  • Page 2 Always keep the manual ready. We have been seeking advancements in product design and quality. Therefore, even when this manual contains the latest production information available at the time of printing, there may be minor discrepancies between your scooter and this manual. If you have any question concerning this manual, contact your Linhai dealer.
  • Page 3 Congratulations on your purchase of new Linhai ADV Buck 125 scooter. This model conforms to the latest international emission standards, and meets the demands for the development of the modern society. This model is the result of Linhai’s vast experience in the production of scooters and sport, racing and touring motorcycles. Please read this manual carefully to enjoy all the benefits of your scooter.
  • Page 4 This manual uses the following symbols and terms to identify particularly important information: ⚠ DANGER The Safety Alert Symbol indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. ⚠ WARNING Failure to follow WARNING instructions COULD result in severe injury or death to the vehicle operator or others. ⚠...
  • Page 5 WARNING LABELS Warning labels on the scooter warn you of potential hazards that could cause serious injury or they provide important safety information. Read these labels carefully and don’t remove them. Warning label on central panel: ⚠ WARNING For the sake of your safety and that of other people, please read the operation and maintenance manual carefully before operating your motorcycle.
  • Page 6: Table Of Contents

    CONTENT Replacing the Key Fob Battery ............. 19 CONTENT ........................6 Indicators and Warning Lights ..............20 IMPORTANT SAFETY INFORMATION ............. 10 ABS Indicator ..................20 DESCRIPTION ....................... 13 Traction control (TCS) indicator ..........20 Left View ......................13 Right View ......................14 Engine temperature warning light ...........
  • Page 7 Take the helmet off the hooks: ............. 29 Horn ......................24 Engine Stop Switch ..................24 Front storage compartment ..............29 Underseat storage compartment ............. 30 Hazard Switch ..................24 Rear suspension....................31 Side stand ......................31 START Button ..................24 Center stand ....................
  • Page 8 Spark plug removal ..................42 Wheels ........................51 Spark plug inspection ................42 Front/Rear brake inspection ..............52 Spark plug installation: ................43 Front /Rear brake pad inspection ............52 Engine oil and oil strainer ............... 44 Brake fluid inspection ................53 Engine oil level inspection ..............
  • Page 9 LED Turn signals/Tail/Brake/Position light replacement ... 60 Rear view mirrors ..................60 Troubleshooting ....................61 Troubleshooting chart ................62 1. Fuel ........................62 2. Compression ....................62 3. Ignition ......................62 4. Battery ......................62 CLEANING AND STORAGE ................63 Cleaning......................
  • Page 10: Important Safety Information

    OWNERS MANUAL IMPORTANT SAFETY INFORMATION ⚠ DANGER ● This scooter is not a toy and can be dangerous. Be careful when driving or performing maneuvers. ● Read this manual carefully to know all the functions and features of your scooter. ●...
  • Page 11 ● Use hazard lights when you need to alert others of a possible danger, such as a traffic jams, accident or temporary parking. ● Never carry more than one passenger and make sure he/she has the necessary knowledge about how to ride on the scooter. ●...
  • Page 12 ● If any warning label on the scooter comes off or becomes hard to read, contact your Linhai dealer for replacement. Failure to follow these warnings increases the possibility of accident and, consequently, serious injury and death.
  • Page 13: Description

    DESCRIPTION Left View 1. Fuel tank 6. Air filter 2. Side stand 7. Tail light / Brake light 3. Seat 8. Rear turn signal 4. Center stand 9. Final drive oil filler cap 5. OBD interface 10. Rear wheel [Kategorie]...
  • Page 14: Right View

    Right View 1. Exhaust muffler 6. Passenger footrest 2. Battery 7. Front turn signal 3. Underseat compartment 8. Position light 4. Engine oil filler cap 9. Headlight 5. Rear suspension 10. Front wheel [Kategorie]...
  • Page 15: Meters And Controls

    Meters and Controls 1. Rear brake lever 5. Front brake master cylinder 9. Throttle grip 2. Left handlebar switch 6. Instrument panel / LCD display 10. Main switch/Steering lock 3. Rear brake master cylinder 7. Right handlebar switch 11. Front storage compartment 4.
  • Page 16: Vehicle Identification

