Optoma 3651RK User Manual

Optoma 3651RK User Manual

Interactive flat panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Interactive Flat Panel
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3651RK and is the answer not in the manual?

Questions and answers

Related Manuals for Optoma 3651RK

Summary of Contents for Optoma 3651RK

  • Page 1 Interactive Flat Panel User manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ....................5 Safety Instructions ........................5 Copyright ........................... 6 Disclaimer ..........................6 Trademark Recognition ......................6 FCC Statement .......................... 6 FCC Warning ..........................6 Declaration of Conformity for EU Countries ................7 WEEE ............................7 ENERGY STAR ......................... 7 INTRODUCTION ..................
  • Page 3 Adjusting the Volume Level ....................34 Configuring OSD Settings ......................35 Configuring Image Settings ....................35 Configuring Display Settings ....................36 Configuring Signal Settings (for VGA input only) ..............37 Configuring Audio Settings ....................37 Viewing Device Information ....................38 Configuring Advanced Settings ....................
  • Page 4 Cleaning the Screen ......................91 Clean the Front Frame ......................91 Optoma Global Offices ......................92 English...

  • Page 5: Safety

    ‡ Do not attempt to service the device yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the device for repair. ‡ Disconnect the power plug from AC outlet if the device is not being used for a long period of time.

  • Page 6: Copyright

    Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2020 Disclaimer The information in this document is subject to change without notice.

  • Page 7: Declaration Of Conformity For Eu Countries

    Declaration of Conformity for EU Countries ‡ EMC Directive 2014/30/EU (Including amendments) ‡ Low Voltage Directive 2014/35/EU WEEE Disposal instructions Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle it. ENERGY STAR ENERGY STAR is a U.S.

  • Page 8: Introduction

    For detailed instructions, please scan the QR code or visit the URL: *The product images shown are for illustration purposes only and may not be an exact representation of the product. Optoma reserves the right to change product images and specifications at any time without notice. Batteries...

  • Page 9: Optional Accessories

    INTRODUCTION Optional Accessories OPS2-i7 (slot in PC, Stand Mount Wall Mount with OPS2-i5 (slot in PC, intel i7 8th CPU, 8G PC Vesa Bracket intel i5 8th CPU, 8G RAM, 256G SSD) (OWMFP01) RAM, 128G SSD) Wi-Fi Dongle English...

  • Page 10: Product Overview

    INTRODUCTION Product Overview Front View Item Item Touch screen Light sensor USB 2.0 IR receiver USB 2.0 Home button USB TOUCH Back button HDMI Front Setup menu button MIC in Decrease volume button Power button with LED indicator Increase volume button Note: Front USB 2.0 ports are full channel USB ports.

  • Page 11: Rear View

    INTRODUCTION Rear View TOUCH AUDIO IN VGAR S232 LAN IN LAN OUT Item Item OPS slot Touch DP SPDIF HDMI Out Power switch Line Out AC In socket USB 2.0 Embedded Audio In USB 2.0 USB 3.0 Touch Touch 2 RS232 HDMI 2 LAN IN...

  • Page 12: Remote Control

    INTRODUCTION Remote Control Button Description Power On/Off Mute/Unmute Enter Number Go to the Home Page Return to Previous/Exit Enter Whiteboard Mode English...
  • Page 13 INTRODUCTION Button Description Take a Screenshot Up/Down/Left/Right Confirm/OK Enable Sound Only Mode Freeze the Current Screen, Click Again to Exit Freeze Function Adjust the Sound Volume Adjust the Brightness (10 to 255) Enter the Source Selection Page View Currently Running Applications Open the File Manager View all Pre-installed Applications Switch Source to Internal PC...

