Thank you for purchasing our Jaguar VXR series of inverters.

• This product is designed to drive a three-phase induction motor. Read through this instruction

manual and be familiar with the handling procedure for correct use.

• Improper handling might result in incorrect operation, a short life, or even a failure of this

product as well as the motor.

• Deliver this manual to the end user of this product. Keep this manual in a safe place until this

product is discarded.

• For how to use an optional device, refer to the instruction and installation manuals for that

optional device.

IMO Precision Controls Ltd.

Instruction Manual

High Performance Compact Inverter

VXR-MANUAL

Table of Contents

Chapters

Need help?

Do you have a question about the Jaguar VXR3A-2E and is the answer not in the manual?

Questions and answers

Summary of Contents for IMO Precision Controls Jaguar VXR3A-2E

Page 1 • Deliver this manual to the end user of this product. Keep this manual in a safe place until this product is discarded. • For how to use an optional device, refer to the instruction and installation manuals for that optional device. IMO Precision Controls Ltd. VXR-MANUAL...
Page 2 Copyright © 2007 IMO Precision Controls Ltd. All rights reserved. No part of this publication may be reproduced or copied without prior written permission from IMO Precision Controls Ltd. All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.
Page 3: Preface
Preface Thank you for purchasing our Jaguar VXR series of inverters. This product is designed to drive a three-phase induction motor for fan and pump applications. Read through this instruction manual and be familiar with proper handling and operation of this product. Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as the motor.
Page 4 Installation • Install the inverter on a nonflammable material such as metal. Otherwise fire could occur. • Do not place flammable object nearby. Doing so could cause fire. • Do not support the inverter by its terminal block cover during transportation. Doing so could cause a drop of the inverter and injuries.
Page 5 • Ensure that the number of input phases and the rated voltage of the product match the number of phases and the voltage of the AC power supply to which the product is to be connected. Otherwise fire or an accident could occur. •...
Page 6 • The key on the keypad is effective only when the keypad operation is enabled with function code F02 (= 0, 2 or 3). When the keypad operation is disabled, prepare an emergency stop switch separately for safe operations. Switching the run command source from keypad (local) to external equipment (remote) by turning ON the "Enable communications link"...
Page 7 Maintenance and inspection, parts replacement, and installation of an option card • Turn the power OFF and wait for at least five minutes before starting inspection, parts replacement, and installation of an option card. Further, check that the LED monitor is unlit and that the DC link bus voltage between the P (+) and N (-) terminals is lower than 25 VDC.
Page 8 Conformity to the Low Voltage Directive in the EU If installed according to the guidelines given below, inverters marked with CE are considered as compliant with the Low Voltage Directive 2006/95/EC. 1. The ground terminal G should always be connected to the ground. Do not use only a residual-current-operated protective device (RCD)/earth leakage circuit breaker (ELCB)* as the sole method of electric shock protection.
Page 9 Conformity to the Low Voltage Directive in the EU (Continued) 10. Use wires listed in EN60204 Appendix C. Recomm ended wire size (mm M ain c ircuit D C R Rated c urrent (A) A pplied C ontrol power input [P 1, m otor circ ui t...
Page 10 Conformity to UL standards and Canadian standards (cUL certification) If installed according to the guidelines given below, inverters marked with UL/cUL are considered as compliant with the UL and CSA (cUL certified) standards. 1. Solid state motor overload protection (motor protection by electronic thermal overload relay) is provided in each model.
Page 11 Conformity to UL standards and Canadian standards (cUL certification) (Continued) 7. Install UL/CSA certified circuit breaker rated 240 V or more for 200 V input, 480 V or more for 400 V input between the power supply and the inverter, referring to the table below. Standard type Required torque Wire size...
Page 12 Conformity to UL standards and Canadian standards (cUL certification) (Continued) EMC filter built-in type Required torque Wire size Ib-in (N·m) AWG or kcmil (mm Power supply Inverter type voltage Main Main Control circuit Control circuit terminal terminal VXR3A-2E 10.6 (1.2) VXR5A -2E VXR8A -2E 15.9 (1.8)
Page 13: Precautions For Use
Precautions for use When driving a 400V general-purpose motor with an inverter Driving a 400 V using extremely long wires, damage to the insulation of the general-purpose motor may occur. Use an output circuit filter (OFL) if motor necessary after checking with the motor manufacturer. When the inverter is used to run a general-purpose motor, Torque the temperature of the motor becomes higher than when it is...
Page 14 Synchronous It is necessary to take special measures suitable for this motors motor type. Consult your IMO representative for details. In running Single-phase motors are not suitable for inverter-driven special variable speed operation. Use three-phase motors. Single-phase motors motors Even if a single-phase power supply is available, use a three-phase motor as the inverter provides three-phase output.
Page 15 Do not mount power capacitors for power factor correction in Discontinuance the inverter’s primary circuit. (Use the DC reactor to correct of power the inverter power factor.) Do not use power capacitors for capacitor for power factor correction in the inverter’s output (secondary) power factor circuit.
Page 16: How This Manual Is Organized
How this manual is organized This manual is made up of chapters 1 through 10. Chapter 1 BEFORE USING THE INVERTER This chapter describes acceptance inspection and precautions for transportation and storage of the inverter. Chapter 2 MOUNTING AND WIRING OF THE INVERTER This chapter provides operating environment, precautions for installing the inverter, wiring instructions for the motor and inverter.
Page 17: Table Of Contents
Table of Content Preface ..............i Chapter 4 RUNNING THE MOTOR ....... 4-1 Safety precautions ............i 4.1 Running the Motor for a Test......4-1 Precautions for use.............xi 4.1.1 Inspection and preparation prior to How this manual is organized ........xi v powering on..........
Page 18 Chapter 9 LIST OF PERIPHER AL EQUIPMENT AND OPTIONS ........9-1 Chapter 10 COMPLIANCE WITH STANDARDS..10-1 10.1 Compliance with UL Standards and Canadian Standards (cUL certification)..10-1 10.1.1 General..........10-1 10.1.2 Considerations when using Jaguar VXR in systems to be certified by UL and cUL ..........10-1 10.2 Compliance with European Standards ..10-1 10.3 Compliance with EMC Standards....10-2...
Page 19: Chapter 1 Before Using The Inverter
Chapter 1 BEFORE USING THE INVERTER 1.1 Acceptance Inspection Unpack the package and check the following: (1) An inverter and accessories below are contained in the package. • Cooling fan fixing screws (for inverters of 5.5 to 15 kW) • Keypad rear cover (with fixing screws) •...
Page 20: External View And Terminal Blocks
1.2 External View and Terminal Blocks (1) Outside and inside views Figure 1.2 Outside and Inside Views of Inverters (VXR60A-2) (2) Warning plates and label Figure 1.3 Warning Plate and Sub Nameplate (3) Terminal block location (a) VXR5A-2 (b) VXR60A-2 Figure 1.4 Terminal Blocks...
Page 21: Transportation
1.3 Transportation • When carrying an inverter, always support its bottom at the right and left sides with both hands. Do not hold covers or individual parts only. • Avoid applying excessively strong force to the terminal block covers as they are made of plastic and are easily broken.
Page 22: Inverter
Chapter 2 MOUNTING AND WIRING OF THE INVERTER 2.1 Operating Environment Install the inverter in an environment that satisfies the requirements listed in Table 2.1. Table 2.1 Environmental Requirements Table 2.2 Output Current Derating Factor in Relation to Altitude Item Specifications Output current Altitude...
Page 23 When mounting two or more inverters Horizontal layout is recommended when two or more inverters are to be installed in the same unit or panel. If it is necessary to mount the inverters vertically, install a partition plate or the like between the inverters so that any heat radiating from an inverter will not affect the one/s above.
Page 24 (3) Mounting direction Mount the inverter vertically to the mounting surface and fix it securely with four screws or bolts so that the logo "Jaguar VXR" can be seen from the front. Do not mount the inverter upside down or horizontally. Doing so will reduce the heat dissipation efficiency of the inverter and cause the overheat protection function to operate, so the inverter will not run.
Page 25: Wiring
2.3 Wiring Follow the procedure below. (In the following description, the inverter has already been installed.) 2.3.1 Removing and mounting the terminal cover and the main circuit terminal block cover (1) For inverters with a capacity of less than 5.5 kW To remove the terminal cover, put your finger in the dimple of the terminal cover (labeled "PULL"), and then pull it up toward you.