    VEHICLE IDENTIFICATION PARTS AND THEIR FUNCTIONS Vehicle identification number Main switch / Steering lock The vehicle identification number is located on the rear Main switch/ Steering lock controls the ignition and lighting systems, and locks the steering. After you center section of the frame. unlock the scooter (either by pressing Key Fob Unlock Button or by keyless unlocking), for 5 seconds you can operate this switch manually to the desired position.
  • Page 17: Fuel / Seat

    FUEL / SEAT Key Fob In this position you can press the square button on the Your scooter comes with two key fobs with backup key right to electrically open the fuel tank lid or seat. inside. Search button Manual Unlock / Lock Alarm button Button -...
  • Page 18: Vehicle Search Button

    Vehicle search button Also keep in mind the following: When parking the scooter, press the search button. The • If the ignition switch is in the "i" (On) position, the key fob system will beep 3 times, and simultaneously the turn signal buttons are not active.
  • Page 19: Backup Key

    Backup key Replacing the Key Fob Battery If the keyless unlock function fails, due to for example low If the Key Fob indicator flashes 5 times when the ignition battery or electrical failure, you can use the backup key  switch is turned On, or the operating range becomes shorter, located inside the key fob to operate the vehicle.
  • Page 20: Indicators And Warning Lights

    If the TCS indicator remains on when traction control is Under normal conditions, the ABS indicator will come on working, it indicates a malfunction of the TCS. Contact Linhai whenever the key is in "ON" position, and will turn off when an authorized service as soon as possible.
  • Page 21: Engine Temperature Warning Light

    Never allow the tank to be completely empty. on for a few seconds and then should come off. If the ⚠ WARNING problem persists, contact authorized Linhai service. lamp When fuel warning light " " starts flashing, refuel as soon as This light comes on when the diagnostic system detects a possible.
  • Page 22: Handlebar Switches

    Right Handlebar Switches HANDLEBAR SWITCHES Left Handlebar Switches 6. Engine stop switch 7. Hazard signal 8. Electric start button 1. Display operation buttons 9. Throttle grip 2. Pass switch 3. High / Low beam switch 4. Turn signal switch 5. Horn [Kategorie]...
  • Page 23: Display Operation Buttons

    Display operation buttons SET Button UP Button Press and hold for more than 3 seconds to disable the Press and hold for 3 traction control function. The TCS warning light will flash seconds to change indicating that the ECU has disabled the TCS function. When between metric and normal driving, the TCS warning light on the display will imperial units.
  • Page 24: High / Low Beam Switch

    ⚠ NOTE High / Low Beam Switch Although the engine stop switch stops the engine, it does Move the switch (3) to “ ” position to activate the high beam, and to “ ” position to activate the low beam. not turn off all the electrical circuits.
  • Page 25: Rear Brake Lever

    Rear brake lever USB Socket Rear brake lever is located on the left handlebar. Pull the A USB socket (1) is provided at the left side of the instrument lever toward the handlebar to activate the rear brake. panel. Its USB-A type socket with output of 5V/2A. This socket can charge electronic devices through USB connection.
  • Page 26: Abs System

    ABS System The ABS (Anti-lock Braking System) on this scooter uses dual electronic control system which can operate front and rear brake separately. The way how you brake on a scooter with ABS is the same, how you brake with vehicles without ABS. Whenever the ABS is activated, you will feel vibrations in the brake lever.
  • Page 27: Fuel Tank Cap

    Fuel Tank Cap 4. Do not overfill the tank. When heated (the heat can come Open the Fuel Tank from engine or sunlight), gasoline expands and may spill out Rotate the manual ignition switch to FUEL / SEAT position from the tank. and press the FUEL button to open the fuel tank lid.
  • Page 28: Seat

    Seat Passenger footrests Open the seat Rotate the manual ignition switch to FUEL / SEAT position and press the SEAT button to open to open the seat and the trunk underneath Close the seat 1. Push the seat down until you hear a click indicating This scooter is equipped with passenger footrests on the seat is properly closed.
  • Page 29: Helmet Hooks

