- Page 1 SEC America Corp. Model 822 PS Pump Sentry Model 1622 PS Pump Sentry Owner's Manual October 28, 2021...
-
Page 2: Table Of Contents
Index Page Quick Installation & Battery Essentials………………….. Precautions and Sequencing During Initial Hookup…. How Pump Sentry Works……………………………..…….. Important Safety Instructions……………………………..Safety Warnings……………………………………………… Battery Precautions………………………………………….. Battery Box……………………………………………………. Installation Location…………………………………………. Making Connections…………………………………………. Installation Test………………………………………………. Changing the Battery………………………………………… Charger Functions.…………………………………………… Uninterruptible Power Indicator …………………………… Fan Operation …………………………………………………... -
Page 3: Quick Installation & Battery Essentials
Pump Sentry ® Models 822 PS & 1622 PS INSTALLATION INSTRUCTIONS QUICK INSTALLATION & BATTERY ESSENTIALS Pump Sentry is designed to operate with an external battery or battery bank ® whose nominal operating voltage is 12V, and whose single or combined A- Hr. -
Page 4: Precautions And Sequencing During Initial Hookup
PRECAUTIONS & SEQUENCING DURING INITIAL HOOKUP a) Secure Pump Sentry in its designated spot. It is recommended that the ® unit be placed on a shelf or mounted to a wall. b) Make sure the ON/OFF switch is in the OFF position and that the Pump Sentry power cord is not plugged into an AC outlet. - Page 5 ® we recommend its installation be made by a licensed electrician or fully qualified professional. Read these instructions completely and follow directions carefully. Pump 12 Volt Battery 1622PS/822 PS Figure 1 AC Utility Power...
-
Page 6: How Pump Sentry Works
How the Pump Sentry Works ® When electricity is present, the Pump Sentry charges a 12-volt battery and ® surveys the power line. At the instant that a power failure occurs, the Pump Sentry converts the energy stored in the battery to AC power to operate ®... -
Page 7: Safety Warnings
ELECTRICAL SHOCK HAZARD This unit has not been evaluated for use outdoors. Never operate Pump Sentry outdoors. Never operate Pump Sentry with battery enclosure open. ® Never operate Pump Sentry in a wet location. ® Never operate Pump Sentry in a location where liquid or moisture will ®... -
Page 8: Battery Precautions
FAILURE TO COMPLY WITH THE ABOVE WARNINGS COULD RESULT IN INJURY OR DEATH BATTERY PRECAUTIONS: WARNING: IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. 1. Servicing of batteries should be performed or supervised by a person knowledgeable about batteries and the required precautions. Keep unauthorized personnel away from batteries. -
Page 9: Battery Box
A. Wear full eye protection and clothing. B. If electrolyte comes in contact with the skin, wash if off immediately. C. If electrolyte comes in contact with the eyes, flush thoroughly with water and seek medical attention immediately. 6. CAUTION – Lead acid batteries can present a risk of fire and explosion because they generate hydrogen gases. -
Page 10: Making Connections
VENTILATION Do Not block either the fan or the exit air ports of the Pump Sentry ® Allow at least 2 inches of air clearance on all sides. Any room in which the Pump Sentry is mounted should have adequate ventilation. ®... -
Page 11: Installation Test
WARNING! A spark may occur when connecting the second cable. This is normal. An explosion hazard may exist if flammable liquid or gas is present. INSTALL AND OPERATE PUMP SENTRY IN A WELL VENTILATED AREA ONLY. Plug your pump into the Pump Sentry’s AC outlet. ... -
Page 12: Changing The Battery
CHANGING THE BATTERY If for any reason the battery needs changing, it is important to follow the steps below, in the order shown to avoid damage to the Pump Sentry unit. ® 1. Turn the ON/OFF switch on the Pump Sentry to the OFF position. -
Page 13: Charger Functions
Charger Function s The smart charging system in Pump Sentry is microprocessor controlled to yield ® optimum charging rates and long battery life. When the electrical source is restored allowing the resumption of the charging process, there is a 2 second delay during which the charge state of the battery is assessed. After this delay, the bottom of the two LED indicators comprising the battery monitor will illuminate. -
Page 14: Uninterruptible Power Indicator
Uninterruptible Power Indicator The “Power Output” indicator shown in Figure #1 informs the user that AC power is present at the output receptacle providing power to the load. This LED is applicable to both the standby (AC line power present) and Back Up (Battery Power) states. This LED will be extinguished in the following situations: The main fuse is blown (in the Standby or Back Up states). - Page 15 Figure #2 Figure #1 Charger Fuse POWER OUTPUT Active When Lit Main Fuse Replace Battery Charged = ON Charging = Flashing BATTERY MONITOR When Utility AC is Down ALL Battery Indicators Are OFF Inverter ON/OFF SIDE VIEW TOP VIEW...
-
Page 16: How To Discern When Pump Sentry
How to Discern When Pump Sentry is Operational in the Backup Mode ® When all LED’s of the battery monitor are OFF, and the Pump Sentry is plugged into an ® AC outlet, the unit is in the back up mode. In this mode when there is sufficient energy in the battery to operate the system, the uninterruptible power LED is illuminated. - Page 17 If the audible alarm is found to be irritable, it may be turned off by simply turning off the ON/OFF switch of the Pump Sentry . IT IS IMPORTANT TO TURN THIS SWITCH ® BACK “ON” WHEN THE UNIT’S OPERATION IS REINSTATED. This should take place when utility power comes back on or after the battery has been replaced.
-
Page 18: Warranty
Pump Sentry 822 PS, 1622 PS ® Manufactured by SEC America Corp. S. Burlington, VT, 05403 Manufacturers Limited Warranty Pump Sentry is warranted to be free from defects in material and workmanship ® and to perform within applicable specifications for a period of two years after original shipment.