Page 26 (2) For inverters with a capacity of 5.5 and 7.5 kW To remove the terminal cover, first loosen the terminal cover fixing screw on it, and put your finger in the dimple of the terminal cover (labeled "PULL"), and then pull it up toward you. To remove the main circuit terminal block cover, put your thumbs on the handles of the main circuit terminal block cover, and push it up while supporting it with your fingers.
Page 27 (3) For inverters with a capacity of 11 and 15 kW To remove the terminal cover, first loosen the terminal cover fixing screw on it, and put your finger in the dimple of the terminal cover (labeled "PULL"), and then pull it up toward you. To remove the main circuit terminal block cover, hold the handles on the both sides of the main circuit terminal block cover, and pull it up.
Page 28: Terminal Arrangement Diagram And Screw Specifications
2.3.2 Terminal arrangement diagram and screw specifications The table below shows the main circuit screw sizes, tightening torque and terminal arrangements. Note that the terminal arrangements differ according to the inverter types. Two terminals designed for grounding shown as the symbol, G in Figures A to E make no distinction between a power supply source (a primary circuit) and a motor (a secondary circuit).
Page 29 Figure F (Note 1) Filter output (Note 2) (Note 1) Terminal screw type is listed in the table below. Inverter type Screw type VXR25A-2E Cross VXR33A-2E VXR47A-2E Hexagon VXR60A-2E VXR13A-4E Flat VXR18A-4E VXR24A-4E Cross VXR30A-4E (Note 2) Cables of EMC filter output are already connected to inverter input by factory default.
Page 30 (2) The control circuit terminals (common to all models) Screw size: M3 Tightening torque: 0.5 to 0.6 (N·m) Table 2.5 Control Circuit Terminal Block Dimension of openings in the control circuit terminals for ferrule Wire strip length (for Europe type terminal block)* Screwdriver type Allowable wire size Flat screw driver...
Page 31: Recommended Wire Sizes
2.3.3 Recommended wire sizes Table 2.7 lists the recommended wire sizes. The recommended wire sizes for the main circuits are examples of using HIV single wire (for 75°C) at an ambient temperature of 50°C. Table 2.7 Recommended Wire Sizes Recommended wire size (mm Main circuits Main circuit Nominal...
Page 32: Wiring Precautions
2.3.4 Wiring precautions Follow the rules below when performing wiring for the inverter. (1) Make sure that the power supply voltage is within the rated voltage range specified on the nameplate. (2) Be sure to connect the three-phase power wires to the main circuit power input terminals L1/R, L2/S and L3/T, or connect the single-phase power wires to the main circuit power input terminals L1/L and L2/N of the inverter.
Page 33 Follow the procedure below for wiring and configuration of the inverter. Figure 2.9 illustrates the wiring procedure with peripheral equipment. Wiring procedure Grounding terminals ( G) Inverter output terminals (U, V, W, and DC reactor connection terminals (P1 and P(+)) * DC braking resistor connection terminals (P(+), DB) * DC link bus terminals (P(+) and N(-)) * Main circuit power input terminals (L1/R, L2/S and L3/T, or L1/L and L2/N)
Page 34 Grounding terminals ( G) Be sure to ground either of the two grounding terminals for safety and noise reduction. The inverter is designed to use with a safety grounding to avoid electric shock, fire and other disasters. Grounding terminals should be grounded as follows: 1) Ground the inverter in compliance with the national or local electric code.
Page 35 Driving 400 V class series motor • If a thermal relay is installed in the path between the inverter and the motor to protect the motor from overheating, the thermal relay may malfunction even with a wiring length shorter than 50 m. In this situation, add an output circuit filter (option) or lower the carrier frequency (Function code F26).
Page 36 When a DC reactor (DCR) is not connected together with the braking resistor 1) Remove the screws from terminals P1 and P(+), together with the jumper bar. 2) Put the wire from terminal P of the braking resistor and the jumper bar on terminal P(+) in this order, then secure them with the screw removed in 1) above.
Page 37: Wiring For Control Circuit Terminals
Main circuit power input terminals, L1/R, L2/S, and L3/T (three-phase input), or L1/L and L2/N (single-phase input) 1) For safety, make sure that the molded case circuit breaker (MCCB) or magnetic contactor (MC) is turned off before wiring the main circuit power input terminals. 2) Connect the main circuit power supply wires (L1/R, L2/S and L3/T for three-phase input, or L1/L and L2/N for single-phase input) to the input terminals of the inverter via an MCCB or residual-current-operated protective device (RCD)/earth leakage circuit breaker (ELCB)*, and...
Page 38 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals Symbol Name Functions [13] Power Power supply (+10 VDC) for frequency command potentiometer supply (Potentiometer: 1 to 5kΩ) for the The potentiometer of 1/2 W rating or more should be connected. potentio- meter [12]...
Page 39 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions - Since low level analog signals are handled, these signals are especially susceptible to the external noise effects. Route the wiring as short as possible (within 20 m) and use shielded wires.
Page 40 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions Connects to PLC output signal power supply. [PLC] (Rated voltage: +24 VDC (Maximum 50 mA DC): Allowable range: +22 to signal +27 VDC) power This terminal also supplies a power to the circuitry connected to the transistor output terminals [Y1] and [Y2].
Page 41 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Name Functions Symbol Analog The monitor signal for analog DC voltage (0 to +10 V) is output. You can [FM] monitor select FMA function with slide switch SW6 on the interface PCB, and change the data of the function code F29.
Page 42 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Name Functions Symbol Transistor (1) Various signals such as inverter running, speed/freq. arrival and [Y1] output 1 overload early warning can be assigned to any terminals, [Y1] and [Y2] by setting function code E20 and E21.
Page 43 Table 2.9 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions [30A/B/ Alarm (1) Outputs a contact signal (SPDT) when a protective function has been relay activated to stop the motor. output Contact rating: 250 VAC, 0.3A, cos φ = 0.3, 48 VDC, 0.5A (for any error) (2) Any one of output signals assigned to terminals [Y1] and [Y2] can also...
Page 44: Setting Up The Slide Switches
2.3.7 Setting up the slide switches Before changing the switches, turn OFF the power and wait more than five minutes. Make sure that the LED monitor is turned OFF. Further, make sure, using a circuit tester or a similar instrument, that the DC link bus voltage between the terminals P (+) and N (-) has dropped below the safe voltage (+25 VDC).
Page 45 Figure 2.22 shows the location of slide switches for the input/output terminal configuration. Switching example Factory default SOURCE Factory default ON SINK Figure 2.22 Location of the Slide Switches 2-24...
Page 46: Mounting And Connecting A Keypad
2.4 Mounting and Connecting a Keypad 2.4.1 Mounting style and parts needed for connection (1) Mounting style You can mount a keypad in any style described below. Mounting a keypad on the panel wall (Refer to Figure 2.23.) Installing a keypad at a remote site (e.g. for operation on hand) (Refer to Figure 2.24.) Figure 2.23 Mounting Keypad on the Panel Wall Figure 2.24 Installing Keypad at a Remote Site (e.g.
Page 47: Mounting/Installing Steps
(2) Parts needed for connection To mount/install a keypad on a place other than an inverter, parts listed below are needed. Parts name Model Remarks (Note) CUBRMC-5, CUBRMC-3, Extension cable 3 cables available in length of 5m, 3m, and 1m. CUBRMC-1 M3 ×...
Page 48 Make a cut-out on the panel wall. For details, refer to Chapter 8, Section 8.4.2 "Standard keypad." To mount the keypad on the panel, fix it firmly using a pair of M3 screws put through the taps shown below. (Figure 2.27.) (Tightening torque: 0.7 N m) Figure 2.27 Mounting a Keypad on the Panel Wall Connect an extension cable (CUBRMC-5, CUBRMC-3, CUBRMC-1) or off-the-shelf...
Page 49: Cautions Relating To Harmonic Component, Noise, And Leakagecurrent
2.5 Cautions Relating to Harmonic Component, Noise, and Leakage Current (1) Harmonic component Input current to an inverter includes a harmonic component, which may affect other loads and power factor correcting capacitors that are connected to the same power supply as the inverter. If the harmonic component causes any problems, connect a DC reactor (option) to the inverter.
Page 50: Chapter 3 Operation Using The Keypad
Chapter 3 OPERATION USING THE KEYPAD 3.1 LED Monitor, Keys and LED Indicators on the Keypad 7-segment LED As shown at the right, the keypad monitor consists of a four-digit LED monitor, indicators six keys, and five LED indicators. The keypad allows you to run and stop the motor, monitor running status, and switch to the menu mode.
Page 51: Overview Of Operation Modes
Table 3.1 Overview of Keypad Functions (Continued) LED Monitor, Item Functions Keys, and LED Indicators RUN LED Lights when any run command to the inverter is active. Lights when the inverter is ready to run with a run command entered by KEYPAD key (F02 = 0, 2, or 3).