    Helmet hooks When you open the seat, you Front storage compartment will find two helmet hooks that Your scooter is equipped with two storage compartments: you can use to hang your one in the front of the scooter, under the handlebars, and the helmets and then close the seat other in the trunk, under the seat.
  • Page 30: Underseat Storage Compartment

    Underseat storage compartment ⚠ WARNING When using the underseat compartment, keep following in mind:  Underseat compartment may become heated due to the sun or heat coming from engine.  Do not store food and other items which are flammable or susceptible to heat damage in this compartment.
  • Page 31: Rear Suspension

    Have the weak spring replaced by Do not tamper or attempt to open the shock absorber. authorized Linhai service. Do not subject the rear shock absorber to an open flame or any other source of high heat. High heat can cause an explosion due to excessive gas pressure.
  • Page 32: Center Stand

    If the center stand spring loses tension, the side stand may harmful get loose when riding. Have the weak spring replaced by emissions gases Linhai authorized service. into safer ones by chemical Exhaust emission control system reaction. Your scooter is equipped with the exhaust gas emission...
  • Page 33: Oxygen Sensor

    Oxygen sensor Oxygen sensor (1) in the exhaust system measures oxygen ⚠ WARNING content in exhaust gases. •Use only 95 octane unleaded fuel. The use of leaded fuel will damage the catalytic converter. •Do not switch off the main switch while the scooter is moving, or large amount of unburned gases will get into the muffler and burn there, which will damage the catalytic converter.
  • Page 34 [Kategorie]...
  • Page 35: Pre-Ride Inspection

    If the scooter is not checked and maintained properly, it will increase the probability of an accident or damage to parts. If you find any problem, stop riding the vehicle. If you cannot find a solution to solve the problem in this manual, contact Linhai authorized dealer for check.
  • Page 36 Item Check Page Throttle grip ·Check for smooth operation. ·Check the grip free play. Contact Linhai dealer for adjustment and lubrication if necessary. Bowdens / Cables ·Check for smooth operation. ·Lubricate if necessary. Wheels/Tires ·Check for damage. ·Check tire pressure, wear and tread depth, adjust pressure or change tire if 30~31 necessary.
  • Page 37: Basic Operation And Riding

    Starting control the functions. If you are unfamiliar with, or do not understand any operation or function, consult your local Linhai dealer. 1. Stand on the left side of the scooter and push it forward and off the center stand, or….
  • Page 38: Braking

    Braking Fuel-efficient driving tips The way you ride determines whether your engine consumes too much fuel or not. Following tips can help you to ride your ⚠ WARNING scooter with less fuel consumption: Avoid emergency or sudden braking (especially when in lean •...
  • Page 39 Avoid prolonged operation above 3/4 throttle. 1000 km and beyond Avoid prolonged full throttle operation, change the engine rpm occasionally. ⚠ NOTICE If any engine trouble should occur during the break-in period, have a Linhai dealer check the scooter immediately. [Kategorie]...
  • Page 40: Parking

    Parking ⚠ WARNING When parking the scooter, stop the engine and remove the Because of the heat of a muffler and exhaust pipe, park the ignition key. scooter at the places where the pedestrians and children are not likely to touch it. ⚠...
  • Page 41: Periodic Maintenance And Minor Repairs

    Careful periodic maintenance will help keep your scooter in When inspections reveal the need for replacement parts, the safest, most reliable condition. The owner is responsible genuine Linhai parts are available from your Linhai dealer. for performing the scheduled maintenance specified in this manual.
  • Page 42: Tool Kit

    If you do not have tools or skills necessary to complete a harmful pollutants in the exhaust gases. Maintain the system procedure properly, take your vehicle to Linhai dealer for according to the maintenance chart so as the exhaust gases service.
  • Page 43: Spark Plug Installation

    Do not tighten it by 1/4~1/2 turns further with a supplied wrench. attempt to diagnose problems by yourself. Instead, take the scooter to your authorized Linhai dealer for inspection. Spark plug: CPR8EA Spark plug gap: 0.7-0.8 mm...
  • Page 44: Engine Oil And Oil Strainer

