Summary of Contents for Percy Doughty & Co PENMAN AURUS
- Page 1 INSTALLATION INSTRUCTIONS AURUS WOOD BURNING STOVE AUR - REV A - 03/19...
-
Page 3: Table Of Contents
CONTENTS USER INSTRUCTIONS Page 4 Welcome General Cross section drawing Heating capacity Health and safety INSTALATION Page 7 Installation guide Installation notes & guide Positioning the appliance Flue installation Soapstone or ceramic covers OPERATING INSTRUCTIONS Page 9 General information Suitable fuels Reducing emissions Lighting the stove for the first time After use and maintaining perfect burn... -
Page 4: User Instructions
1.0 USER INSTRUCTIONS Welcome Thank you for your decision to buy an Olsberg Stove. The crackling, visible flames give you the sense of comfort and security. The combination of hot-air heating and heat radiation provides a pleasant and healthy climate in any room. The combined use of modern heating technology, excellent quality of materials and effective heat exchange, results in high efficiency and economical operation. -
Page 5: Cross Section Drawing
1.0 USER INSTRUCTIONS - REMOTE CONTROL Cross section drawing Primary air Secondary air ”Cold” air of room Warm air Escaping gases Hot gases Grate Chamotte or vermiculite lining 9/10 Tertiary air Charcoal pan PAGE 4... -
Page 6: Heating Capacity
1.0 USER INSTRUCTIONS 1.4 Heating capacity The heating capacity according to DIN 18893 standards is in m³, referring to buildings that do not comply with the Heat Insula- tion Regulation. For buildings complying with the mentioned regulation other values are valid (DIN 18893 -1). Make inquiries about further details at a specialized dealer or a responsible chimney sweep. -
Page 7: Instalation
2.0 INSTALLATION Installation guide This appliance must be installed by a competent person and the installation must comply with bs8303 –code of practice for installation of domestic heating and cooking appliances burning solid mineral fuel, national building regulations, local by-laws and standards and the requirements of the health and safety at work act - in particular: Handling: Adequate facilities must be available for loading, unloading and site handling. -
Page 8: Positioning The Appliance
2.0 INSTALLATION Positioning the appliance The technical data sheet and the type of board on the stove contain the data referring to the stove that might differ from these standard regulations. In case of combustible floors, being sensitive to a rise in temperature, non-combustible floor protectors must be used. This floor protector must reach 500mm beyond the front of the stove, 250mm to either side (measured form inside the combustion chamber). -
Page 9: Operating Instructions
3.0 OPERATING INSTRUCTIONS General information All national, regional, local laws, orders and regulations must be kept. Therefore, depending on the location of installation, spe- cial operating conditions and restrictions can be enforced regarding the period of use and fuels used. It is important to consult a chimney sweep or other competent expert before installing and using the appliance. -
Page 10: After Use And Maintaining Perfect Burn
3.0 OPERATING INSTRUCTIONS Lighting the stove for the first time (continued) The stove is painted in high quality heat resistant lacquer that gains its final stability during the first heating. The smell during the first heating derives from the evaporation of the protecting lacquer in the paint. As a precaution, the heated room should be well ventilated from time to time (every 1-2 hours). -
Page 11: Troubleshooting
4.0 TROUBLE SHOOTING General troubleshooting The condition of proper operation of the stove is the appropriate chimney draught (feed pressure). This is considerably de- pendant on the temperature of the outer environment. In case of higher outer temperature (above 15oC) feed pressure can considerably fall and it can disturb proper operation. -
Page 12: Special Notes
5.0 SPECIAL NOTES Notes Your guarantee expires immediately in case of extreme or long lasting overload above nominal capacity or the use of fuel not specified. Cleaning schedule (To be performed only when stove is cold) What Frequency Utensil Combustion chamber of stove Min. -
Page 13: Appendix 1 Dimensional Drawings
APPENDIX 1—DIMENSIONAL DRAWINGS PAGE 11... -
Page 15: Commissioning Checklist
COMMISSIONING CHECKLIST Ensure the serial number has been recorded on the front of this manual for any future use Ensure the door seals are in good condition and that the glass is secured correctly in the door (do not over tighten the glass as this will prohibit its expansion and could cause the glass to crack) Ensure that all internal components are fitted correctly (these may have shifted in transit) - Page 16 Brought to you by Imperial Point Express Trading Estate Stone Hill Road Farnworth Bolton BL4 9TN Tel: 01204 868 550 Fax: 01204 868 551 Email: sales@percydoughty.com www.penmancollection.com...