Page 52 Figure 3.1 shows the status transition of the inverter between these three operation modes. (*1) The speed monitor allows you to select the desired one from the seven speed monitor items by using function code E48. (*2) Applicable only when PID control is active (J01 = 1, 2 or 3). (*3) The Timer screen appears only when the timer operation is enabled with function code C21.
Page 53: Running Mode
3.3 Running Mode When the inverter is turned ON, it automatically enters Running mode in which you can: (1) Monitor the running status (e.g., output frequency and output current), (2) Configure the reference frequency and other settings, (3) Run/stop the motor, and (4) Jog (inch) the motor.
Page 54 Table 3.3 Monitoring Items (Continued) Display sample on LED indicator Function Monitor items Unit Meaning of displayed value the LED : ON, : OFF code E43 monitor * 1 PID command PID command/feedback amount 1*0* － * 3 , * 4 transformed to that of virtual physical value of the object to be controlled (e.g.
Page 55: Setting Up Frequency And Pid Commands
3.3.2 Setting up frequency and PID commands You can set up the desired frequency and PID commands by using keys on the keypad. It is also possible to set up the frequency command as load shaft speed, motor speed etc. by setting function code E48.
Page 56 ■ Settings under PID process control To enable the PID process control, you need to set function code J01 to "1" or "2." Under the PID control, the items that can be specified or checked with keys are different from those under regular frequency control, depending upon the current LED monitor setting. If the LED monitor is set to the speed monitor (E43 = 0), you can access manual speed commands (frequency command) with keys;...
Page 57 Setting up the frequency command with keys under PID process control When function code F01 is set to "0" ( keys on keypad) and frequency command 1 is selected as a manual speed command (when disabling the frequency setting command via communications link or multi-frequency command), switching the LED monitor to the speed monitor in Running mode enables you to modify the frequency command with the keys.
Page 58 ■ Settings under PID dancer control To enable the PID dancer control, you need to set function code J01 to "3." Under the PID control, the items that can be specified or checked with keys are different from those under the regular frequency control, depending upon the current LED monitor setting. If the LED monitor is set to the speed monitor (E43 = 0), the item accessible is the primary frequency command;...
Page 59 Setting up the primary frequency command with keys under PID dancer control When function code F01 is set to "0" ( keys on keypad) and frequency command 1 is selected as a primary frequency command (when disabling the frequency setting command via communications link and multi-frequency command), switching the LED monitor to the speed monitor in Running mode enables you to modify the frequency command with the keys.
Page 60: Running/Stopping The Motor
3.3.3 Running/stopping the motor By factory default, pressing the key starts running the motor in the forward direction and pressing the key decelerates the motor to stop. The key is enabled only in Running mode. The motor rotational direction can be selected by changing the setting of function code F02.
Page 61 Table 3.9 Menus Available in Programming Mode Refer monitor Menu # Menu Main functions shows: Displays only basic function codes to customize Section *fn: "Quick Setup" the inverter operation. 3.4.1 F codes !f__ (Fundamental functions) E codes !e__ (Extension terminal functions) C codes !c__ (Control functions)
Page 62: Setting Up Basic Function Codes Quickly -- Menu #0 "Quick Setup
3.4.1 Setting up basic function codes quickly -- Menu #0 "Quick Setup" -- Menu #0 "Quick Setup" in Programming mode allows you to quickly display and set up a basic set of function codes specified in Chapter 5, Section 5.1, "Function Code Tables." To use Menu #0 "Quick Setup,"...
Page 63 Figure 3.2 shows the menu transition in Menu #0 "Quick Setup." Figure 3.2 Menu Transition in Menu #0 "Quick Setup" Basic key operation This section gives a description of the basic key operation, following the example of the function code data changing procedure shown in Figure 3.3. This example shows you how to change function code F01 data from the factory default "...
Page 64: Setting Up Function Codes -- Menu #1 "Data Setting
(5) Change the function code data using the keys. (In this example, press the two times to change data (6) Press the key to establish the function code data. saue appears and the data will be saved in the memory inside the inverter. The display will f 02 return to the function code list, then move to the next function code.
Page 65: Checking Changed Function Codes -- Menu #2 "Data Checking
3.4.3 Checking changed function codes -- Menu #2 "Data Checking" -- Menu #2 "Data Checking" in Programming mode allows you to check function codes that have been changed. Only the function codes whose data has been changed from the factory defaults are displayed on the LED monitor.
Page 66 Basic key operation To monitor the running status on the drive monitor, set function code E52 to "2" (Full-menu mode) beforehand. (1) Turn the inverter ON. It automatically enters Running mode. In that mode, press the key to switch to Programming mode. The function selection menu appears. #ope (2) Use the keys to display "Drive Monitoring"...
Page 67 Displaying running status To display the running status in hexadecimal format, each state has been assigned to bits 0 to 15 as listed in Table 3.13. Table 3.14 shows the relationship between each of the status assignments and the LED monitor display. Table 3.15 gives the conversion table from 4-bit binary to hexadecimal. Table 3.13 Running Status Bit Assignment Notation Content...
Page 68: Checking I/O Signal Status -- Menu #4 "I/O Checking
3.4.5 Checking I/O signal status -- Menu #4 "I/O Checking" -- Using Menu #4 "I/O Checking" displays the I/O status of external signals including digital and analog I/O signals without using a measuring instrument. Table 3.16 lists check items available. The menu transition in Menu #4 "I/O Checking"...
Page 69 Basic key operation To check the status of the I/O signals, set function code E52 to "2" (Full-menu mode) beforehand. (1) Turn the inverter ON. It automatically enters Running mode. In that mode, press the key to switch to Programming mode. The function selection menu appears. $i_o (2) Use the keys to display "I/O Checking"...
Page 70 ■ Displaying control I/O signal terminals The status of control I/O signal terminals may be displayed with ON/OFF of the LED segment or in hexadecimal display. • Display I/O signal status with ON/OFF of each LED segment As shown in Table 3.17 and the figure below, each of segments "a" to "g" on LED1 lights when the corresponding digital input terminal circuit ([FWD], [REV], [X1], [X2], [X3], [X4] or [X5]) is closed;...
Page 71 Table 3.18 Segment Display for I/O Signal Status in Hexadecimal Format LED No. LED4 LED3 LED2 LED1 Input (RST)* (XR)* (XF)* X1 REV FWD terminal Output terminal A/B/C Binary Hexa- decimal on the LED monitor – No corresponding control circuit terminal exists. * (XF), (XR), and (RST) are assigned for communication.
Page 72: Reading Maintenance Information -- Menu #5 "Maintenance Information
3.4.6 Reading maintenance information -- Menu #5 "Maintenance Information" -- Menu #5 "Maintenance Information" contains information necessary for performing maintenance on the inverter. The menu transition in Menu #5 "Maintenance information" is as same as its of in Menu #3 "Drive Monitoring." Basic key operation To view the maintenance information, set function code E52 to "2"...
Page 73 Table 3.20 Display Items for Maintenance Information (Continued) Monitor Item Description shows: Number of Shows the content of the cumulative counter of times the inverter is startups started up (i.e., the number of run commands issued). 1.000 indicates 1000 times. When any number from 0.001 to 9.999 is 5_08 displayed, the counter increases by 0.001 per startup, and when any number from 10.00 to 65.53 is counted, the counter increases by 0.01...
Page 74: Reading Alarm Information -- Menu #6 "Alarm Information
3.4.7 Reading alarm information -- Menu #6 "Alarm Information" -- Menu #6 "Alarm Information" shows the causes of the past 4 alarms in alarm code. Further, it is also possible to display alarm information that indicates the status of the inverter when the alarm occurred.
Page 75 Basic key operation To view the alarm information, set function code E52 to "2" (Full-menu mode) beforehand. (1) Turn the inverter ON. It automatically enters Running mode. In that mode, press the key to switch to Programming mode. The function selection menu appears. &al (2) Use the keys to display "Alarm Information"...
Page 76: Alarm Mode
Table 3.21 Alarm Information Displayed (Continued) LED monitor shows: Item displayed Description (item No.) Shows the temperature of the heat sink. 6_11 Max. temperature of heat sink Unit: ºC Terminal I/O signal status 6_12 (displayed with the ON/OFF of LED segments) Shows the ON/OFF status of the digital I/O terminals.
Page 77 Displaying the status of inverter at the time of alarm When the alarm code is displayed, you may check various running status information (output frequency and output current, etc.) by pressing the key. The item number and data for each running information will be displayed alternately.