    If you find any leakage, take your 2. Start the engine, warm it up for a several minutes and stop scooter to your Linhai dealer for inspection. the engine. 3. Wait for a few minutes to let the oil settle down and ⚠...
  • Page 45: Engine Oil Change

    Before every ride check, if there is any leakage in the final drive. If you find any leakage, take your scooter to your Linhai dealer for inspection. Final drive oil should be regularly replaced in intervals specified in the maintenance chart.
  • Page 46: Coolant

    Coolant 3. If coolant level is below the "L" mark, remove the reservoir The cooling system has two main parts: radiator and reservoir. cap (under the floorboard cover) and add coolant as required Check the coolant level in reservoir before every ride. Since to bring the coolant level to the FULL level mark.
  • Page 47 Never add hard or salt water as it is harmful to the engine. Use only distilled water. Softened tap water may be used too, if distilled water is not available. If you have used soft water, contact authorized Linhai service. Recommended coolant: Glycol-based coolant Reservoir tank capacity: 0,25 L...
  • Page 48: Coolant Replacement

    5. Install a new air cleaner element. Coolant must be replaced regularly. Have the coolant 6. Install the air filter cover and tighten the screws. replaced by your Linhai dealer in intervals specified in the ⚠ NOTICE maintenance chart. Make sure that the air filter element is installed in the air box Main air filter and V-belt air filter correctly.
  • Page 49: Clean V-Belt Air Filter Element

    Clean V-belt Air Filter Element ⚠ NOTICE Be careful when cleaning V-belt air filter. Torn air filter can cause damage to the drive system.  Screw 2x  Washer 2x 5. Oil the V-belt air filter element with recommended oil. ...
  • Page 50: Throttle Grip Free Play Inspection

    ⚠ WARNING 3~5 mm. If adjustment is needed, Cold tire pressure: have it adjust by a Linhai dealer. 1 person (0~90kg) Front: 171 kPa Rear: 196 kPa Valve Clearance Adjustment...
  • Page 51: Tread Wear

    Inspect the wheels for cracks, bends, damage or warpage before every ride. If you find any damage, have the wheel 1. Tread depth replaced by a Linhai dealer. Do not attempt to repair the 2. Tire sidewall wheels yourself. Deformed or cracked wheel must be replaced.
  • Page 52: Front/Rear Brake Inspection

    There should be no free play at the end of brake lever. If there Follow the maintenance chart and check the front and rear is free play, ask Linhai dealer to check the brake system. brake pads regularly for wear.
  • Page 53: Brake Fluid Inspection

    Always clean up all spilled brake fluid immediately. •Its normal that the brake fluid level goes down gradually as the brake pads wear. Anyway, if the brake fluid level descends rapidly, take your scooter to official Linhai dealer for inspection. Brake Fluid Replacement 1.
  • Page 54: Cables Inspection And Lubrication

    Before each ride always inspect the throttle grip for smooth operation. Also, check if throttle cables are in good condition and are working properly. In addition, have your Linhai dealer lubricated throttle grip and cables regularly in intervals specified in the maintenance table. Throttle cable is equipped with rubber dust covers;...
  • Page 55: Center And Side Stand Inspection And Lubrication

    Securely support the scooter so there is no danger of it falling Linhai dealer. An improperly retracted side stand or center over. stand could contact the ground and cause a loss of control How to check resulting in serious injury or death.
  • Page 56: Steering Inspection

    Linhai dealer. the steering column can cause dangerous situations. For your safety, have your Linhai dealer check and repack the steering column bearings every 10 000 km. Check the operation of the steering regularly according to the maintenance chart.
  • Page 57: Battery

    • Eyes: Flush with water for 15 minutes and get prompt •If you notice that the starter motor cranks the engine slowly, medical attention. have your Linhai dealer check the condition of the battery and charging system. [Kategorie]...
  • Page 58: Battery Charging

    Battery Charging 2. If the scooter is going to be stored for more than two Batteries require regular cleaning and recharging in order to months, recharge the battery to full capacity every 30 - 60 deliver peak performance and maximum service life. If your days.
  • Page 59: Fuse