  • Page 14: Setup And Installation

    SETUP AND INSTALLATION Wall Mounting Installation Use only an Optoma-approved optional wall mount kit (available separately). Kit will include the following items: Screw (x4) Screw (x8) Screw (x2) Dual mounting brackets and wall mount Anchor (x8) Washer (x8) Wall Mount Specifications...
  • Page 15 SETUP AND INSTALLATION To mount the IFP on the wall, complete the following steps: Install the dual mounting brackets on the rear of the IFP. Then secure the brackets with four screws (A). Drill eight small holes on the mounting location and insert the anchors into the holes. Position the wall mount on the wall, then secure the wall mount with eight screws (B) through the washers into the installed anchors on the wall.
  • Page 16 SETUP AND INSTALLATION Align and hook the dual mounting brackets to the wall mount. Secure the dual mounting brackets and the wall mount with two screws (C). Note: ‡ The maximum wall mount kit load capacity:160kg (352lbs). ‡ Please ensure that the wall mount is installed on a wall that can bear the weight of the IFP. If an appropriate wall is not available, we recommend using a stand instead.

  • Page 17: Installing An External Mini Computer

    SETUP AND INSTALLATION Installing an External Mini Computer Install the mini PC bracket on the rear side of the IFP, then complete one of the following to install the mini computer: ‡ Install the screws onto the mini computer, then align and hook the mini computer to the mini PC bracket. ‡...

  • Page 18: Stand Mounting Installation (Optional)

    SETUP AND INSTALLATION Stand Mounting Installation (Optional) The stand mount kit includes the following items: Pen tray (x1) Wheel (x4) Screw (x16) Screw (x4) (x4) Washer (x4) Split Ring Lock Washer (x4) Stand pole (x2) Stand base (x1) Screw (x4) Washer (x4) (x4)
  • Page 19 SETUP AND INSTALLATION Flip the stand base so that you can see the screw holes for the wheel, then install the wheel onto its slot and secure it with four screws (J). Repeat the same procedure to install the remaining three wheels. Place the stand base on the stable surface, then install the stand pole onto its slot and secure both standoffs with two nuts (G) through the washers and G1).
  • Page 20 SETUP AND INSTALLATION Align the pen tray with the screw holes on the middle part of the poles, then secure the pen tray with four screws (H). Install the wall mount on the upper part of the poles, then insert the screws (K) through the screw holes from the rear side of the poles.

  • Page 21: Using The Remote Control

    SETUP AND INSTALLATION Using the Remote Control Installing/Replacing the Remote Control Batteries Two AAA size batteries are supplied for the remote control. IMPORTANT! Replace only with the same or equivalent type batteries. Remove the cover of the battery compartment. Insert the two batteries with correct polarity (+/-) as shown inside the battery compartment. Replace the cover.

  • Page 22: Remote Control Operating Range

    SETUP AND INSTALLATION Remote Control Operating Range When using the remote control, make sure to point it within ±30° to the IR receiver on the IFP. The distance between the remote control and the IR sensor window should not be longer than 8 meters. ‡...

  • Page 23: Connections

    SETUP AND INSTALLATION Connections Connecting to Power Connect one end of the power cord to the AC-in socket on the IFP. Connect the other end of the power cord to a power outlet or a power supply. Set the Power switch to ON (I). The IFP will automatically enter standby mode. Connecting External Devices IMPORTANT! To use the touch screen function, make sure to connect one end of the USB cable to the USB B...
  • Page 24 SETUP AND INSTALLATION VGA input connection Connect your computer to the IFP using a VGA cable. Note: For audio input, connect one end of an audio cable to the Audio-in jack on the IFP and the other end of the cable to the audio jack on your computer.
  • Page 25 SETUP AND INSTALLATION HDMI output connection Connect your projector to the HDMI out port on the IFP. HDMI OUT USB connection Connect your USB peripheral device to the IFP using a USB cable. Note: For the USB flash drive connection, simply plug it into one of the available USB ports. RS232 connection Connect your computer to the IFP using a RS232 cable.
  • Page 26 SETUP AND INSTALLATION LAN connection Connect your router to the IFP using an Ethernet cable. LAN IN LAN Settings Note: To configure network settings, refer to “Configuring Network Settings” on page 41. Wi-Fi connection For Wi-Fi connection, you need to install a Wi-Fi dongle to the USB port slot on the side of the IFP. Wi-Fi dongle can receive the signal in an area where there is a Wi-Fi network.
  • Page 27 SETUP AND INSTALLATION Touch pen holder connection To install a holder for the touch pen, complete the following steps: Attach the magnetic touch pen holder to the front side of the screen. Insert the touch pen to its holder. English...

