Spears SP-Chain Tool Instructions

thank you for purchasing a Spears Racing product. Manufactured to a high standard, this product will, if used according
to these instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear protective
instructions gloves
1. Safety
WarninG! ensure Health and safety, local authority and general workshop practice regulations are adhered to when using tools and
‰
equipment.
Do not use if damaged.
8
maintain in good and clean condition for best and safest performance.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and unauthorised persons away from the work area.
9
ensure that the motorcycle is safely positioned and secured.
8
2. introDuction
Breaks and rejoins most types of chain quickly and easily. suitable for most sizes of drive or cam chain from #35 to #630. supplied with a
range of pins, dies and detailed instructions.
3. Specification
model ..........................................................SP-Chain-Tool
contents.................................................... Pins: 2.2, 2.9, 3.8.
..................................Pin Guide: 2.2mm upper, 2.2mm lower.
...................................................................Anvil: 3mm, 6mm.
....................................................................................spring.
.......................................................................... Press Plates.
..................................................................................... lever.
...................................................................................Handle.
...........................................................................chain Press.
4. operation
© Spears Enterprises/Spears Racing LLC
instructions for
Motorcycle chain breaker &
riveter
Wear safety
footwear
SP-Chain Tool
model no:
fig.1
SP-Chain Tool | issue 1 2018
