Precision Flight Controls C2 Quick Setup Manual

Professional desktop flight console
Hide thumbs

Advertisement

Table of Contents

c2 professional
deskt
op flight console
quick setup guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C2 and is the answer not in the manual?

Questions and answers

Related Manuals for Precision Flight Controls C2

Summary of Contents for Precision Flight Controls C2

  • Page 1 guide...

  • Page 2: Table Of Contents

    CONTENTS 1 PRECAUTIONS AND WARNINGS 2 INTRODUCTION 3 INSTALLATION 4 INSTALLATION OF PFCUSBHID PLUGIN FOR X-PLANE 9.70 5 SWITCHING QUADRANTS 6 SWITCHING TO VERNIER CONTROLS 7 USBHIDPLUGIN OPTIONS 8 LIMITED WARRANTY INFORMATION...

  • Page 3: Precautions And Warnings

    THE DEVICE IS NOT A TOY. CHILDREN SHOULD NOT OPERATE IT WITHOUT ADULT SUPERVISION. ELECTRIC SHOCK / FIRE HAZARD. USE ONLY THE POWER SUPPLY PROVIDED BY PRECISION FLIGHT CONTROLS. MAKE SURE THAT THE DEVICE IS ON A FLAT STABLE SURFACE. FAILURE TO DO SO MAY RESULT IN THE DEVICE FALLING WHICH MAY RESULT BODILY INJURY, DEATH AND DAMAGE TO THE DEVICE.

  • Page 4: Introduction

    2 INTRODUCTION CONGRATULATIONS ON YOUR PURCHASE OF THE PFC C2 PROFESSIONAL DESKTOP FLIGHT CONSOLE! THE C2 PROFESSIONAL DESKTOP FLIGHT CONSOLE FEATURES TACTILE SWITCHES, ROBUST YOKE MECHANISM AND CAST ALUMINUM YOKES. THE YOKE MECHANISM FEATURES PRECISION BALL BEARINGS WITH SELF ALIGNING BUSHINGS THAT ENSURES SMOOTH AND REALISTIC FEEL THROUGH OUT THE CONTROL MOVEMENT.

  • Page 5: Installation

    3 INSTALLATION 1. CHECK PACKAGING FOR DAMAGE. DO NOT UNPACK ITEM IF THERE ARE ANY DAMAGE. REPORT ANY DAMAGE TO THE CARRIER AND PFC TECHNICAL SUPPORT. TAKE CLEAR PICTURE OF ANY DAMAGE AND EMAIL THE PICTURES TO techsupport@flypfc.com. 2. IF C2PRO IS UNDAMAGED. CAREFULLY LIFT IT OUT OF THE BOX. 3.
  • Page 6 4 SOFTWARE INSTALLATION THE C2PRO CONSOLE WILL REQUIRES TWO SOFTWARE FOR PROPER OPERATION. THE SWITCHES ON THE C2PRO CONSOLE WORKS WITH X-PLANE BY INSTALLING THE PFC USBHIDPLUGIN. THIS GUIDE ASSUMES THAT YOU HAVE PROPERLY INSTALLED THE X-PLANE 9.70 AND THAT YOU HAVE RUN IT AT LEAST ONCE PRIOR TO INSTALLATION OF THE PLUGIN.
  • Page 7 7. AFTER SELECTING THE FOLDER, CLICK ON NEXT. 9. NOW CLICK ON FINISH. 8. CLICK ON INSTALL IN THIS WINDOW...

  • Page 8: Switching Quadrants

    5 SWITCHING QUADRANTS THERE ARE 2 MAIN STYLES OF POWER CONTROL FOR THE C2PRO. THE QUADRANT STYLE AND VERNIER STYLE. PFC MANUFACTURES DIFFERENT QUADRANTS AND VERNIER CONTROLS FOR PISTON SINGLE AND TWIN, SINGLE AND TWIN TURBO PROP, ONE, TWO, THREE AND FOUR ENGINE JETS. SWITCHING TO STANDARD QUADRANT STYLE 1.