  • Page 28: Using The Device

    USING THE DEVICE Turning the Power On/Off Powering on Note: After the power cord is properly connected, make sure the Power switch is set to ON (I). Press the Power button to turn on the IFP. The LED indicator light turns white, indicating it is ready to use. Note: You can also press the button on the remote control to turn on the IFP.

  • Page 29: Setup Wizard

    USING THE DEVICE Setup Wizard The Setup Wizard will appear on the screen when you turn on your IFP for the first time. Note: This IFP is equipped with a touch-sensitive screen. You can simply tap the touch screen to operate your IFP. Select the language for the on-screen display (OSD) menu.
  • Page 30 USING THE DEVICE Configure the date and time related settings. Select Next to continue. Read Optoma’s legal policies, including Terms and Conditions of Use, Privacy Policy, and Cookie Policy. Tap Agree to complete setup. The IFP is now ready to use.

  • Page 31: Basic Operations

    BASIC OPERATIONS Home Screen Overview The Home screen is displayed every time you start the IFP. Wireless display PIN code from TapCast Pro Current date and time Apps shortcuts Input shortcuts Hidden toolbar shortcut Hidden Connection with OSD menu Apps list WiFi connection status toolbar JOAN...

  • Page 32: Setup Menu

    BASIC OPERATIONS Setup Menu On any screen, drag the bottom of the screen upwards to open the Setup menu. The Setup menu is part of the OSD menu. To view other OSD menu items, tap on the left side of the Setup menu. Setup menu OSD menu English...

  • Page 33: Selecting An Input Source

    BASIC OPERATIONS Selecting an Input Source In the Setup menu, the available input source is indicated by the ● icon. To change the input source, simply tap the desired input source. Note: ‡ For more information about device connections, refer to the “Connections” section. ‡...

  • Page 34: Activating The Low Blue Light Function

    Optoma Low Blue Light is an eye protection feature that can reduce the blue light. In the Setup menu, drag the slider bar to the right/left to adjust the low blue light level.

  • Page 35: Configuring Osd Settings

    BASIC OPERATIONS Configuring OSD Settings To open the OSD menu, do any of the following: ‡ Drag the bottom of the screen upwards, then tap on the left side of the Setup menu. For more information, refer to “Setup Menu” on page 32. Press the Menu button on the remote control.

  • Page 36: Configuring Display Settings

    BASIC OPERATIONS Note: ‡ USB playback function in Android source also supports HDR content. If you play an HDR video from USB disk, Display Mode will switch to HDR automatically. ‡ Image setting can only be adjusted in HDMI, VGA, and OPS input. It can’t be adjusted and will be grayed-out in Android source.

  • Page 37: Configuring Signal Settings (For Vga Input Only)

    BASIC OPERATIONS Configuring Signal Settings (for VGA input only) In OSD menu, tap to open Signal menu, then complete the following steps: ‡ Tap Automatic to automatically adjust the image to its optimized frequency, phase, and position. ‡ Tap ◄► on Frequency item to adjust the vertical noise of the image. ‡...

  • Page 38: Viewing Device Information

    BASIC OPERATIONS Tap ◄► on Treble item to adjust the treble level that is suitable for your room. ‡ ‡ Tap ◄► on Balance item to adjust the sound balance level that is suitable for your room. Viewing Device Information In OSD menu, tap to open the Information menu, then complete the following steps: ‡...