Page 78: Chapter 4 Running The Motor
Chapter 4 RUNNING THE MOTOR 4.1 Running the Motor for a Test 4.1.1 Inspection and preparation prior to powering on Check the following prior to powering on. (1) Check if connection is correct. Especially check if the power wires are connected to the inverter input terminals L1/R, L2/S and L3/T or L1/L and L2/N, and output terminals U, V and W respectively and that the grounding wires are connected to the ground electrodes correctly.
Page 79: Preparation Before Running The Motor For A Test--Setting Functioncode Data
4.1.3 Preparation before running the motor for a test--Setting function code data Before running the motor, set function code data specified in Table 4.1 to the motor ratings and your system design values. For the motor, check the rated values printed on the nameplate of the motor. For your system design values, ask system designers about them.
Page 80 2) Selection of tuning process Check the situation of the machine system and choose between "Tuning while the motor is stopped (P04 or A18 = 1)" and "Tuning while the motor is running (P04 or A18 = 2)." In the case of "Tuning while the motor is running (P04 or A18 = 2),"...
Page 81: Errors During Tuning
Errors during tuning Improper tuning would negatively affect the operation performance and, in the worst case, could even cause hunting or deteriorate precision. Therefore, if the inverter finds any abnormality in the results of the tuning or any error in the process of the tuning, it will display and discard the tuning data.
Page 82: Operation
------------------------------------------------ Test Run Procedure ------------------------------------------------- (1) Turn the power ON and check that the reference frequency Hz is blinking on the LED monitor. (2) Set a low reference frequency such as 5 Hz, using keys. (Check that the frequency is blinking on the LED monitor.) (3) Press the key to start running the motor in the forward direction.
Page 83: Chapter 5 Function Codes
Chapter 5 FUNCTION CODES 5.1 Function Code Tables The following tables list the function codes available for the Jaguar VXR series of inverters. F codes: Fundamental Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment...
Page 84 (F codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng Motor Sound 　 (Carrier frequenc y) 0.75 to 15 5-33 －－ (T one) 0: Level 0 (Inac tive) 1: Level 1 2: Level 2 3: Level 3...
Page 85 E codes: Extension Terminal Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng －－ T erminal [X1] Functi on Selec ting func tion code data ass igns the c orrespondi ng func tion to 5-39 terminals [X1] to [X5] as li sted below.
Page 86 (E codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng －－ T erminal [Y1] Functi on Selec ting func tion code data ass igns the c orrespondi ng func tion to 5-47 terminals [Y1], [Y2], and [30A/B/C] as lis ted below.
Page 87 (E codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng － PID Di splay Coeffici ent A -999 to 0.00 to 9990 *1 0.01 － PID Di splay Coeffici ent B -999 to 0.00 to 9990 *1 0.01...
Page 88 (E codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Unit when Code ment copying s etting page: runni ng －－ T erminal [FWD] Functi on Selec ting func tion code data ass igns the c orrespondi ng func tion to 5-39 terminals [FWD] and [REV] as lis ted bel ow.
Page 89 C codes: Control Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng Jump Frequenc y 1 0.0 to 400.0 (Hys teres is wi dth) 0.0 to 30.0 Multi-Frequency 0.00 to 400.00 *1 0.01...
Page 90 P codes: Motor 1 Parameters Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng Motor 1 (No. of poles ) 2 to 22 poles 5-55 (Rated c apacity) 0.01 to 30.00 (where, P99 data is 0, 3, or 4.) 0.01 0.01 to 30.00 (where, P99 data is 1.)
Page 91 H codes: High Performance Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng －－ Data Initial ization 0: Dis able initi ali zation 5-57 Ini tialize all func tion c ode data to the fac tory defaults 2: Ini tialize motor 1 parameters 3: Ini tialize motor 2 parameters Auto-res et...
Page 92 (H codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng ACC/DEC T ime 0.00 to 3600 0.01 6.00 (J ogging operation) *ACC ti me and DEC time are c ommon. Dec eleration Ti me for Forced Stop 0.00 to 3600 0.01...
Page 93 (A codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng T orque Boos t 2 0.0 to 20.0 (percentage wi th respec t to "A03: Rated Voltage at Base Frequenc y 2") Note: T his s etting takes effect when A13 = 0, 1, 3, or 4.
Page 94 J codes: Application Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng －－ J 01 PID Control (Mode s el ec tion) 0: Dis able 1: Enable (Process c ontrol, normal operati on) 2: Enable (Process c ontrol, i nvers e operati on) 3: Enable (Dancer c ontrol)
Page 95 (J codes continued) Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng J 73 Pos itioning Control (Start ti mer) *5 0.0 to 1000.0 J 74 (Start point; upper di gits) *5 -999 to 999 J 75 (Start point;...
Page 96 y codes: Link Functions Change Inc re- Data Default Refer to Name Data setti ng range Code Unit when ment copying s etting page: runni ng RS-485 Communi cation (Standard) 1 to 255 － (Station addres s) －－ (Communi cations error process ing) 0: Immedi ately tri p wi th alarm T ri p with alarm after running for the period s peci fied by timer y03...
Page 97 Table 5.1 Factory Defaults According to Inverter Capacity Restart mode Rated after Rated current Standard of standard capacity of momentary Nominal torque boost Power motor motor power failure applied supply Inverter type (kW) (Restart time) motor voltage (kW) F11/E34/ F09/A05 P02/A16 E37/A07 VXR3A-2...
Page 98 Changing, validating, and saving function code data when the inverter is running Function codes are indicated by the following based on whether they can be changed or not when the inverter is running: Change when Notation Validating and saving function code data running Possible If the data of the codes marked with Y* is changed with...
Page 99: Overview Of Function Codes
5.2 Overview of Function Codes This section provides an overview of the function codes frequently used for the Jaguar VXR series of inverter. Data Protection F00 specifies whether to protect function code data (except F00) and digital reference data (such as frequency command, PID command and timer operation) from accidentally getting changed by pressing the keys.
Page 100 Data for Function F01, C30 Enable the current input to terminal [C1] (C1 function) (+4 to +20 mA DC, maximum frequency obtained at +20 mA DC). Enable the sum of voltage (0 to +10 VDC) and current inputs (+4 to +20 mA DC) given to terminals [12] and [C1] (C1 function), respectively.
Page 101 Operation Method F02 selects the source that specifies a run command for running the motor. Data for F02 Run Command Source Description Enables the keys to run and stop the motor. Keypad The rotation direction of the motor is specified by (Rotation direction terminal command FWD or REV.
Page 102 Base Frequency 1 Rated Voltage at Base Frequency 1 Maximum Output Voltage 1 H50, H51 Non-linear V/f Pattern 1 (Frequency and Voltage) H52, H53 Non-linear V/f Pattern 2 (Frequency and Voltage) These function codes specify the base frequency and the voltage at the base frequency essentially required for running the motor properly.
Page 103 Examples: Normal (linear) V/f pattern V/f pattern with two non-linear points Acceleration Time 1 Deceleration Time 1 Acceleration Time 2 Deceleration Time 2 F07 specifies the acceleration time, the length of time the frequency increases from 0 Hz to the maximum frequency. F08 specifies the deceleration time, the length of time the frequency decreases from the maximum frequency down to 0 Hz.
Page 104 • If you choose S-curve acceleration/deceleration or curvilinear acceleration/ deceleration Acceleration/Deceleration Pattern (H07), actual acceleration/deceleration times are longer than the specified times. Refer to the description of H07 for details. • Specifying an improperly short acceleration/deceleration time may activate the current limiter, torque limiter, or anti-regenerative control, resulting in a longer acceleration/deceleration time than the specified one.
Page 105 When the variable torque V/f pattern is selected (F37 = 0 or 3), the output voltage may be low and insufficient voltage output may result in less output torque of the motor at a low frequency zone, depending on some characteristics of the motor itself and load.
Page 106 • Auto torque boost This function automatically optimizes the output voltage to fit the motor with its load. Under light load, auto torque boost decreases the output voltage to prevent the motor from over-excitation. Under heavy load, it increases the output voltage to increase output torque of the motor.
Page 107 The figure below shows operating characteristics of the electronic thermal overload protection α α when F10 = 1. The characteristic factors 1 through 3 as well as their corresponding switching frequencies f and f vary with the characteristics of the motor. The tables below list the factors of the motor selected by P99 (Motor 1 Selection).
Page 108 Thermal time constant (F12) F12 specifies the thermal time constant of the motor. If the current of 150% of the overload detection level specified by F11 flows for the time specified by F12, the electronic thermal overload protection becomes activated to detect the motor overload. The thermal time constant for general-purpose motors is approx.
