Summary of Contents for AEG FSK75737P

  • Page 1 EN User Manual | Dishwasher FSK75737P aeg.com\register...

  • Page 2: Table Of Contents

    FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...

  • Page 4: Safety Instructions

    • Follow the maximum number of 14 place settings. • The appliance door should not be left in an open position to avoid the tripping hazard. • If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.
  • Page 5 Make sure that there is access to the • Do not drink and play with the water in the mains plug after the installation. appliance. • Do not pull the mains cable to disconnect • Do not remove the dishes from the the appliance.

  • Page 6: Installation

    Authorized Service Centre to replace it with 3.1 Building in the new one. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux 60 cm Sliding Door Dishwasher min. 560 1240 3.2 Safety caps If the furniture panel is not installed, open the appliance door carefully to avoid the risk of injury.

  • Page 7: Product Description

    4. PRODUCT DESCRIPTION Ceiling spray arm Rinse aid dispenser Upper spray arm Detergent dispenser Lower spray arm Lower basket Filters Upper basket Rating plate Cutlery drawer Salt container Air vent 4.1 Beam-on-Floor • The red light flashes when the appliance has a malfunction.

  • Page 8: Control Panel

    5. CONTROL PANEL On/Off button / Reset button Option buttons (EXTRAS) Delay start button AUTO Sense program button Display MY TIME program selection bar 5.1 Display 5.2 ECOMETER The ECOMETER indicates how the programme selection impacts energy and water consumption. The more bars are on, the lower the consumption is.

  • Page 9: Programme Selection

    6. PROGRAMME SELECTION 6.1 MY TIME The appliance senses the degree of soil and the amount of dishes in the baskets. It adjusts MY TIME selection bar allows to select a the temperature and quantity of water as well suitable dishwashing cycle based on as the wash duration.
  • Page 10 6.4 Programmes overview Programme Dishwasher Degree of Programme phases EXTRAS load soil Quick Crockery, cutlery Fresh • Dishwashing 50 °C • ExtraPower • Intermediate rinse • GlassCare • Final rinse 45 °C • AirDry Crockery, cutlery Fresh, lightly • Dishwashing 60 °C •...

  • Page 11: Basic Settings

    Consumption values Water (l) Energy (kWh) Duration (min) Programme 1)2) Quick 11.0 0.620 11.8 0.970 1h 30min 11.9 1.110 2h 40min 11.9 1.210 0.644 AUTO Sense 12.1 1.220 Machine Care 10.6 0.710 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values.
  • Page 12 The order of the basic settings presented in How to change a setting the table is also the order of the settings on the ECOMETER: Make sure the appliance is in setting mode. 1. Use Previous or Next to select the bar of the ECOMETER dedicated to the desired setting.
  • Page 13 Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH) grees level 47 - 50 84 - 90 8.4 - 9.0 835 - 904 58 - 63 43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57...
  • Page 14 Each performed softener rinse (possible more than one in the same cycle) may prolong the programme duration by another 5 minutes when it occurs at any point at the beginning or in the middle of a programme. All the consumption values mentioned in this section are determined in line with the currently applicable standard in laboratory conditions with water hardness...

  • Page 15: Before First Use

    is then selected automatically after you When the latest programme selection is activate the appliance. disabled, the default programme is ECO. 8. BEFORE FIRST USE 1. Make sure that the current level of the 4. Carefully shake the funnel by its handle to water softener agrees with the get the last granules inside.

  • Page 16: Daily Use

    4. Close the lid. Make sure that the lid locks CAUTION! into position. Only use rinse aid designed specifically for dishwashers. Fill the rinse aid dispenser when the 1. Open the lid (C). indicator (A) is clear. 2. Fill the dispenser (B) until the rinse aid reaches the marking ''MAX''.
  • Page 17 2. Press the button dedicated to the option 3. Close the appliance door to start the you want to activate. countdown. • The light related to the button is on. During the countdown, you cannot change • The display shows the updated the delay time and the programme selection.

  • Page 18: Hints And Tips

    • When the programme is completed. • After 5 minutes if a programme was not started. If the door is opened for more than 30 seconds during the drying phase, the 9.10 End of the programme running programme ends. It does not happen if the door is opened by the When the programme is complete, the AirDry function.
  • Page 19 softened water results in detergent • The programme is suitable to the type of residues on the dishes. Adjust the amount load and the degree of soil. of detergent based on the water hardness. • The correct quantity of detergent is used. Refer to the instructions on the detergent 10.5 Loading the baskets packaging.

  • Page 20: Care And Cleaning

    11. CARE AND CLEANING 11.2 Internal cleaning WARNING! • Clean the appliance interior with a soft Before any maintenance other than damp cloth. running the programme Machine Care, • Do not use abrasive products, abrasive deactivate the appliance and disconnect cleaning pads, sharp tools, strong the mains plug from the main socket.
  • Page 21 5. Make sure that there are no residues of food or soil in or around the edge of the 1. Turn the filter (B) counterclockwise and sump. remove it. 6. Put back in place the flat filter (A). Make sure that it is correctly positioned under the 2 guides.
  • Page 22 CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 11.6 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.
  • Page 23 4. To install the spray arm back, press the spray arm upwards and simultaneously turn it counterclockwise until it locks into place. 2. Move the upper basket to the lowest level to reach the spray arm more easily. 3. To detach the spray arm (C) from the 11.8 Cleaning the ceiling spray arm delivery tube (A), turn the mounting element (B) counterclockwise and pull the...

  • Page 24: Troubleshooting

    12. TROUBLESHOOTING Refer to the below table for information on WARNING! possible problems. Improper repair of the appliance may With some problems, the display shows an pose a danger to the safety of the user. alarm code. Any repairs must be performed by qualified personnel.
  • Page 25 Problem and alarm code Possible cause and solution Technical malfunction of the appli‐ • Switch the appliance off and on. ance. The display shows iC0 or iC3. The level of water inside the appli‐ • Switch the appliance off and on. ance is too high.
  • Page 26 12.1 The product number code 1. Press and hold simultaneously (PNC) for about 3 seconds. If you contact an Authorised Service Centre, The display shows the PNC of your you need to provide the product number code appliance. of your appliance. 2.

  • Page 27: Technical Information

    Problem Possible cause and solution Traces of rust on cutlery. • There is too much salt in the water used for washing. Refer to "The water softener". • Silver and stainless steel cutlery were placed together. Do not place silver and stainless steel items close together. There are residues of detergent in the •...

  • Page 28: Environmental Concerns

    Water supply pressure Min. / max. MPa (bar) 0.05 (0.5) / 1 (10) Water supply min. 5 - max. 60 °C Cold water or hot water Capacity Place settings Refer to the rating plate for other values. If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply to de‐ crease energy consumption.
  • Page 32 117834750-A-272023...
