Summary of Contents for Keebofly SBT-01
- Page 1 MOBILE VINYL RECORD STORAGE STAND （1009201） Customer service mail: hydservice2023@163.com Any question will be replied within 24 hours...
-
Page 2: Table Of Contents
PARTS Bracket 1 Bracket 2 Bracket 3 Bracket 4 Square Tube 5 Round Tube 6 Wooden Board Wooden Board Wooden Board Oxford Fabric HARDWARE Brake Caster M6*12mm Screw M6*28mm Screw M5*50mm Screw Caster Coarse wrench Thin wrench S4 Allen Key S3 Allen Key... - Page 3 PARTS OVERVIEW...
-
Page 4: Bracket 4
STEP 1 Bracket 4 Square Tube 5 M6*28mm Screw S4 Allen Key... -
Page 5: Wooden Board
STEP 2 Wooden Board Wooden Board Wooden Board M5*50mm Screw （1） （2） Side with metal hole upward Finished S3 Allen Key... - Page 6 STEP 3 Brake Caster M6*28mm Screw M5*50mm Screw Caster （1） （2） S4 Allen Key...
-
Page 7: X2 Bracket
STEP 4 Bracket 1 Bracket 2 Bracket 3 M6*12mm Screw Opposite Side Opposite Side Opposite Side S4 Allen Key... - Page 8 STEP 5 Step 3 Step 4 M6*12mm Screw S4 Allen Key...
-
Page 9: Oxford Fabric
STEP 6 Round Tube 6 Oxford Fabric M6*28mm Screw Oxford fabric go through the round tube （1） The black and rough surface upward （2） S4 Allen Key... - Page 10 NOTE Please check that all screws are tightened after installation. Finished...