Page 109 Restart Mode after Momentary Power Failure Restart Mode after Momentary Power Failure, Restart time Restart Mode after Momentary Power Failure, Frequency fall rate Restart Mode after Momentary Power Failure, Allowable momentary power failure time F14 specifies the action to be taken by the inverter such as trip and restart in the event of a momentary power failure.
Page 110 Restart mode after momentary power failure (Basic operation) The inverter recognizes a momentary power failure upon detecting the condition that DC link bus voltage goes below the undervoltage detection level, while the inverter is running. If the load of the motor is light and the duration of the momentary power failure is extremely short, the voltage drop may not be great enough for a momentary power failure to be recognized, and the motor may continue to run uninterrupted.
Page 111 During a momentary power failure, the motor slows down. After power is restored, the inverter restarts at the frequency just before the momentary power failure. Then, the current limiting function works and the output frequency of the inverter automatically decreases. When the output frequency matches the motor speed, the motor accelerates up to the original output frequency.
Page 112 Restart after momentary power failure (Frequency fall rate) (H14) During restart after a momentary power failure, if the inverter output frequency and the idling motor speed cannot be harmonized with each other, an overcurrent will flow, activating the overcurrent limiter. If it happens, the inverter reduces the output frequency to match the idling motor speed according to the reduction rate (Frequency fall rate: Hz/s) specified by H14.
Page 113 Bias (Frequency command 1) Bias (for Frequency 1) (Bias base point) C32, C34 Analog Input Adjustment for [12] (Gain, Gain base point) C37, C39 Analog Input Adjustment [C1] (Gain, Gain base point) C42, C44 Analog Input Adjustment [V2] (Gain, Gain base point) When any analog input for frequency command 1 (F01) is used, it is possible to define the relationship between the analog input and the reference frequency by multiplying the gain and adding the bias specified by F18.
Page 114 (Point A) To set the reference frequency to 0 Hz for an analog input being at 1 V, set the bias to 0% (F18 = 0). Since 1 V is the bias base point and it is equal to 10% of 10 V (full scale), set the bias base point to 10% (C50 = 10).
Page 115 In general, specify data of function code F20 at a value close to the rated slip frequency of motor. If you set it at an extremely high value, control may become unstable and an overvoltage alarm may result in some cases. The DC brake function of the inverter does not provide any holding mechanism.
Page 116 Specifying a too low carrier frequency will cause the output current waveform to have a large amount of ripples. As a result, the motor loss increases, causing the motor temperature to rise. Furthermore, the large amount of ripples tends to cause a current limiting alarm.
Page 117 Function (F31) F31 specifies what is output to analog output terminal [FM]. Data for Function Meter scale [FM] output (Monitor the following) (Full scale at 100%) Output frequency of the inverter Output frequency (before slip Ma ximum frequency (F03/A01) (Equivalent to the motor compensation) synchronous speed) Output frequency...
Page 118 The torque limiter and current limiter are very similar function each other. If both are activated concurrently, they may conflict each other and cause a hunting in the system. Avoid concurrent activation of these limiters. Control Mode Selection 1 Slip Compensation 1 (Operating conditions) F42 specifies the control mode of the inverter to control a motor.
Page 119 In the slip compensation and dynamic torque vector control, the inverter uses the motor parameters to control its speed. Therefore, the following conditions should be satisfied; if not, the inverter may not get the proper performance from the motor. • A single motor should be controlled. (It is difficult to apply this control to a group motor driving system.) •...
Page 120 The table below lists the discharging capability and allowable average loss of the braking resistor. These values depend upon the inverter and braking resistor models. External Braking Resistors Standard models The thermal sensor relay mounted on the braking resistor acts as a thermal protector of the motor for overheat, so assign an "Enable external alarm trip"...
Page 121 10% ED models Continuous braking Intermittent braking Braking resistor (100% braking torque) (Period: Less than 100 s) Power Resistance supply Inverter type Discharging Braking Allowable (Ω) Duty voltage capacity Type Qty. time average loss (%ED) (kW) (kWs) VXR3A-2 See IMO 0.075 VXR5A-2 VXR8A-2...
Page 122 Function code data Terminal commands assigned Symbol Active ON Active OFF 1000 1001 Select multi-frequency (0 to 15 steps) 1002 1003 1004 Select ACC/DEC time 1006 Enable 3-wire operation 1007 Coast to a stop 1008 Reset alarm 1009 Enable external alarm trip 1010 Ready for jogging 1011...
Page 123 Terminal function assignment and data setting Select multi-frequency (0 to 15 steps) -- SS1, SS2, SS4, and SS8 (Function code data = 0, 1, 2, and 3) The combination of the ON/OFF states of digital input signals SS1, SS2, SS4 and SS8 selects one of 16 different frequency commands defined beforehand by 15 function codes C05 to C19 (Multi-frequency 0 to 15).
Page 124 Enable 3-wire operation -- HLD (Function code data = 6) Turning this terminal command ON self-holds the forward FWD or reverse REV run command issued with it, to enable 3-wire inverter operation. Short-circuiting the terminals between HLD and [CM] (i.e., when HLD is ON) self-holds the first FWD or REV command at its leading edge.
Page 125 Ready for jogging -- JOG (Function code data = 10) This terminal command is used to jog or inch the motor for positioning a work piece. Turning this command ON makes the inverter ready for jogging. Simultaneous keying keys on the keypad is functionally equivalent to this command; however, it is restricted by the run command source as listed below.
Page 126 Select motor 2 / motor 1 -- M2/M1 (Function code data = 12) Turning this terminal command ON switches from motor 1 to motor 2. Switching is possible only when the inverter is stopped. Upon completion of switching, the digital terminal output "Switched to motor 2"...
Page 127 Motor 2 imposes functional restrictions on the following function codes. Confirm the settings of those function codes before use. Related function Functions Restrictions codes Non-linear V/f pattern Disabled. Linear V/f pattern only H50 to H53 Starting frequency Starting frequency holding time not supported. F24 Stop frequency Stop frequency holding time not supported.
Page 128 The UP/DOWN control is available in two modes--one mode (H61 = 0) in which the initial value of the reference frequency is fixed to "0.00" at the start of the UP/DOWN control and the other mode (H61 = 1) in which the reference frequency applied in the previous UP/DOWN control applies as the initial value.
Page 129 Enable communications link via RS-485 or field bus (option) -- LE (Function code data = 24) Turning this terminal command ON assigns priorities to frequency commands or run commands received via the RS-485 communications link (H30) or the field bus option (y98). No LE assignment is functionally equivalent to the LE being ON.
Page 130 The table below lists functions that can be assigned to terminals [Y1], [Y2], and [30A/B/C]. To make the explanations simpler, the examples shown below are all written for the normal logic (Active ON). Function code data Functions assigned Symbol Active ON Active OFF 1000 Inverter running...
Page 131 Frequency arrival signal -- FAR (Function code data = 1) This output signal comes ON when the difference between the output frequency and reference frequency comes within the frequency arrival hysteresis width specified by E30. (Refer to the description of E30.) Frequency detected -- FDT (Function code data = 2) This output signal comes ON when the output frequency exceeds the frequency detection level specified by E31, and it goes OFF when the output frequency drops below the...
Page 132 ■ Inverter output limiting with delay -- IOL2 (Function code data = 22) If the inverter enters any output limiting operation such as output torque limiting, output current limiting, automatic deceleration (anti-regenerative control), or overload stop (hit and stop), it automatically activates the stall-free facility and shifts the output frequency.
Page 133 Brake signal -- BRKS (Function code data = 57) This signal outputs a brake control command that releases or activates the brake. Refer to the descriptions of J68 through J72. Alarm output (for any alarm) -- ALM (Function code data = 99) This output signal comes ON if any of the protective functions is activated and the inverter enters Alarm mode.
Page 134 Coefficient for Constant Feeding Rate Time Coefficient for Speed Indication E39 and E50 specify coefficients for determining the constant feeding rate time, load shaft speed, and line speed, as well as for displaying the output status monitored. Calculation expression Coefficient for speed indication (E50) Constant feedi ng rate ti me (mi n) = Frequency ×...