  • Page 39: Configuring Advanced Settings

    BASIC OPERATIONS Configuring Advanced Settings To open the Advanced Settings menu, tap on the Home screen. Note: Advanced settings can be modified only in Android mode. Sub menu Settings Main menu Note: ‡ To configure Advanced Settings, simply touch the desired item on the screen and use screen controls to adjust the value or set the setting.

  • Page 40: Personalizing The System

    BASIC OPERATIONS Personalizing the System In the Advanced Settings menu, tap to open Personalize menu, then complete the following steps: ‡ Tap Wallpaper and then select one of the available image options among default wallpapers or from an image gallery (Choose from files). To confirm the wallpaper, tap Save at the prompt. Tap Home Shortcut to customize Home screen shortcuts.

  • Page 41: Configuring Network Settings

    BASIC OPERATIONS ‡ Tap Input Name to rename input. Tap on the input name you wish to change, then type a new name and confirm name modification by tapping OK at the prompt. Configuring Network Settings In Advanced Settings menu, tap to open Network menu, then complete the following steps: ‡...
  • Page 42 BASIC OPERATIONS Note: In Other Options list, you can configure additional wireless network settings, such as connecting via WPS, adding a new network, and configuring portable hotspot settings. ‡ Tap Ethernet to configure LAN settings and view the current connection status. Enter proxy settings and IP settings (DHCP or static).

  • Page 43: Configuring Device Settings

    BASIC OPERATIONS Configuring Device Settings In Advanced Settings menu, tap to open the Device menu, then complete the following steps: English...
  • Page 44 Tap Device ID to assign a new ID to the IFP. To confirm, tap OK. Note: Device ID is related to Optoma ProService Device ID. ‡ Tap SAMBA Service to enable or disable SAMBA service and configure the related parameters.

  • Page 45: Configuring Security Settings

    BASIC OPERATIONS Configuring Security Settings In the Advanced Settings menu, tap to open the Security menu, then complete the following steps: ‡ Tap Password to set screen lock password or USB/Wi-Fi access password. To set passwords, do any of the following: - Tap Screen Lock Password Settings and enter a new password twice at the prompt.
  • Page 46 BASIC OPERATIONS After entering the correct password, the DEBUG MENU opens. b) Tap >>> next to Disable USB/WIFI Drive to enable or disable the respective feature. To enable, select ON at the prompt or to disable, select OFF. If you selected ON, the Advanced Settings > Security > Password menu opens automatically with USB/ Wi-Fi Access Password option visible.

  • Page 47: Configuring System Settings

    BASIC OPERATIONS Configuring System Settings In the Advanced Settings menu, tap to open the System menu, then complete the following steps: ‡ Tap Date and Time to configure date and time related settings. Tap any of the following: - Select Time Zone to select time zone in your area. - Daylight Saving Time to enable or disable daylight saving time (if applicable).
  • Page 48 BASIC OPERATIONS ‡ Tap Keyboard to view and manage keyboards. Tap Startup and Shutdown to configure settings related to starting and shutting down the IFP. Tap any of the ‡ following: - ◄► on Startup input source item to select one of the available startup input options: Last shutdown input, Android, OPS, HDMI1, HDMI2, HDMI Front, Displayport, or VGA, DP.
  • Page 49 Active Standby mode consumes higher power since system only turns off backlight and mainboard is still working to listen for power on command from LAN and Optoma ProService. If you don’t have remote power on requirement, we suggest using Eco. Standby mode to save more power.
  • Page 50 BASIC OPERATIONS - OTA (Over-The-Air) Software Upgrade to enable or disable upgrading software over Internet. Tap Auto to enable the system to check for firmware upgrades automatically every time the IFP is powered on and connected to the Internet. If the Auto option is disabled, the system will not check for firmware upgrades automatically.

