 Linux Deb: Enter command sudo dpkg -r ugee-pentablet and execute the command. Rpm: Enter command sudo rpm -e ugee-pentablet and execute the command. Tag.gz: Unzip file. Enter command sudo. Drag uninstall.sh to the window and...
Page 30 3.1 The drawing software cannot detect pen pressure. Please confirm if the drawing software supports pen pressure. • Visit the ugee website to download and install the latest driver and test • if the pen pressure is working normally. Before installation, please close all antivirus and graphics software.
Page 31 If the signal is unstable, check if the cable connections are secure. • 3.4 The computer cannot recognize the device. Check if the computer's USB port is functioning properly. If there is an • issue, try using a different USB port. 3.5 The drawing pen is not working.

This manual is also suitable for:

Ue12 Ue12 plus Ue16
