KB4-GNB014-A
Wall Mirror Units
FRONT
BACK
WARNING:
-Contains small parts,sharp points and edges.
-Adult assembly required.
-Two adults recommended.
-Do not stand, sit, kneel or pull on unit for support.
-Never leave children unattended.
-Do not place unit near high heat or moisture.
-Adult supervision recommended.
-Clean with a moist cloth.
PART LIST
X1
HARDWARE
(Ø4*60)
(Ø4*35)
X4
X4
TIP!
DO NOT FULLY
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
POSITIONED.
X2
X4
BEFORE
ASSEMBLING ,
MAKE SURE THERE
ARE NO
MISSING PARTS .
NOTE:
AN ELECTRIC
SCREWDRIVER IS
RECOMMENDED FOR
ASSEMBLY(NOT INCLUDED)
PAGE 1/3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wisdom KB4-GNB014-A
Summary of Contents for Wisdom KB4-GNB014-A
- Page 1 PART LIST KB4-GNB014-A Wall Mirror Units FRONT BACK HARDWARE (Ø4*60) (Ø4*35) WARNING: -Contains small parts,sharp points and edges. -Adult assembly required. NOTE: TIP! -Two adults recommended. BEFORE DO NOT FULLY AN ELECTRIC ASSEMBLING , -Do not stand, sit, kneel or pull on unit for support.
- Page 2 (Ø4*60) 1.Mark and drill holes 488mm apart for top and bottom rails as shown (use a screwdriver or brad awl and use the existing screw holes in the wood 2. Fix rails securely to wall (making sure the screw holes on the bottom rail hanging rail as a guide).
- Page 3 Place label and this sheet in an accessible place. Model Number: KB4-GNB014-A Manufacture Date: Fasten your Hex Key Tool in the box below and keep in a convenient place for future use.