Page 135 Terminal [12] Extended Function Terminal [C1] Extended Function (C1 function) Terminal [C1] Extended Function (V2 function) E61, E62, and E63 define the property of terminals [12], [C1] (C1 function), and [C1] (V2 function), respectively. There is no need to set up these terminals if they are to be used for frequency command sources.
Page 136 Timer Operation C21 enables or disables a timer operation that is triggered by a run command and continues ／ for the timer count previously specified with the keys. The operating procedure for the timer operation is given below. Data for C21 Function Disable timer operation Enable timer operation...
Page 137 Motor 1 (No. of poles) P01 specifies the number of poles of the motor. Enter the value given on the nameplate of the motor. This setting is used to display the motor speed on the LED monitor (refer to E43). The following expression is used for the conversion.
Page 138 where, R1: Primary resistance of the motor (Ω) Cable R1: Resistance of the output cable (Ω) V: Rated voltage of the motor (V) Rated current of the motor (A) %X (P08): Enter the value calculated by the following expression. × Cable ×...
Page 139 For P99, enter the following data according to the motor type. • P99 = 0 (Motor characteristics 0): Standard motors • P99 = 4 (Other motors): Other manufacturer’s or unknown motors • If P99 = 4 (Other motors), the inverter runs following the motor characteristics of standard motors.
Page 140 When standard motors (P99 = 0 or A39 = 0) or other motors (P99 = 4 or A39 = 4) are selected, the motor parameters are as listed in the following tables. 200 V class series Rated No-load Rated slip Nominal Motor capacity current...
Page 141 H04, H05 Auto-reset (Times and Reset interval) H04 and H05 specify the auto-reset function that makes the inverter automatically attempt to reset the tripped state and restart without issuing an alarm (for any faults) even if any protective function subject to reset is activated and the inverter enters the forced-to-stop state (tripped state).
Page 142 Cooling Fan ON/OFF Control To prolong the life of the cooling fan and reduce fan noise during running, the cooling fan stops when the temperature inside the inverter drops below a certain level while the inverter stops. However, since frequent switching of the cooling fan shortens its life, the cooling fan is kept running for 10 minutes once it is started.
Page 143 Acceleration/deceleration time <S-curve acceleration/deceleration (weak): when the frequency change is 10% or more of the maximum frequency> Acceleration or deceleration time (s): (2 × 5/100 + 90/100+ 2 × 5/100) × (reference acceleration or deceleration time) = 1.1 × (reference acceleration or deceleration time) <S-curve acceleration/deceleration (strong): when the frequency change is 20% or more of the maximum frequency>...
Page 144 H09 and STM terminal command ("Enable auto search for idling motor speed at starting") The combination of H09 data and the STM state determines whether to perform the auto search as listed below. Auto search for idling motor speed at starting Data for H09 For restart after momentary For normal startup...
Page 145 Deceleration Mode H11 specifies the deceleration mode to be applied when a run command is turned OFF. Data for H11 Function Normal deceleration The inverter decelerates and stops the motor according to deceleration commands specified by H07 (Acceleration/deceleration pattern), F08 (Deceleration time 1), and E11 (Deceleration time 2).
Page 146 Droop Control In a system in which two or more motors drive single machinery, any speed gap between inverter-driven motors results in some load unbalance between motors. The droop control allows each inverter to drive the motor with the speed droop characteristics for increasing its load, eliminating such kind of load unbalance.
Page 147 Command sources specified by H30 (Mode selection) Data for H30 Frequency command Run command Inverter itself (F01/C30) Inverter itself (F02) Via RS-485 communications link Inverter itself (F02) (standard) Via RS-485 communications link Inverter itself (F01/C30) (standard) Via RS-485 communications link Via RS-485 communications link (standard) (standard)
Page 148 Mock Alarm Clear Alarm Data H45 causes the inverter to generate a mock alarm in order to check whether external sequences function correctly at the time of machine setup. Setting the H45 data to "1" displays mock alarm on the LED monitor and issues alarm output ALM to the digital output terminal specified (see E20, E21 and E27).
Page 149 Overload Prevention Control H70 specifies the decelerating rate of the output frequency to prevent a trip from occurring due to an overload. This control decreases the output frequency of the inverter before the inverter trips due to a heat sink overheat or inverter overload (with an alarm indication of respectively).
Page 150 Input phase loss protection ( ) (Bit 1) Upon detection of an excessive stress inflicted on the apparatus connected to the main circuit due to phase loss or line-to-line voltage unbalance in the three-phase power supplied to the inverter, this feature stops the inverter and displays an alarm In configurations where only a light load is driven or a DC reactor is connected, phase loss or line-to-line voltage unbalance may not be detected because of the relatively small stress on the apparatus connected to the main circuit.
Page 151 Conversion table (Decimal to/from binary) Binary Binary Decimal Decimal Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Overload Stop J63 to J67 (Detection value, Detection level, Mode selection, Operation condition and Timer) When the monitored status index of the load exceeds the detection level specified by J64 for the period specified by J67, the inverter activates the overload stop function according to operation specified by J65.
Page 152 Mode selection (J65) J65 specifies operation when the load amount exceeds that of one specified by J64. Mode Description Data for J65 Disable The inverter cancels the overload stop function. The inverter decelerate-to-stops the motor by the Decelerate to stop specified deceleration time.
Page 153 Releasing the Brake The inverter releases the brake (Terminal command BRKS: ON) after checking torque generation of the motor, monitoring whether it applies both the output current and frequency to the motor, which are higher than ones specified for the time long enough. Name Data setting range Function code...
Page 154: Chapter 6 Troubleshooting
Chapter 6 TROUBLESHOOTING 6.1 Before Proceeding with Troubleshooting If any of the protective functions have been activated, first remove the cause. Then, after checking that the all run commands are set to off, reset the alarm. Note that if the alarm is reset while any run commands are set to on, the inverter may supply the power to the motor which may cause the motor to rotate.
Page 155: If No Alarm Code Appears On The Led Monitor
6.2 If No Alarm Code Appears on the LED Monitor 6.2.1 Motor is running abnormally [ 1 ] The motor does not rotate. Possible Causes What to Check and Suggested Measures (1) No power supplied to Check the input voltage, output voltage and interphase voltage the inverter.
Page 156 Possible Causes What to Check and Suggested Measures (7) A frequency command Check the higher priority run command with Menu #2 "Data with higher priority than Checking" and Menu #4 "I/O Checking" using the keypad, referring the one attempted was to the block diagram of the drive command block.
Page 157 [ 2 ] The motor rotates, but the speed does not increase. Possible Causes What to Check and Suggested Measures (1) The maximum frequency Check the data of function codes F03 and A01 (Maximum currently specified was frequency). too low. Readjust the data of F03 and A01.
Page 158 Possible Causes What to Check and Suggested Measures (9) In the torque control Check whether data of torque limiter related function codes (F40, mode, the output F41, E16 and E17) is correctly configured and the torque limit frequency does not switching signal TL2/TL1 is correct.
Page 159 Possible Causes What to Check and Suggested Measures (3) Frequency switching or Check whether the relay signal for switching the frequency multi-frequency command is chattering. command was enabled. If the relay has a contact problem, replace the relay. (4) The connection Check whether auto-torque boost or auto-energy saving operation between the inverter is enabled.
Page 160 [ 6 ] The motor does not accelerate and decelerate at the set time. Possible Causes What to Check and Suggested Measures Check the data of function code H07 (Acceleration/deceleration (1) The inverter ran the motor by S-curve or pattern). curvilinear pattern.
Page 161: Problems With Inverter Settings
[ 7 ] Even if the power recovers after a momentary power failure, the motor does not restart. Possible Causes What to Check and Suggested Measures Check if an undervoltage trip occurs. (1) The data of function code F14 is either "0" or Change the data of function code F14 (Restart mode after "1."...
Page 162 Possible Causes Check and Measures (3) The keypad was not Check whether the keypad is properly connected to the inverter. properly connected to Remove the keypad, put it back, and see whether the problem the inverter. persists. Replace the keypad with another one and check whether the problem persists.
Page 163: If An Alarm Code Appears On The Led Monitor
