Summary of Contents for Luxman LX09-U007K Series
- Page 1 EV CHARGER USER MANUAL （ U Version : . ）...
-
Page 2: Table Of Contents
CONTENT Content 1. Safety Tips …………………………………………………………………………………… 2. Important Information ……………………………………………………………………… 2.1 Specified use …………………………………………………………………………… 2.2 About this Manual ……………………………………………………………………… 3. Use of Products ……………………………………………………………………………… Product Appearance Size ……………………………………………………………… 3.2 Product Appearance Introduction ……………………………………………………… Floor Mounted Appearance Size ……………………………………………………… Product Performance Description …………………………………………………… Equipment Parts List ……………………………………………………………………... -
Page 3: Safety Tips
.SAFETY TIPS IMPORTANT SAFETY INSTRUCTIONS WARNING: This manual contains important instructions for AC charger series that shall be followed during installation, operation and maintenance of the unit. a. Read all the instructions before using this product; b. This device should be supervised when used around children; c. -
Page 4: Important Information
. I MPORTANT INFORMATION . Specified Use ● This type of product is a charger that can charge electric vehicles in indoor and outdoor areas (such as electric vehicles). ● When installing and connecting the charger, the relevant regulations of the local country or government shall be observed;... -
Page 5: Use Of Products
.USE OF PRODUCTS . Product Appearance Size 255mm 126.5mm . Product Appearance Introduction [B]Display Screen [A]Surface Cover [D]EV connector Holder [C]Panel [F]Output Wire [E]EV connector [H]Bottom Shell [G]Input Wire [J]The Self-tapping screws [I]Fixing Plate [L]Emergency Stop Switch [K]Junction Box Cover [M]Waterproof Joint USER MANUAL... -
Page 6: Floor Mounted Appearance Size
.USE OF PRODUCTS . Floor Mounted Appearance Size [A]Pedestal [B]Display Screen [C]Charging Cable [D]EV connector [E]Input Wire [F]Wire protector [G]Column [H]Expandable Rubber Stopper ● The appearance shall be subject to the real object. ● When the charging operation is not performed, the charging cable shall be rolled up and put back into the cable slot. -
Page 7: Product Performance Description
.USE OF PRODUCTS . Product Performance Description Product Characteristics Product Item ZB -U K Series ZB -U K Series ZB -U K Series Output Power . kW Operating Current Operating Voltage L /L /PE； Vac(± %) ＜ . kg Product Weight Operating Frequency Hz±... -
Page 8: Equipment Parts List
.USE OF PRODUCTS Operating Temperature - ℃~+ ℃(- ℉~+ ℉） Storage Temperature - ℃~+ ℃ （- ℉~+ ℉） Operating Humidity %~ %RH Operating Altitude ＜ Protection Degree TYPE R Reliability MTBF Warranty Years Safety Standard ， UL - /- , UL . -
Page 9: Operation Guide
. OPERATION GUIDE . Operation Steps Open the charging seat If the green light Hold the EV connector and confirm that there flashes, the EV connector and connect the electric is no foreign matter is correctly connected vehicle Charging Procedure Scheduled RFID Card Plug and Charge... - Page 10 . OPERATION GUIDE Steps to Add the Device to the APP Download Method For iOS: Search for Smart Life in the Apple Store, then download and install it. For Android: Search for Smart Life in the Google Play Store, then download and install it.
- Page 11 . OPERATION GUIDE . . APP Current Switch Steps EV Charger EV Charger > > Charging current Charging current quick_start quick_start Step 1: Step : Current temperature > Current temperature 70℃ 21℃ > Charging Settings. Current CP State CP6 Connected Current CP State CP12 Not connecred Current.
- Page 12 . OPERATION GUIDE . . APP Timed Charging Steps EV Charger Charging mode selection Charging mode selection Real-time charge RealTime charging RealTime charging Fixed time charges Fixed time charges Time quantum 21:00 ~ next day08:00 Charging Delayed charging click to end charge Delayed charging Start time End time...
- Page 13 . OPERATION GUIDE 4.2. Charging Records on the APP EV Charger EV Charger Real-time charge Charging record Power 2024-3-14 Start time Charging time Charge Explanation : Explanation : min 11. 16:02 ~ 17:02 Swipe right to Charging Records. charge. Charging Users can view their Insert the charging charging history in...
-
Page 14: Installation Method
.INSTALLATION METHOD . Wallbox Installation Method . . The distance between the center of the wall drilling is shown in the figure, and the wall hole template is placed at a suitable height (the top surface of the wall hole template is at least . - Page 15 . INSTALLATION METHOD 5.1.3 Pass the cable through the waterproof connector, and lock it to the terminal according to the symbols on the junction box in order to ensure that the connection among the tension disc, the cable and the waterproof connector is completely fastened As shown in Figure A- （power cables), only for ZB K Series and ZB Series.
-
Page 16: Floor Mounted Installation Method
. INSTALLATION METHOD . Floor Mounted Installation Method . . . Floor Mounted general assembly drawing A- （Floor Mounted General Assembly Drawing） [A]Charger [B]EV connector [C]Cross pan head screwM * [D]Flat head self-tapping screwsφ [E]L-shaped fixing strip [F]Output Wire [G]Pan head self-tapping screwsφ [H]Fixing plate [I] Wire protector [J]Input Wire... -
Page 17: Specification Of Switch Socket
. INSTALLATION METHOD . . . The power supply in the cement foundation has been embedded in the cable at one end of the outlet, and the column is erected at a suitable position on the cement foundation . Mark the cement foundation through the four bolt holes in the column flange plate, drill holes with a diameter of mm with a hole depth of mm with an... -
Page 18: Installation Environment Requirements
. INSTALLATION METHOD . Installation Environment Requirements . . The installation position of the charger shall not be close to dangerous locations or areas such as water, oil and gas pipelines. The installation position shall be convenient for charging, the wiring length shall be shortened to reduce the energy consumption of cable resistance when laying lines. -
Page 19: Troubleshooting
. TROUBLESHOOTING . Troubleshooting Table Failure Causes and Solutions ● Check the power supply and cables to make sure they are not damaged in any way and properly connected and that the power supply is working properly. Unable to turn on ●... - Page 20 . TROUBLESHOOTING Causes and Solutions Failure ● Indicates that the charger input voltage is below the limit Vac(min). ● Contact an electrician to confirm that the supply voltage is The screen displays normal. "Low voltage fault" ● Please check whether the power supply load capacity is sufficient.
-
Page 21: Maintenance
. MAINTENANCE . Maintenance ● The following routine maintenance items are only for reference, please refer to relevant standards and operation instructions for operation; ● Sunshade and rainproof measures shall be taken for the charging pile, and it is recommended to install a canopy outdoors;... -
Page 22: Model Number Definition
. MAINTENANCE Model Number Definition Product flow （ ） Cable length； by A to Z (As shown in . . ) Charging method； by A to Z (As shown in . . ) Motherboard version； by A to Z (As shown in . . ) Product power Country of use Product design flow... - Page 23 . MAINTENANCE . . Code Table for Version of AC Pile Main Board Mother board Bluetooth Bluetooth Basic Edition hardware version WiFi version version Code Notice a. The charger must be grounded through the grounding conductor of the permanent wiring system or equipment;...
- Page 24 . MAINTENANCE k. If your EV is covered with a car cover or a car coat, please remove it before charging the car; l. Users may affect or impair the function of the charger during usage if he/she wears any medical or implantable electronic device, such as cardiac defibrillators, pacemakers, etc;...
