Summary of Contents for Sembdner RS 50 E
- Page 1 Operation Manual Sembdner Landscaper RS 50 E Electric Drive Sembdner Maschinenbau GmbH – Liebigstraße 16, 82256 Fürstenfeldbruck Telefon +49 (8141) 81851-0 - Telefax +49 (8141) 81851-14 Subject to technical changes; errors excepted - as of 10/2020...
-
Page 2: Table Of Contents
Table of contents Technical data ..........................3 Machine characteristics ......................3 Type label ............................3 General ............................. 3 2.1 Limitation of Liability ........................3 2.2 Guarantee/Warranty ........................4 2.3 Accident prevention regulations ....................4 Transportation/Installation ......................4 Packaging ............................. 4 Scope of Delivery ......................... -
Page 3: Technical Data
We do not accept any liability for damage and malfunctions caused by operating errors, non-compliance with these operating instructions or improper repairs. SEMBDNER Maschinenbau GmbH accepts no liability for damage resulting from the use of non-original spare parts and / or accessories. -
Page 4: Guarantee/Warranty
2.2 Guarantee/Warranty Warranty claims are to be made immediately after the damage has been determined, stating the purchase details. Complaints have to be confirmed by us. Wear parts are not covered by the warranty. Guarantee/Warranty expires with: - improper operation - improper use Nonuse of original spare parts 2.3 Accident prevention regulations... -
Page 5: Working Method Of The Landscaper
4. Working method of the landscaper 4.1 Pre rolling The pre roller crushes smaller clods so that the seeds do not decay too deep and the soil cover is not too high. 4.2 Sowing Sowing is carried out using a flexible nylon brush, which is impervious to foreign particles. The seed in the seed container is ejected from the brush shaft through an adjustable perforated plate after opening the shutter and falls onto the seed guide plate. -
Page 6: Service / Maintenance
5. Service / maintenance 5.1 Notes on maintenance Check the function of the sowing mechanism by operating the seed discharge lever. The seed container should be emptied after the procedure to ensure that the seed outlet plate can move freely. All plain bearings are self-lubricating and therefore maintenance-free! The machine must be protected from wetness and moisture!! 5.2 Notes on the battery... -
Page 7: Spare Sparts
5.3 Spare sparts Only original spare parts from SEMBDNER may be used, otherwise the guarantee claims will expire. 5.4 Customer Service Our specialist staff and our resellers, agricultural machinery dealers and motorists are at your disposal for all technical information. -
Page 8: Declaration Of Conformity
Liebigstr. 16 82256 Fürstenfeldbruck herewith declares that the product Landscaper RS 50 E Electric Drive to which this declaration relates, is in conformity with the relevant safety and health provisions stipulated by EG Directive 2006 / 42 / EG Peter Schwarzmann Fürstenfeldbruck, Sept.
