Summary of Contents for MJ Acoustics Reference Series
-
Page 1: Table Of Contents
User’s Manual Reference Series Sub-Woofer Professional Reference For Home Cinema, Audiophile Specialists & Studios Natural Bass Impact Unparalleled in the Entertainment Environment Table of Contents Safety Instructions ………………….. page 2 Introduction ………………….. page 3 Display Menu ..…...…..……….. page 4 - 6 Memories ………………….. -
Page 2: Safety Instructions
CAUTION CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT. FULLY INSERT. RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, Caution: To Reduce Risk of Electric Shock, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET Do Not Remove Amplifier. -
Page 3: Introduction
When setting up your MJ Acoustics Sub bass system please visit the sup- port section on our website and navigate to setup my sub bass system, for useful set up hints and tips. - Page 4 Reference Series User’s Manual Incorporated within this model is our 3rd generation DAMP® offering full digital adjustments of all features but with that all important analogue feel. All the system functions and adjustments can be made using a single data rotary control knob. In addition to the main Data rotary control we provide a further 4 rotary controls for instant access to FREQ and GAIN for the twin independent crossovers.
-
Page 5: Display Menu
Reference Series User’s Manual Display Menu Display Description Factory Range Menu Default OFF, –99 to 0 Gain adjustment for RCA & Speakon inputs 120hz 20 to120hz Frequency adjustment for RCA & Speakon inputs OFF, –99 to 0 Gain adjustment for LFE & CEN inputs (via RCA) 120hz 20 to120hz Frequency adjustment for LFE &... - Page 6 Reference Series User’s Manual Press and hold to store settings at one of 4 locations Press to select menu item. Turn for setting Repeated pressing of the data rotary control scrolls through the menu options as follows: Repeated pressing of the data rotary control scrolls through the menu options as follows: Hi —...
-
Page 7: Memories
REMOTE 3.5mm Socket This jack is used to connect the MJ Acoustics infra red eye (optional). This unique feature pro- vides for remote control of all functions but is primarily beneficial for the selecting of user pre-set stored data which can be selected for different program sources. The remote eye sensor hous- ing must be located in line of sight with the ir remote transmitter. -
Page 8: Set-Up Hints & Tips
Reference Series User’s Manual Output Meter On the display window there is a series of LED’s which light-up as power output is increased. This is intended as a guide only and provides an indication of how hard the system is working. POWER The digital display on the rear panel shows that the unit is powered and the amplifier is ready for use. - Page 9 Reference Series User’s Manual Ref 200 Ref 210 Ref 400 Ref 1 Mk 4 10" DRIVER 12" DRIVER NON LOADED TUNED PORT REFERENCE GRADE COMPONENT MATCHING GOLD PLATED RCA SOCKETS DIGITAL DISPLAY POWER OUTPUT METER SMART REMOTE SPEAKER LEVEL CONNECTION (SPEAKON) STEREO LINE LEVEL Left + Right INPUT RCA sockets all Gold Plated LFE &...
- Page 10 Reference Series User’s Manual Amplifier Resulting from continued extensive development design, the twin MOSFET amplifiers provide the engine to power the perfectly matched ultra long throw woofers. The power supply has been designed to provide the requirements of Instant High Reference Current incorporated in all Series.
- Page 11 MJ Acoustics Smart Remote (sr) is an app for tablet or smartphone. sr employs wireless communication technology for use with those subwoofers in the MJ Acoustics range that have sr enabled hardware. No requirement for router connection but with total autonomous communication between subwoofer and smart device is achieved using Bluetooth LE data transmission support.
- Page 12 Defective parts will be replaced if in the sole judgement of MJ ACOUSTICS they be deemed defective over and above that considered to be normal wear and tear.