6.3 If an Alarm Code Appears on the LED Monitor Quick reference table of alarm codes Alarm Alarm Name Refer to Name Refer to code code Electronic thermal overload alarm 1 6-17 Electronic thermal overload alarm 2 Instantaneous overcurrent 6-10 Overload 6-17 Memory error...
Page 164: 0U2 Overvoltage
Possible Causes What to Check and Suggested Measures (2) Ground faults occurred Remove the wires connected to the inverter output terminals (U, V, at the inverter output and W) and perform a Megger test. terminals. Remove the part that short-circuited (including replacement of the wires, relay terminals and motor).
Page 165: Lu Undervoltage
Possible Causes What to Check and Suggested Measures (2) A surge current entered If within the same power supply a phase-advancing capacitor is the input power supply. turned ON or OFF or a thyristor converter is activated, a surge (temporary precipitous rise in voltage or current) may be caused in the input power.
Page 166: Input Phase Loss
Possible Causes What to Check and Suggested Measures (4) Peripheral equipment Measure the input voltage to find where the peripheral equipment for the power circuit malfunctioned or which connection is incorrect. malfunctioned, or the Replace any faulty peripheral equipment, or correct any incorrect connection was connections.
Page 167: 0Pl Output Phase Loss
[ 5 ] Output phase loss Problem Output phase loss occurred. Possible Causes What to Check and Suggested Measures (1) Inverter output wires are Measure the output current. broken. Replace the output wires. (2) Wires for motor winding Measure the output current. are broken.
Page 168: Alarm Issued By An External Device
[ 7 ] Alarm issued by an external device Problem External alarm was inputted (THR). (when "Enable external alarm trip" THR is assigned to one of digital input terminals [X1] through [X5], [FWD], and [REV]) Possible Causes What to Check and Suggested Measures (1) An alarm function of the Inspect external equipment operation.
Page 169: Dbh Braking Resistor Overheated
Possible Causes What to Check and Suggested Measures (6) The value set for the Check the data of function codes F09 and A05 and readjust the torque boost (F09 and data so that the motor does not stall even if you set the data to a A05) was too high.
Page 170: Electronic Thermal Overload Alarm 1
[ 10 ] Electronic thermal overload alarm 1 Electronic thermal overload alarm 2 Problem Electronic thermal protection for motor 1 or motor 2 activated. Possible Causes What to Check and Suggested Measures (1) The characteristics of Check the motor characteristics. electronic thermal did Reconsider the data of function codes (P99, F10 and F12) and not match those of the...
Page 171: Memory Error
Possible Causes What to Check and Suggested Measures (6) The service life of the Check the cumulative running time of cooling fan. Refer to Chapter cooling fan has expired 3, Section 3.4.6 "Reading maintenance information – "Maintenance or the cooling fan Information"."...
Page 172: Keypad Communications Error
[ 13 ] Keypad communications error Problem A communications error occurred between the standard keypad or the multi-function keypad and the inverter. Possible Causes What to Check and Suggested Measures (1) Break in the Check continuity of the cable, contacts and connections. communications cable Re-insert the connector firmly.
Page 173: Operation Protection
[ 17 ] Operation protection Problem You incorrectly operated the inverter. Possible Causes What to Check and Suggested Measures Although a Run command had been inputted from the input (1) The key was terminal or through the communications port, the inverter was pressed when H96 = 1 forced to decelerate to stop.
Page 174: Communications Error
Possible Causes What to Check and Suggested Measures (4) The rated capacity of the Check whether the rated capacity of the motor is smaller than that motor was significantly of the inverter by three or more orders of class or larger by two or different from that of the more orders of class.
Page 175: Data Saving Error During Undervoltage
Possible Causes What to Check and Suggested Measures (6) A high intensity noise Check if appropriate noise control measures have been was given to the implemented (e.g., correct grounding and routing of control and inverter. main circuit wires). Improve noise control. Improve noise reduction measures on the host side.
Page 176: Hardware Error
[ 21 ] Hardware error Problem Abnormality on the control PCB or related hardware. Possible Causes What to Check and Suggested Measures (1) The interface PCB is Remove the interface PCB once and remount it into the card slot wrongly mounted. until it clicks into place.
Page 177: If An Abnormal Pattern Appears On The Led Monitor While No Alarmcode Is Displayed
6.4 If an Abnormal Pattern Appears on the LED Monitor while No Alarm Code is Displayed [ 1 ] – – – – (center bar) appears Problem A center bar (– – – –) has appeared on the LED monitor. Possible Causes What to Check and Suggested Measures (1) Any of PID commands...
Page 178: Chapter 7 Maintenance And Inspection
Chapter 7 MAINTENANCE AND INSPECTION Perform daily and periodic inspection to avoid trouble and keep reliable operation for a long time. Take care of the following items during work. • Before proceeding to the maintenance and inspection, turn OFF the power and wait more than five minutes.
Page 179 Table 7.1 List of Periodic Inspections (Continued) Check part Check item How to inspect Evaluation criteria 1) Check if the display is clear. 1), 2) 1), 2) Keypad 2) Check if there is missing parts in Visual inspection The display can the characters.
Page 180: List Of Periodical Replacement Parts
Table 7.1 List of Periodic Inspections (Continued) Check part Check item How to inspect Evaluation criteria 1) Check for loose screws and 1) Retighten. 1), 2), 3), 4) Printed connectors. circuit board 2) Smelling and No abnormalities 2) Check for odor and discoloration. visual inspection 3) Check for cracks, breakage, 3), 4)
Page 181: Judgment On Service Life
7.3.1 Judgment on service life (1) Viewing data necessary for judging service life; Measurement procedures Through Menu #5 "Maintenance Information" in Programming mode, you can view on the keypad various data (as a guideline) necessary for judging whether key components such as the DC link bus capacitor, electrolytic capacitors on the printed circuit boards, and cooling fan are approaching their service life.
Page 182 -2 Measuring the capacitance of the DC link bus capacitor (during power-off time under ordinary operating condition) If the measuring method for discharging condition of the DC link bus capacitor during a power-off time under the ordinary operating condition at the end user’s installation is different from the initial measuring method at the time of factory shipment, the capacitance of the DC link bus capacitors can not be measured.
Page 183: Measurement Of Electrical Amounts In Main Circuit
Cooling fan Select Menu #5 "Maintenance Information" and check the accumulated run time of the cooling fan. The inverter accumulates hours for which the cooling fan has run. The display is in units of 1000 hours. The accumulated time should be used just a guide since the actual service life will be significantly affected by the temperature and operation environment.
Page 184 Table 7.4 Meters for Measurement of Main Circuit DC link bus Input (primary) side Output (secondary) side voltage (P (+)-N (-)) Voltage Current Voltage Current Ammeter Voltmeter Wattmeter Ammeter Voltmeter Wattmeter DC voltmeter Rectifier or Digital Moving iron Digital AC Digital AC Digital AC Moving coil...
Page 185: Insulation Test
7.5 Insulation Test Because an insulation test is made in the factory before shipment, avoid a Megger test. If a Megger test is unavoidable, follow the procedure below. Because a wrong test procedure will cause breakage of the inverter, take sufficient care. A dielectric strength test will cause breakage of the inverter similarly to the Megger test if the test procedure is wrong.
Page 186: Inquiries About Product And Guarantee
7.6 Inquiries about Product and Guarantee 7.6.1 When making an inquiry Upon breakage of the product, uncertainties, failure or inquiries, inform your IMO representative of the following information. Inverter type (Refer to Chapter 1, Section 1.1.) SER No. (serial number of equipment) (Refer to Chapter 1, Section 1.1.) Function codes and their data that you changed from the factory defaults (Refer to Chapter 3, Section 3.4.3.) ROM version (Refer to Chapter 3, Section 3.4.6.)
Page 187: Chapter 8 Specifications
Chapter 8 SPECIFICATIONS 8.1 Standard Models 8.1.1 Three-phase 200 V class series *1 Standard motor *2 Rated capacity is calculated assuming the output rated voltage as 220 V. *3 Output voltage cannot exceed the power supply voltage. *4 Use the inverter at the current enclosed with parentheses ( ) or below when the carrier frequency is set to 4 kHz or above (F26) and the inverter continuously runs at 100% load.
Page 188: Three-Phase 400 V Class Series
8.1.2 Three-phase 400 V class series *1 Standard motor *2 Rated capacity is calculated assuming the output rated voltage as 440 V. *3 Output voltage cannot exceed the power supply voltage. *4 Use the inverter at the current enclosed with parentheses ( ) or below when the carrier frequency is set to 4 kHz or above (F26) and the inverter continuously runs at 100% load.
Page 189: Single-Phase 200 V Class Series