  • Page 51: Side Toolbar

    BASIC OPERATIONS Side Toolbar to open the side toolbar. You can drag the panel to change its position on the screen. Side toolbar ‡ To hide the toolbar, tap ‡ To return to the previous screen, tap ‡ To return to Home screen, tap ‡...

  • Page 52: Viewing Recent Tasks

    BASIC OPERATIONS Viewing Recent Tasks > to view all of your recently used apps. ‡ Tap on the app you want to launch. ‡ To remove the app from the list, swipe it left or right. ‡ To clear the list, swipe the list downwards first (if necessary), then tap CLEAR ALL. ‡...

  • Page 53: Team Share App

    BASIC OPERATIONS Team Share App > to open Team Share app. You can write, scribble, or draw on the virtual whiteboard. To start using the app, do the following: In New tab, select a background or template for your content. Note: To open a previously saved project, tap Recent, select your desired project, and then tap Open.
  • Page 54 BASIC OPERATIONS Item Description Write or draw a freeform line. Tap to select the desired line thickness and color. IMPORTANT! Avoid damaging the virtual whiteboard. For writing and drawing, use ONLY the supplied touch pen or your fingers. Note: ‡ To change the Colour/Color palette, tap ‡...
  • Page 55 BASIC OPERATIONS Item Description Select an object on the whiteboard. Tap any of the following to alter the selected area: Select ‡ (boundary point) to enlarge or diminish. ‡ to rotate. ‡ to duplicate. ‡ to delete. Draw a geometric shape. Tap to select the desired 2D or 3D shape with several color options.
  • Page 56 BASIC OPERATIONS Item Description Select one of the available options to export a file. Tap any of the following: ‡ to export the file to an internal/external storage or cloud storage. Note: For more information on cloud storage account management, refer to “Cloud Storage”...
  • Page 57 BASIC OPERATIONS Item Description Select a background or template for your content. Background options Undo Undo your last action. Redo Redo your last action. Add page Add a new page. English...

  • Page 58: Annotation App

    BASIC OPERATIONS Annotation App > to open annotation app. In this mode, you can do the following: ‡ to write and draw on the screen. Note: You can change the pen color by tapping repeatedly. ‡ to highlight the item on the screen. Note: You can change the highlighter color by tapping repeatedly.

  • Page 59: Screen Freezing

    BASIC OPERATIONS Screen Freezing > to freeze the current screen. In this mode, you can do the following: ‡ To zoom in, tap . Then you can pan and move around the image. Note: Each tap increases the magnification. ‡ To zoom out, tap Note: You can also pinch with two fingers on the screen to zoom in or out.

  • Page 60: Screen Recorder

    BASIC OPERATIONS Screen Recorder > to open screen recording utility. This utility helps you to record video from the IFP’s screen. ‡ to start recording the screen. While recording, tap to pause recording or to stop recording, then select a location where to save the recording and tap OK. ‡...

  • Page 61: Using The Apps

    Optoma support in rectifying any issue which may result from the installation of third-party apps will be chargeable and may be limited.

  • Page 62: Tapcast Pro

    USING THE APPS TapCast Pro TapCast Pro to project your mobile device or your computer display to the IFP through Wi-Fi or LAN connection. IMPORTANT! ‡ The IFP and your mobile device/computer must be connected to the same Wi-Fi or LAN network. ‡...
  • Page 63 USING THE APPS To share the screen, complete the following steps: Launch the TapCast Pro app. Enter the TapCast password and tap OK to establish the connection. Note: You can obtain the password for the wireless connection setup on the setup guideline screen. Tap any of the following: ‡...

  • Page 64: Computer

    To mirror your iOS mobile device screen to the IFP, drag the bottom of the screen upwards to open Control Center > Screen Mirroring, then tap on the device. To end the remote session, tap Stop Mirroring. Computer Go to https://www.optoma.com/ifp/ to download the Share Sender app. Then install the app onto your computer. English...
  • Page 65 USING THE APPS To share the screen: Launch the TapCast Pro app. Then enter the TapCast password to establish the connection. Note: You can obtain the password on the IFP’s screen. Once connected, tap any of the following: ‡ Start to mirror the screen of your computer to the IFP. ‡...

