Safavieh Outdoor Archie PAT9047A Manual

NOTICE
*Please make sure that you have all parts indicated and they are in good condition before you
begin assembly of this item. Refer to part list and hardware list below for guidance.
*This item should be assembled on a soft surface to prevent scratching the finish during
assembly.
*This item may require periodic tightening.
*If you are having difficulty, our friendly Customer Care team is always here to help. Please
email customersupport@safavieh.com
PREPARATION
*Before beginning assembly of product, make sure all parts are present. Compare parts with part
contents list and hardware contents list.
*If any part is missing or damaged, do not attempet to assemble the product.
*Estimated Assembly Time: 30minutes.
*Tools Required for Assembly (included): Allen Key
CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use. Remove wooden furniture from
standing water. Dust regularly with small brush or vacuum. Spills should be taken care of
immediately before they harden or stain with a slightly dampened sponge.
Part List and Hardware List
DESCRIPTION PICTURE
PIECE
A Chair leg
B Connecting rod
C Chair cloth
D
Back cushion
E Seat cushion
F Table top
G Table leg
QUANTITY DESCRIPTION
PIECE
H
4 Table leg
10 HW1 Bolt
2 Bolt
HW2
HW3
2 Bolt
2 Washer
HW4
HW5
1 Allen key
1
PICTURE QUANTITY
1
4
1
20
25
3
ITEMNO.:PAT9047
Product Dimensions:
Chair:W27.56''xD37.01''xH35.48''
Table:Dia19.69''xH17.72''
Weight Capacity:
Chair:330LBS
Table:165LBS
Warning: Do not stand on the table
Warning: Do not over torque bolts