8.1.3 Single-phase 200 V class series *1 Standard motor *2 Rated capacity is calculated by assuming the output rated voltage as 220 V. *3 Output voltage cannot exceed the power supply voltage. *4 Use the inverter at the current enclosed with parentheses ( ) or below when the carrier frequency is set to 4 kHz or above (F26) and the inverter continuously runs at 100% load.
Page 190: Models Available On Order (Emc Filter Built-In Type)
8.2 Models Available on Order (EMC filter built-in type) 8.2.1 Three-phase 200 V class series Item Specifications Type (VXR_ _ _-2E) Applicable motor rating (kW) *1 0.75 Weight (kg) 10.3 11.3 Category C2 Category C3 Emission EMC Directives (EN61800-3:2004) Category C3 Category C3 Immunity *1 Standard motor...
Page 191: Specifications Of Keypad Related
8.3 Specifications of Keypad Related 8.3.1 General specifications of keypad Table 8.1 General Specifications Items Specification Remarks Protective structure Front side: IP40, Back (mounting) side: IP20 Site to be installed In door Ambient temperature -10 to 50°C Ambient humidity 5 to 95% RH, no condensation allowed No corrosive gas, no inflammable gas, no dust, and no Ambient air direct sunlight allowed...
Page 192: Terminal Specifications
8.4 Terminal Specifications 8.4.1 Terminal functions For details about the main and control circuit terminals, refer to Chapter 2, Section 2.3.5 and Section 2.3.6 (Table 2.9), respectively. 8.4.2 Running the inverter with keypad (Note 1) When connecting an optional DCR, remove the jumper bar from the terminals [P1] and [P (+)]. (Note 2) Install a recommended MCCB or RCD/ELCB (with overcurrent protection) in the primary circuit of the inverter to protect wiring.
Page 193: Running The Inverter By Terminal Commands
8.4.3 Running the inverter by terminal commands (Note 1) When connecting an optional DCR, remove the jumper bar from the terminals [P1] and [P (+)]. (Note 2) Install a recommended MCCB or RCD/ ELCB (with overcurrent protection) in the primary circuit of the inverter to protect wiring.
Page 194: External Dimensions
8.5 External Dimensions 8.5.1 Standard models Unit: mm Power supply Dimensions (mm) Inverter type voltage Three-phase VXR3A-2 200 V VXR5A-2 Single-phase VXR3A-1 200 V VXR5A-1 Power supply Dimensions (mm) Inverter type voltage VXR1A5-4 Three-phase 400 V VXR2A5-4...
Page 195 Unit: mm Power supply Dimensions (mm) Inverter type voltage Three-phase VXR8A-2 200 V VXR11A-2 Three-phase VXR3A7-4 400 V VXR5A5-4 Single-phase VXR8A-1 200 V Power supply voltage Inverter type Three-phase 200 V VXR17A-2 Three-phase 400 V VXR9A-4 Single-phase 200 V VXR11A-1...
Page 196 Unit: mm Power supply voltage Inverter type VXR25A-2 Three-phase 200 V VXR33A-2 VXR13A-4 Three-phase 400 V VXR18A-4 Power supply voltage Inverter type VXR47A-2 Three-phase 200 V VXR60A-2 VXR24A-4 Three-phase 400 V VXR30A-4 8-10...
Page 197: Models Available On Order (Emc Filter Built-In Type)
8.5.2 Models Available on Order (EMC filter built-in type) Unit: mm Power supply Inverter Dimensions (mm) voltage type Three-phase VXR3A-2E 36.2 200 V VXR5A-2E 61.2 Single-phase VXR3A-1E 36.2 200 V Power Dimensions (mm) Inverter type supply voltage Three- VXR1A5-4E 61.5 10.5 phase 85.5...
Page 198 Unit: mm Power supply voltage Inverter type VXR8A-2E Three-phase 200 V VXR11A-2E VXR17A-2E VXR3A7-4E Three-phase 400 V VXR5A5-4E VXR9A-4E VXR8A-1E Single-Phase 200V VXR11A-1E Power supply Dimensions (mm) Inverter type voltage Three-phase VXR25A-2E 27.5 200 V VXR33A-2E Three-phase VXR13A-4E 400 V VXR18A-4E 8-12...
Page 199 Unit: mm Power supply voltage Inverter type VXR47A-2E Three-phase 200 V VXR60A-2E Power supply voltage Inverter type VXR24A-4E Three-phase 400 V VXR30A-4E 8-13...
Page 200: Standard Keypad
8.5.3 Standard keypad Unit: mm For remote operation or panel wall-mounting (The keypad rear cover should be mounted.) 8-14...
Page 201: Protective Functions
8.6 Protective Functions Alarm Name Description monitor output displays [30A/B/C] Overcurrent Stops the inverter output to protect the During protection inverter from an overcurrent resulting from acceleration overload. Short-circuit Stops the inverter output to protect the protection inverter from overcurrent short-circuiting in the output circuit.
Page 202 Alarm Name Description monitor output displays [30A/B/C] Overload Stops the inverter output if the Insulated Gate Bipolar protection Transistor (IGBT) internal temperature calculated from the output current and temperature of inside the inverter is over the preset value. External alarm Places the inverter in alarm-stop state upon receiving digital input input signal THR.
Page 203 Alarm Name Description monitor output displays [30A/B/C] Option Upon detection of an error in the communication between the communications inverter and an optional card, stops the inverter output. error detection Option error When an option card has detected an error, this function stops detection the inverter output.
Page 204 Alarm Name Description monitor output displays [30A/B/C] Protection Upon detecting a momentary power failure lasting more than 15 —- — against ms, this function stops the inverter output. momentary If restart after momentary power failure is selected, this function power failure invokes a restart process when power has been restored within a predetermined period.
Page 205 Chapter 9 LIST OF PERIPHERAL EQUIPMENT AND OPTIONS The table below lists the main peripheral equipment and options that are connected to the Jaguar VXR. Use them in accordance with your system requirements. Name of Function and application peripheral equipment Molded case MCCBs are designed to protect the power circuits between the power control board and inverter’s main terminals (L1/R, L2/S and L3/T for three-phase input...
Page 206 Name of peripheral Function and application equipment An MC can be used at both the power input (primary) and output (secondary) Magnetic sides of the inverter. At each side, the MC works as described below. When contactor (MC) inserted in the output circuit of the inverter, an MC can also switch the motor drive power supply between the inverter output and commercial power lines.
Page 207 Name of option Function and application A DCR is mainly used for power supply matching and for input power factor DC reactors correction (for reduction of harmonics). (DCRs) 1) For power supply matching - Use a DCR when the capacity of a power supply transformer exceeds 500 kVA.
Page 208 Name of option Function and application An external potentiometer may be used to set the drive frequency. Connect the External potentiometer to control signal terminals [11] to [13] of the inverter. potentiometer for frequency commands Allows you to monitor the status of the inverter including voltage, current, and Multi-function input power, as well as to set various parameters in a conversational mode.
Page 209: Chapter 10 Compliance With Standards
Chapter 10 COMPLIANCE WITH STANDARDS 10.1 Compliance with UL Standards and Canadian Standards (cUL certification) 10.1.1 General Originally, the UL standards were established by Underwriters Laboratories, Inc. as private criteria for inspections/investigations pertaining to fire/accident insurance in the USA. Later, these standards were authorized as the official standards to protect operators, service personnel and the general populace from fires and other accidents in the USA.
Page 210: Compliance With Emc Standards
10.3 Compliance with EMC Standards 10.3.1 General The CE marking on inverters does not ensure that the entire equipment including our CE-marked products is compliant with the EMC Directive. Therefore, CE marking for the equipment shall be the responsibility of the equipment manufacturer. For this reason, IMO’s CE mark is indicated under the condition that the product shall be used within equipment meeting all requirements for the relevant Directives.
Page 211 4) In the case of VXR5A-1E, motor cable shall be wired through the ring core (that comes with the inverter), and the ring core shall be fixed by the EMC grounding flange. For VXR5A-1E, a ring core comes with the inverter. Figure 10.2 Connecting Shielded Cables 5) If noise from the inverter exceeds the permissible level, enclose the inverter and its peripherals within a metal enclosure as shown in Figure 10.3.
Page 212: Harmonic Component Regulation In The Eu
10.4 Harmonic Component Regulation in the EU 10.4.1 General comments When you use general-purpose industrial inverters in the EU, the harmonics emitted from the inverter to power lines are strictly regulated as stated below. If an inverter whose rated input is 1 kW or less is connected to public low-voltage power supply, it is regulated by the harmonics emission regulations from inverters to power lines (with the exception of industrial low-voltage power lines).
Page 213: Compliance With The Harmonic Component Regulation
10.4.2 Compliance with the harmonic component regulation Table 10.3 Compliance with Harmonic Component Regulation Power supply Inverter type w/o DC reactor w/ DC reactor voltage √ * √ * VXR3A-2 Three-phase 200 V √ * √ * VXR5A-2 √ VXR1A5-4 —...
Page 214 MEMO...
Page 215 In no event will IMO Precision Controls Ltd. be liable for any direct or indirect damages resulting from the application of the information in this manual.
Page 216 IMO Precision Controls Ltd. 1000 North Circular Road, Staples Corner, London, NW2 7JP England Phone: +44 (0)20 8452 6444 Fax: +44 (0)20 8450 2274 http://www.imopc.com 2007-03 S.Mc (Issue 1)