    To access the fuse box, 4. If the new fuse immediately blows again, contact remove battery cover. authorized Linhai dealer. OBD connector The OBD connector is next to the battery. Remove the Fuse box battery cover to access the OBD connector.
  • Page 60: Led Headlight Lamp Replacement

    LED Headlight Lamp Replacement The LED Headlights are not serviceable. If the headlight becomes damaged or inoperable, the entire assembly must be replaced. Contact your authorized Linhai dealer. LED Turn signals/Tail/Brake/Position light replacement The LED Turn Signals / Tail / Brake / Position lights are not 1.
  • Page 61: Troubleshooting

    Use only original Linhai spare parts for maintenance and replacement. Aftermarket parts may look like original Linhai parts, but they are often poor quality products and their service life is shorter and can lead to extra maintenance costs.
  • Page 62: Troubleshooting Chart

    If engine cannot start, check the ignition. Compression There is Check ignition compression Use electric starter motor Ask Linhai dealer to check the No compression scooter. 3. Ignition Wipe dry and adjust plug gap Open the throttle halfway or replace the spark plug Remove spark plug and use electric starter.
  • Page 63: Cleaning And Storage

    CLEANING AND STORAGE •Never use harsh chemical products on plastic parts. Avoid Cleaning using clothes or sponges that are stained with strong or Keeping your scooter clean not only improves its appearance, abrasive detergents, gasoline, dust, grim, sand, brake fluid, but can also extend the life of the components.
  • Page 64: Cleaning After Riding In Rain, Winter Or Near The Sea

    5. Apply car or motorcycle wax to all painted surfaces. ⚠ NOTE 6. Let the scooter dry completely before storing or covering •Consult a Linhai dealer for advice on what products may be used. •After washing or riding in rainy days or foggy weather , the headlights may mist up temporarily.
  • Page 65: Storage

    •Crank the engine several times to coat the cylinder walls Storage with oil. Short-term storage •Reinstall the spark plug and spark plug cap. Be sure the storage area is dry and cool. Cover the scooter ⚠ WARNING with a breathable dustproof cover if needed. Always make sure the spark plug electrode is grounded ⚠...
  • Page 66: Specifications

    SPECIFICATIONS Dimensions and Weights Engine oil (4-stroke): Overall length 1980 mm Recommended engine oil Overall width 740 mm Overall height 1220 mm Seat height 800 mm Wheelbase 1390 mm Ground clearance 90 mm Maximum turning radius 2200 mm Mass in running order 147 kg Capacity - periodic oil change 0,95 L Passengers capacity...
  • Page 67 Air filter Tires Air filter Dry paper element Front 110/80-14 M/C 53P, tubeless Fuel Rear 130/70-13 M/C 63P, tubeless Type Unleaded petrol, 95 octane, Tire pressure Driver only: Fuel tank capacity 12 L Front tire 171 kPa Cooling system Rear tire 196 kPa Reservoir tank capacity 0,25 L...
  • Page 68 Front wheel Electric system Type Aluminum rim Ignition system Size Charging system Magneto Rear wheel Battery Type Aluminum rim Type YTX7A-BS Size Capacity 12V 6Ah Smart lock system battery Front brake current draw in standby approximately 2 mA Type Disc brake mode Operation Right hand operation...
  • Page 69: Vehicle Identification

    Vehicle Identification Vehicle Identification Number Record the Vehicle Identification Number and Engine serial Vehicle Identification Number is stamped on the frame as number in the spaces provided for ordering spare parts from shown in the picture. Open the seat to see the Vehicle a dealer or for reference in case the vehicle is stolen.
  • Page 70: Periodic Maintenance Chart

    Fittings / Fasteners * Check all chassis fittings and fasteners. Adjust if necessary. ○ ○ ○ Battery * Check if voltage is over 12.8V. Charge if necessary. ○ ○ *, S: It is recommended these items be serviced by official Linhai service. [Kategorie]...
  • Page 71 The brake fluid must be replaced when removing the master cylinder or caliper. Always check the brake fluid level. Refill if necessary. Replace brake fluid seals of the master cylinders and brake calipers every 2 years. Replace brake hoses every 4 years or immediately if they are damaged. Have all maintenance and repairs performed at an authorized Linhai dealer. [Kategorie]...