  • Page 66: Tapcast Pro Advanced Settings

    USING THE APPS TapCast Pro Advanced Settings Tap any of the following icons to configure TapCast Pro advanced settings: ‡ Settings to rename the device, run the TapCast Pro app by default after starting the IFP, show or hide the PIN code, and enable or disable split screen (4 screens) feature. Tap Finish to save settings and exit the Settings menu.
  • Page 67 USING THE APPS ‡ Grouping Display to enable or disable the function. If enabled, select devices where you want to share casting screen. Tap Refresh to refresh the device list, OK to save settings and exit the Grouping display... menu, or Back to exit without saving. Note: You can also display only these devices that support screen sharing by enabling Only Valid for Screen Sharing.

  • Page 68: File Manager

    USING THE APPS File Manager Tap File Manager to manage files and folders. Managing Files Select a storage and browse for a file or folder you want to view, then do any of the following: Item Description Images Display image files. Videos Display video files.
  • Page 69 USING THE APPS Item Description Select files and folders. When selected, tap any of the following: ‡ undo your last action. ‡ check/uncheck all items. ‡ cut and paste item(s). ‡ copy and paste item(s). ‡ delete item(s). ‡ rename an item. ‡...

  • Page 70: Cloud Storage

    USING THE APPS Cloud Storage Tap File Manager > Cloud Storage to create an account or use an existing account to access your cloud storage. To create an account: Tap Add account. Select the drive type. Follow on-screen instructions to create an account or sign in to your existing account. After successful login, you are prompted to set a security PIN.

  • Page 71: Playing Multimedia Files

    USING THE APPS Your account will be listed in the Cloud Storage menu. Playing Multimedia Files Multimedia support format Media Type Supported Format Video support format (codec) up to 4K resolution: ‡ .avi (MPEG-1, MPEG-2 MP@HL, MPEG-4 SP@L0-3, ASP@L0-5, H.264, MP, HP@Level 4.1,H263, VP6, MJPEG) ‡...
  • Page 72 USING THE APPS Playing videos Select the video you want play and tap to start the playback. During the playback, you can do the following: Item Description Replay Play back the video Previous video Skip to the previous video. Speed up the video Speed up Pause Pause the playback.
  • Page 73 USING THE APPS Playing music Select the song you want play and tap to start the playback. During the playback, you can do the following: Item Description Previous video Skip to the previous video. Pause the playback. To resume, tap . Pause Next video Skip to the next video.
  • Page 74 USING THE APPS Viewing photos Tap to select a photo and view the selected photo in full screen. Item Description Zoom in Magnify the photo. Zoom out Zoom out on the magnified photo. Previous photo Skip to the previous photo Slide show Start the slide show.

  • Page 75: Screen Lock

    USING THE APPS Screen Lock Tap Screen Lock to set the 4-digit pin code. Using the pin code, you can block the IFP from unauthorized use. To set the pin code for the first time, launch the Screen Lock app. Then tap Set password. The Advanced Settings >...

  • Page 76: Joan On Tv

    USING THE APPS Performance Optimzation Select Performance Optimzation to clean and optimize the data on the IFP. Joan on TV Tap Joan on TV to get the access PIN number. Use this PIN to connect the IFP to Joan Portal. After successful connection, the IFP will display meeting room(s) schedule, meeting reminders, and meeting room reminders that are set in Joan Portal.
  • Page 77 USING THE APPS To connect the IFP to the Joan Portal, complete the following steps: Open the web browser on your computer and enter http://Portal.getjoan.com into the address bar. The Joan Portal login page opens. Sign in to the Joan Portal. English...
  • Page 78 USING THE APPS Create a meeting room in Manage > Rooms > Add a room. Connect the IFP to the Joan Portal in Manage > Devices > Add device. English...
  • Page 79 USING THE APPS Enter the Device PIN, and then click Pair device. Note: To get the PIN number, tap Home screen > > Joan on TV. Connect the IFP and the meeting room in Manage > Devices. English...

