Table of Contents The CHAMBERLAIN Warnings ······················································· 3 Chamberlain Features ········································ 6 Installation of Occupant Positioning System ············ 10 Installation of Tether Extension Assembly ·············· 14 Installation of Positioning Vest ···························· 16 Installation of Occupant in Leg Harness ················· 18 Instructions Installation of Occupant in Positioning Vest ············...
Page 2
WA R N I N G ! WARNINGS, CONTINUED F A I L U R E T O C O M P L Y W I T H T H E A list of child passenger safety technicians can be found at F O L L O W I N G W A R N I N G S C A N R E S U L T the Safe Kids Worldwide website: www.safekids.org.
Page 3
WARNINGS, CONTINUED Chamberlain Features This occupant posi- Top Tether Snap Hook tioning system must only be installed in forward facing vehi- Spacer Bar cle seats. Support Harness Adjuster Never install this Pull Strap occupant position- ing system in side Lower facing (Figure A) or Anchor rear facing (Figure...
Chamberlain Features, Continued Chamberlain Features, Continued EZ-Up Head Rest Tether Extension Assembly Snap Hook Adjuster NOTE: This Vest is for positioning only! The vehicle lap and shoulder belt must always be used! Positioning Vest EZ-Up Head Rest Support Plate Page 7 Page 8...
Installation of Occupant Positioning System 1. Lay the Support Snap Hook Spacer Harness out on the This vehicle seat and over the vehicle head rest. If a head rest is not present, simply lay it behind the vehicle seat back (Figures A and B).
Page 6
Installation of Occupant Positioning System, Cont. Installation of Occupant positioning system, Cont. 2. Attach one of the NOTE: If it is lower anchor snap necessary to hooks to it’s corre- use the tether sponding vehicle extension assembly, lower anchor then completely (Figures C and D).
Installation of Occupant positioning system, Cont. Installation of Tether Extension Assembly NOTE: Figure H shows NOTE: If the top tether the Occupant Position- snap hook (See arrow - ing system installed. Figure A) can not reach the vehicle’s tether an- chor, then proceed with the following steps to add the tether extension...
Installation of Tether Extension Assembly, Continued Installation of Positioning Vest 4. Grasp the loose end WARNING! of the tether exten- This vest is for positioning sion assembly and only! The vehicle lap and pull towards the shoulder belt must always Support Harness be used with this occupant (Figure E) until the...
Installation of Positioning Vest, Continued Installation of Occupant in Leg Harness 5. Repeat Steps 3 and 4 for the NOTE: The Leg Har- other Support Harness strap ness portion of the so that the vest is attached Chamberlain is de- as in Figure E.
Installation of Occupant in Leg Harness, Continued Installation of Occupant in Positioning Vest 3. Place the occupant WARNING! on the leg harness This vest is for positioning straps (Figure E). only! The vehicle lap and shoulder belt must always 4. Grasp one of the be used with this occupant straps (Figure E), positioning system (Figure...
Page 11
Installation of Occupant in Positioning Vest, Cont. Installation of Occupant in Positioning Vest, Cont. WARNING! The Ve- 5. Attach the right shoulder hicle’s lap AND portion to the main body of shoulder belt must the vest (Figure D). always be used with this occupant posi- 6.
Page 12
Installation of Occupant in Positioning Vest, Cont. Installation of Occupant in Positioning Vest, Cont. 9. Open the Denim belt NOTE: Verify that the guide on the occupant’s lap and shoulder belt shoulder next to the portions of the vehi- shoulder portion of the cle’s lap and shoulder vehicle seat belt (Figure belt are positioned as...
Installation of the EZ-Up Head Rest to an Adjustable Vehicle Head Rest 1. Remove the EZ-Up This Head Rest from the box. 2. Place it in front of the vehicle’s head rest, with the “tail” lying over the top of the vehicle’s head rest (Figure A).
Installation of the EZ-Up Head Rest to an Adjustable Installation of the EZ-Up Head Rest When there is Vehicle Head Rest, Continued not a Vehicle Head Rest NOTE: It is important to NOTE: If the Support wrap the head rest tightly Harness straps are not for optimum perfor- already loose, then loos-...
Page 15
Installation of the EZ-Up Head Rest When there is Installation of the EZ-Up Head Rest When there is not a Vehicle Head Rest, Continued not a Vehicle Head Rest, Continued notch (See Arrow - Fig- 1. Remove the head rest ure C - Opposite Page) in from the box.
Merritt Manufacturing, Inc. (Merritt) provides the following limited war- ranty on the Chamberlain: 5. Verify that the head rest Merritt warrants to the original purchaser of the Chamberlain that, if is snugly attached to the properly used strictly in accordance with the instructions and specifi- support plate.
Page 17
Limited Warranty, Continued AMOUNT OF DAMAGES ABOVE THE AGGREGATE DOLLAR AMOUNT PAID BY THE CUSTOMER FOR THE PURCHASE OF THE PRODUCT COVERED BY THIS WARRANTY. This LIMITATIONS OF WARRANTIES AND OTHER WARRANTY TERMS AND STATES’ LAW MERRITT FULLY DISCLAIMS AND MAKES NO IMPLIED WARRAN- TIES OF ANY KIND, INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR- TICULAR USE, AND MAKES NO EXPRESS WARRANTIES BE-...
Page 18
This Page Intentionally The Chamberlain Merritt Manufacturing, Inc. Left Blank P.O. Box 17152 Indianapolis, IN 46217-0152 Phone: 317-409-0148 Fax: 317-893-2567 www.eztether.com E-Mail: info@eztether.com Revision 1; January, 2014 Page 35...