  • Page 9: Switching To Vernier Controls

    6 SWITCHING TO VERNIER CONTROLS 1. INSTALL A TWIN NON-VERNIER QUADRANT. (SEE SECTION 5 FOR STEPS) 2. REMOVE THE FOUR (4) SCREWS AROUND THE PANEL. 3. CAREFULLY PULL THE ASSEMBLY OUT. 4. DISCONNECT THE RJ-45 CABLE. 5. CONNECT THE RJ-45 CABLE TO THE VERNIER UNIT. 6.

  • Page 10: Usbhidplugin Options

    USBHIDPLUGIN OPTIONS THE USBHIDPLUGIN HAVE USER CONFIGURABLE OPTIONS THAT INCLUDES: ELEVATOR TRIM HAND TURN THIS CHANGES THE NUMBER OF ELEVATOR TRIM TURN FROM FULL NOSE DOWN TO FULL NOSE UP TRIM. ALT AIR SWITCH CHANGE ALT AIR FUNCTION FROM ALTERNATE STATIC SOURCE TO ALTERNATE ENGINE AIR SOURCE. AI REFERENCE CHANGE THE HORIZON BAR ADJUSTMENT TO WORK WITH ALL AIRCRAFT OR AIRCRAFT WITHOUT FLIGHT DIRECTORS ONLY.
  • Page 11 ACCESSING THE USBHIDPLUGIN MENU TO CHANGE ANY OF THE OPTIONS OF THE USBHIDPLUGIN, YOU MUST FIRST ACCESS THE USBHIDPLUGIN MENU. 1. WITH X-PLANE RUNNING, ACCESS THE X-PLANE MENU BY MOVING YOUR MOUSE TO THE TOP OF THE SCREEN. 2. FROM THE MENU CLICK ON THE “PLUGINS” MENU. 3.
  • Page 12 PILOT YOKE BUTTON AI REFERENCE THE PILOT YOKE BUTTON REFERS TO THE AUTOPILOT THE AI REFERENCE OPTION ALTERS THE HORIZON BAR ADJUSTMENT TO WORK WITH ALL AIRCRAFT OR ONLY DISCONNECT BUTTON ON THE YOKE. THIS OPTION AIRCRAFT WITHOUT FLIGHT DIRECTORS. CHANGES THE FUNCTION BETWEEN AUTOPILOT DISCONNECT OR PUSH TO TALK.
  • Page 13 PFC STANDARD THROTTLE QUADRANTS THE C2PRO CAN BE MATED WITH ANY OF THE PISTON, TURBO PROP AND JET QUADRANTS AS WELL AS ANY OF THE VERNIER STYLE CONTROLS THAT PFC MANUFACTURES. THE PFC STANDARD THROTTLE QUADRANT OPTION WILL ALLOW YOU TO CHANGE THE PLUGIN SETTING TO MATCH THE QUADRANT OR VERNIER CONTROL YOU HAVE INSTALLED ON THE CONSOLE.

  • Page 14: Limited Warranty Information

    8 LIMITED WARRANTY INFORMATION WHAT'S COVERED BY OUR LIMITED WARRANY PRECISION FLIGHT CONTROLS, INC. (HEREAFTER “PFC”) WARRANTS ITS HARDWARE PRODUCTS TO THE ORIGINAL OWNER TO BE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS WHEN USED PROPERLY FOR A PERIOD OF ONE (1) YEAR FROM THE DATE OF DELIVERY.
  • Page 15 WHAT WILL PFC DO IN THE EVENT OF A WARRANTY CLAIM (CONTINUED): IF PRODUCT IS RETURNED WITHIN THE WARRANTY PERIOD, BUT THE RETURN IS NOT RELATED TO DEFECT, A Ÿ REFUND WILL BE ISSUED LESS A FIFTEEN PERCENT (15%) RESTOCKING FEE. OBTAINING WARRANTY EVALUATION &...
  • Page 16 WITHOUT LIMITING THE FOREGOING, SELLER IS NOT LIABLE FOR BUYER'S IMPROPER USE, INSTALLATION, ACCIDENTS, OPERATION OR MAINTENANCE OF ANY PRODUCT OR OTHER ITEMS MANUFACTURED BY SELLER. Precision Flight Controls, Inc. | 2747 Mercantile Drive | Suite 100 | Rancho Cordova CA 95742 | T: 916.414.1310...