  • Page 80: Additional Information

    ADDITIONAL INFORMATION Dimensions 65-inch 1546.5 1431.5 473.2 473.2 English...

  • Page 81: 75-Inch

    ADDITIONAL INFORMATION 75-inch 1770.2 1652.2 485.1 485.1 English...

  • Page 82: 86-Inch

    ADDITIONAL INFORMATION 86-inch 2019.4 1898 609.7 609.7 English...

  • Page 83: Supported Timing List

    ADDITIONAL INFORMATION Supported Timing List Input Source Resolution HDMI (1/2/Front) 2.0 DP (1.4) √ √ 72 x 480i@60Hz − 720 x 480p@60Hz √ √ − 800 x 600@60Hz √ √ − 1024 x 768@60Hz √ √ √ 1280 x 720p@50Hz √...

  • Page 84: Rs232 Protocol Function List

    ADDITIONAL INFORMATION RS232 Protocol Function List Note: IFP supports RS232 and RJ45 (port 23) control command. RS232 Pin Assignments Spec. Pin No. (from IFP side) RS232 RJ45 Control Connection RS232 Settings LAN Control Settings Baud Rate 9600 Machine IP Data Bits Port Parity None...

  • Page 85: Set Command

    ADDITIONAL INFORMATION SET Command Response Type Category Parameter Hex Code CMD Success Failed Power off ~xx00 n 7E 30 30 30 30 20 30 0d Power Restart ~xx00 n 7E 30 30 30 30 20 33 0d Power on ~xx00 n 7E 30 30 30 30 20 31 0d Eco.
  • Page 86 ADDITIONAL INFORMATION Response Type Category Parameter Hex Code CMD Success Failed Español 7E 30 30 37 30 20 35 0d Traditional n=13 7E 30 30 37 30 20 31 33 0d Chinese Simplified n=14 7E 30 30 37 30 20 31 34 0d Chinese Português 7E 30 30 37 30 20 36 0d...

  • Page 87: Get Command

    ADDITIONAL INFORMATION Response Type Category Parameter Hex Code CMD Success Failed Remote UP n=10 7E 30 30 31 34 30 20 31 30 0d Remote DOWN n=14 7E 30 30 31 34 30 20 31 34 0d Remote LEFT n=11 7E 30 30 31 34 30 20 31 31 0d Remote RIGHT n=13...
  • Page 88 ADDITIONAL INFORMATION Response Type Category Hex Code CMD Success Parameter Failed 7E 30 30 31 32 37 20 Aspect Ratio ~xx127 n 16:9 31 0D OK14 Presentation Bright 7E 30 30 31 32 33 20 Picture Mode ~xx123 n Cinema 31 0D User OK21...

  • Page 89: Led Indicator

    ADDITIONAL INFORMATION Note: (*1) Power Running Time Input Source Firmware Version Display Mode ‡ a=0 Power Off Usage hours = nnnnn ‡ cc=02 VGA1 # # # # ‡ ee=01 Presentation ‡ a=1 Power On ‡ cc=07 HDMI1 ‡ ee=02 Bright ‡...

  • Page 90: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your device, please refer to the following information. If a problem persists, please contact your local reseller or service center. No picture or sound. ‡ Make sure all signal and power connections are properly connected. ‡...

  • Page 91: Maintenance

    ADDITIONAL INFORMATION Maintenance Proper routine maintenance can help with early fault detection and keep the IFP looking like new. IMPORTANT! Before cleaning and performing any maintenance task, make sure to unplug the power cord from the power outlet to prevent electric shock. Cleaning the Screen ‡...
